IRiver N11 Manuale utente

www.iriver.com

Thank you for your purchase.

Please read this manual carefully before using your new player.

Instruction Manual

N11

Quick Start

Turning on/off the Player …………………… 1

Playing Music ……………………………… 2

Listening to FM Radio ……………………… 3

Recording …………………………………… 4

Charging the Battery ……………………… 5

1 Before Using the Product

Thank you for your iriver purchase ……… 8

Copyrights/Certification/Trademarks/

Limited Liability

……………………………… 9

Safety Instructions ………………………… 10

2 Getting started

Components ………………………………… 14

Locating the Controls ……………………… 15

LCD Screen ………………………………… 16

Connecting the Product …………………… 18

Installing Software ………………………… 21

Downloading from PC ……………………… 25

3 Basic Operation

Selecting the Function Mode ……………… 28

Playing a Music File ………………………… 29

Browser Function …………………………… 38

Listening to FM Radio ……………………… 39

Recording …………………………………… 44

4 Useful Features

Menu Tree …………………………………… 50

Menu Operation …………………………… 51

Customizing the Function Settings (Menu)

… 53

5 Additional information

Firmware Upgrade ………………………… 72

Initializing the Player (Format) …………… 73

Troubleshooting …………………………… 74

Specifications ……………………………… 76

FCC ………………………………………… 77

Contents

Turning on/off the Player

I Turning on the player

Press the [ ] button.

The player will be turned on and previous function mode will

be displayed.

I Turning off the player

Press and hold the [ ] button.

The player will be turned off.

Note

If the player does not power ON, please replace your battery.

Button image with white background = Press the button. (Example: )

Button image with black background = Press and hold the button. (Example : )

Note

Quick Start

Press the [ ] button to select the <MUSIC>

mode, then press the [ ] button.

Previous music file will resume playback.

When powered on, press and hold the [ ] button.

The function mode screen will be displayed.

I Adjusting the volume

: Decreases volume level

: Increases volume level

I Selecting a music file

: Selects previous music file

: Selects next music file

Playing Music

I Connecting earphone

Connect earphone to the player as shown

in the image.

Type A Type B (Optional)

Note

The player will be automatically turned off if it is being left for a period

of time without doing anything.

(For more information about Timer Setting, refer to page 63.)

For more information about playing music, refer to page 29-37.

Listening to FM Radio

I Selecting the <FM RADIO> mode

Press and hold the [ ] button.

The function mode screen will be displayed.

Press the [ ] button to select the <FM RADIO>

mode, then press the [ ] button.

The <FM RADIO> station will be displayed.

I Searching for a FM radio frequency

: To previous station

: To next station

I Adjusting the volume

: Decreases volume level

: Increases volume level

Note

In areas where the signal is weak, some channels may be unavailable

or reception may be poor.

For more information about FM radio station, refer to 39-43.

Quick Start

Recording

I Selecting the <RECORDING> mode

Press and hold the [ ] button.

The function mode screen will be displayed.

Press the

[ ]

button to select the <RECORDING>

mode, then press the [ ] button.

The <RECORDING> standby screen will be displayed.

I To start recording

Press the [ ] button.

The recording will be started.

Press the [ ] button once again.

The recording will be finished.

I To confirm recorded content

Press the [ ] button.

The recorded content will be played.

Note

For more information about recording, refer to page 44-47.

Charging the Battery

I Charging with mini USB adapter

Push "PUSH OPEN" on the back of your player to disconnect its cap as the image below.

Connect the USB port and PC with mini USB cable to charge battery.

Note

You can also charge the battery when the player is tuned off.

Charging Time : 1.5 hours (At fully discharged/Stop mode)

I 1 Before Using the Product

Chapter

www.iriver.com

Thank you for your iriver purchase

Welcome ……………………………………………………………… 8

iriver’s web site ……………………………………………………… 8

Copyrights/Certification/Trademarks/Limited Liability

Copyrights/Certification/Trademarks/Limited Liability …………… 9

Safety Instructions

Precautions for Player …………………………………………… 10

Precautions for Others …………………………………………… 12

1 I Before Using the Product

Thank you for your iriver purchase

I Welcome I

Thank you for purchasing iriver's N11 player,

This user's manual is provided to help you safely use the product.

Please read this manual carefully before using it.

Thank you.

http://www.iriver.com

The iriver's home page provides the overview of company and products, other related information,

and answers to customers' questions.

Firmware and software updates are also available as well as the most recent information about your

iriver product.

You may get useful information from "User's Forum" and FAQ.

as newly announced product, firmware upgrade, various promotion events via email.

I iriver's web site I

Copyrights/Certification/Trademarks/Limited Liability

iriver Limited has all the rights of the patent, trademark, literary property and intellectual property related

to this manual. You may not copy or reproduce any part of this manual unless authorized by iriver Limited.

You can be punished by using any part of this manual illegally.

The software, audio and video which have an intellectual property are protected by copyright and

international laws.

It is user’s responsibilities when he/she reproduces or distributes the contents created by this product.

The companies, institutions, products, people and events used in examples are not real data. We don't

have any intension to be related with any companies, institutions, products, people and events through

this manual and should not draw inferences.

User’s are responsible for observing the copyrights and intellectual properties.

I Copyrights I

CE, FCC, MIC

I Certification I

Neither the manufacturer, importers nor dealers is responsible for any accidental damage including bodily injury

or any damage resulting from mususe or unsuitable operation by you. The information on this manual is prepared

with the current player specifications.

The manufacturer, iriver Limited, is adding new features to the product and may persistently apply new technologies

hereafter.

All standards may be changed at any time without notice.

I Limited Liability I

WOW technology is incoporated under license from SRS Labs, Inc.

is a tradmark of SRS Labs, Inc.

Windows, Windows 98SE, Windows ME, Windows 2000, Windows XP and Windows Media Player are

the registered trademarks of Microsoft Corp.

I Trademarks I

1 I Before Using the Product

Safety Instructions

For your safety, please read before use.

Safety Instructions

For your safety, please read before use.

Do not put metallic substance

such as coin, hair pin or

flammable substance into the

product.

It may cause malfunction.

Do not put heavy substance over

the product.

It may cause malfunction.

Do not put the product under

moist, dusty, and black smoky

environment.

It may cause malfunction.

Do not dampen your player with

rain (water), beverage, chemicals,

cosmetics and so on.

Never turn on the player. Quickly

wipe it off with dry cloth and get

service from authorized technician.

Do not spray water on the player

in direct. Wipe player's skin with

soft cloth or towel.

It may cause malfunction.

Do not use chemicals and

detergents since they deteriorate

and peel off product's skin.

It may cause malfunction.

I Precautions for Player I

Do not press more than 2 buttons

at the same time or dismantle the

player indiscriminately.

It may cause damage and

malfunction.

Keep out of direct sunlight and

extreme heat and cold.

It may cause malfunction.

Do not drop or subject the

device to impact.

It may cause damage and

malfunction.

Keep the player away from strong

magnets. Magnetic substance

such as magnet, CRT, TV,

monitor, speaker, and so on may

cause your player damaged.

It may cause malfunction.

Never dismantle, repair, or rebuild

your player without permission.

It may cause malfunction.

Data can be damaged because

of physical impact, lightning and

power failure.

Users are responsible for creating

backup data and iriver Limited is not

responsible for any damaged data.

1 I Before Using the Product

Safety Instructions

For your safety, please read before use.

Do not wear headphone/earphone

with high volume when walking,

especially in crosswalk.

Do not use headphone /

earphones at high volume.

It may cause damage or your injury.

Avoid impacting the player

against other objects when it is

in your pocket or backpack.

It may cause injury.

Do not listen music via

headphone/earphone with high

volume for a long time.

It may cause injury.

Be careful that necklace style

earphone is not entangled.

It may cause damage or your injury.

Be careful that headphone/

earphone is not to be caught

in door of vehicle such as car,

subway, etc.,

I Precautions for Others I

I 2 Getting started

Chapter

Components

Components ……………………………………………………… 14

Locating the Controls

Locating the Controls ……………………………………………… 15

LCD Screen

MUSIC mode ……………………………………………………… 16

FM RADIO mode …………………………………………………… 17

RECORDING mode ……………………………………………… 17

Connecting the Product

Connecting earphone – Type A ………………………………… 18

Connecting earphone – Type B (Optional) ……………………… 18

Connecting to PC ………………………………………………… 19

Disconnecting from PC …………………………………………… 20

Installing Software

Minimum requirements for software installation ………………… 21

Installing iriver plus 2 ……………………………………………… 21

Downloading from PC

Downloading from PC …………………………………………… 25

2 I Getting Started

Components

Accessories are subject to change without notice and may vary from image shown.

Mini USB adapter Installation CD Instruction manual/Warranty card/

Quick start guide

Main unit Type A

Necklace style earphone

Type B (Optional)

Cap, Necklace

I Components I

Note

For more information about assembling

necklace, refer to page 18.

Locating the Controls

Your player may differ slightly from that shown in the illustrations.

Rear View – Type A

Rear View – Type B (Optional)

Front View

LCD Screen

Built-in

Microphone

RESET button

USB Connection

Jack PUSH OPEN button

Cap

Earphone Jack

Necklace Connection Loop

PUSH OPEN button

Cap

Play/Stop

button

Previous/Fast Reverse

button

Next/Fast forward

button

Left Side View

Mode/Recording

button

Volume -

button

Volume +

button

Right Side View

I Locating the Controls I

2 I Getting Started

LCD ScreenLCD Screen

I MUSIC mode I

1 Current time

2 Title name

3 Current play status

4 Progress bar

5 Battery indicator

6 Play mode

7 Played time l Total playing time of the title

8 File format

9 Volume level

10 Bit rate I Sampling rate

Note

IRM (iriver Rights Management)

The iriver Rights Management is a digital music format designed by iriver Limited.

The IRM technology protects copyright and property from unauthorized usage of digital contents provided by

iriver Limited.

Please visit our web site for details about this music format.

File format

ASF IRM MP3

OGG WAV WMA

1 Selected frequency

2 Preset indicator

3 Stereo indicator

4 Channel number

5 Frequency bar

1 Recording status

2 Current play status

3 Remaining memory space

4 Recorded time I Remaining time

5 Recording file name

I FM RADIO mode I

I RECORDING mode I

Indice

Altri manuali IRiver Lettore MP3

IRiver

IRiver Astell&Kern PPM12 Manuale utente

IRiver

IRiver iFP-300 Series Manuale utente

IRiver

IRiver iFP-799 Manuale utente

IRiver

IRiver T8 Manuale utente

IRiver

IRiver HP-120 Manuale utente

IRiver

IRiver astell & kern AK120 Manuale utente

IRiver

IRiver iFP-300 Series Manuale utente

IRiver

IRiver iFP-1090 Istruzioni per il montaggio

IRiver

IRiver N10 512MB Manuale utente

IRiver

IRiver E300 Manuale utente

IRiver

IRiver astell & kern AK100 Manuale utente

IRiver

IRiver S10 1GB Manuale utente

IRiver

IRiver T5 2GB Manuale utente

IRiver

IRiver iFP Series Manuale utente

IRiver

IRiver MP3 Player T30 Manuale utente

IRiver

IRiver Astell & Kern AK120 II Manuale utente

IRiver

IRiver H10 Manuale utente

IRiver

IRiver N10 512MB Manuale utente

IRiver

IRiver iFP-120 Manuale utente

IRiver

IRiver S100 Soft Silhouette Manuale utente

IRiver

IRiver Spinn 4GB Manuale utente

IRiver

IRiver PMP-120 Manuale utente

IRiver

IRiver CLIX Manuale utente

IRiver

IRiver iGP-100 Manuale utente

Manuali Lettore MP3 popolari di altre marche

Blaupunkt

Blaupunkt Compact Drive MP3 Manuale utente

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuale utente

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuale utente

Naxa

Naxa NMV-173NX Manuale utente

Philips

Philips PSA250 Manuale utente

Zipy

Zipy go! Waving Manuale utente

Sylvania

Sylvania SMPK4068 Manuale utente

Sony

Sony NW-MS7 - Memory Stick Walkman Manuale utente

Irradio

Irradio RF-42UC Manuale utente

NABAIJI

NABAIJI SWIM MUSIC 100 Manuale utente

Laser

Laser MP3-A9-4GB Manuale utente

Samsung

Samsung YP-T7F Manuale utente

Savant

Savant SMS-1001-00 Guida di riferimento rapido

Trevi

Trevi XP 71 BT Manuale utente

AGPtek

AGPtek C2 Manuale utente

MobiBlu

MobiBlu DAH-1500i Manuale utente

Denver

Denver MPS-201 Manuale utente

Steren

Steren MP3-002 Manuale utente
