Assembly instructions
for the Advertising tower 40.129
constisting of:
- 8x Aluminium proles à 1000 mm incl. 8 bores
- 8x Aluminium cross proles with pointed screws for the lower and upper mounting
- 8x Aluminium cross proles for the middle mounting
- 24x H-proles à 622 mm to stabilize the panels.
- 4x Extension bolts for aluminium prole
8x 8x
8x
4x
24x
System
®
exhibition
Important during assembly
Pointed screws must be used for all proles that have holes.
1. Mount the bottom cross proles
including the pointed screws to
form the corner.
2. Now mount the rst middle cross
proles.
3. Mount the required lower cross
proles including pointed screws.
4. Now mount the next rst middle
cross proles.
System
®
exhibition
5. Insert the bolts in the prole. 7. Push the top proles onto the
bolts. Ensure that the holes face
upward.
8. Now mount the second middle
cross prole.
9. Finally mount the last cross prole
including the pointed screws.
