Itm Digi-Sense TraceableLIVE 18000-31 Manuale utente

CONTROLS

WiFi: Enables WiFi capabilities.

SET: Use to set: date/time, alarm settings

(if WiFi has not been congured).

UP: Adjusts setting up in SET menu.

DOWN: Adjusts setting down in SET menu

CHANNEL SELECT: Selects which channel to

display or select all channel view mode to view all

channels.

PLAY/PAUSE: In single channel view mode,

select second line display: current time, current

minimum, current maximum, alarm setting lower

limit, alarm setting higher limit.

C/F: Selects temperature unit

CLEAR: Press to clear current min/max values.

Note: “WiFi enabled” is indicated by the ashing WiFi

symbol. It also indicates that WiFi network needs to

be congured. If WiFi network has been congured,

and WiFi symbol ashes, it indicates an alarm of

unsuccessful data transmission to cloud server.

Press button to clear alarm, or alarm will clear

automatically upon next successful transmission.

DEVICE SPECIFICATIONS:

• Temperature Range: 0 to 50°C (32 to 122°F)

• Humidity Range: 0 to 95%

• Temperature/Humidity Sampling Rate: 9 seconds

• 6525: CO2 Range: 0 to 10,000 ppm (1%)

• 6526: CO2 Range: 0 to 20%

• CO2 Sample rate: 5 min default, user-adjustable

• Default WiFi Transmission Frequency: 15 minutes

• Maximum number of Stored Records: 672 (7 days if set

to 15 minutes interval)

• Max. Stored Alarms: 100

• Battery: 4 AAA Alkaline battery

DISPLAY MODES

SINGLE CHANNEL MODE

• LCD displays information on channel 1, 2, or 3. Scroll

through: current time -> current minimum / current

maximum -> alarm setting minimum / alarm setting

maximum -> current time.

• Scrolling interval: 3 seconds.

• Press CHANNEL SELECT button to select the desired

channel, or all channels.

• Channel 1 displays humidity; Channel 2 displays

temperature; channel 3 displays pressure.

• To pause scrolling, press PLAY/PAUSE. To resume

scrolling, press PLAY/PAUSE again. To fast forward,

press PLAY/PAUSE to move to next item.

• Once desired information is displayed, press Play/

Pause button again to pause scrolling, otherwise

second line resumes scrolling.

ALL CHANNEL MODE

• To view all Channel 1, 2, and 3. Press CHANNEL

SELECT button to select all channels.

• CH123 symbol will appear on display.

SELECTING CHANNEL

• While the device is not in SETUP Mode, press

Channel/Select button to select channel.

• If Channel 1 (HUMIDITY) is selected, CH1 symbol will

appear on display.

• If Channel 2 (TEMPERATURE) is selected, CH2

symbol will appear on display.

• If Channel 3 (CO2) is selected, CH3 symbol will appear

on display.

• If in all channel view mode, the rst line displays

Channel 1, second line Channel 2, and third line

Channel 3. CH123 symbol will appear on display.

SENSORS

6525: A dongle with temperature, humidity, and carbon

dioxide sensor is provided with unit. Used to measure

and monitor ambient temperature, ambient humidity, and

ambient CO2levels.

IMPORTANT: PLUG DONGLE INTO DEVICE BEFORE

INSERTING BATTERIES AS THIS WILL CAUSE

INCORRECT READINGS.

If dongle sensor was plugged into device after batteries

were installed, remove dongle sensor until LCD reads “-

-.- -” on CH1 and CH2 (about 10 seconds) and then plug

dongle back into device.

6526: An external sensor with extended cable is

provided with unit. Used to measure and monitor

temperature, humidity, and carbon dioxide in a chamber

or other enclosed environment.

CLEAR CURRENT MINIMUM/MAXIMUM MEMORY

1. Press CHANNELSELECT to select probe channel to

be cleared.

2. CH1 will clear Channel 1; CH2 will clear Channel 2;

CH3 will clear Channel 3 and in all channel mode

CH123 will clear Channels 1, 2, 3.

3. Press CLEAR button to clear current minimum and

maximum readings.

4. Each clear of the Minimum/Maximum memory will

also trigger a transmission of current reading(s) to

TraceableLIVE service, if connected. This will display

in EVENT HISTORY with label “DEVICE CHECK”.

DEVICE SETUP

SCENARIO 1: WiFi is disabled.All settings are

congurable.

1. Press and hold SET button for 3s to enter setup

menu.

2. The rst ashing number is the year date setting.

Press the UP or DOWN arrow to set to the current

year. Press the PLAY/PAUSE button to save and

proceed to the next setting.

3. Continue to set the remaining parameters (Month-

>Day->Hour->Minute->Time Format (12H/24H)

->Channel 1 Minimum Alarm->Channel 1 Maximum

Alarm->Channel 2 Minimum Alarm->Channel

2 Maximum Alarm->Channel 3 Minimum Alarm

->Channel 3 Maximum Alarm->CO2Sampling Rate

->Alarm Repost Enable/Disable -> Alarm Repost

Interval Setting (if Alarm Repost is enabled). Press

PLAY/PAUSE to proceed to the next parameter.

Pressing PLAY/PAUSE after the last parameter is set

will exit setup mode.

SCENARIO 2: WiFi is enabled. Alarm settings are not

congurable on the device and can only be set through

the TraceableLIVE cloud service interface.

1. Press and hold the SET button for 3 seconds to enter

setup menu.

2. The rst ashing number is the year date setting.

Press the UP or DOWN arrow to set to the current

year. Press the PLAY/PAUSE button to save and

proceed to the next setting.

3. Continue to set the remaining parameters (Month-

>Day->Hour->Minute->Time Format (12H/24H).->

CO2 sampling rate -> Alarm Repost Enable/Disable

-> Alarm Repost Internal Setting (If Alarm Repost

is enabled). Press PLAY/PAUSE to proceed to the

next parameter. Pressing PLAY/PAUSE after the last

parameter is set will exit setup mode.

NOTE: Setting the time while WiFi is enabled is only

intended for initial device setup. Once connected

to the TraceableLIVE service, the device time will

be synchronized daily for selected time zone in

TraceableLIVE.

ALARM

1. If an alarm triggers, the LCD will automatically display

the alarming channel, and the temperature reading, HI

ALM or LO ALM symbols ash. If temperature is below

low alarm setting, MIN symbol ashes; if temperature

is above high alarm setting, MAX symbol ashes.

Audible alarm will continue beeping for 30 seconds

and will beep once every 15 seconds until alarm is

acknowledged by pressing the CLEAR button.

2. If alarms trigger on both channels, LCD will display

Channel 1.

3. Use CHANNEL SELECT to select which channel to

display. If the displayed channel is not alarming, the

LCD will not ash, but the buzzer will remain active.

4. If an alarm is triggered, the second line of the LCD will

no longer scroll, and if the device is in single channel

display mode, the alarming set point will display on the

second line.

5. To clear an alarm, press the CLEAR button. The LCD

will stop ashing, buzzer will stop beeping, and LCD

second line will resume scrolling.

6. Once an alarm is triggered, the device will post the

alert to the TraceableLIVE service immediately. If

connectivity is currently lost, the device will store the

alarm until it reconnects. Devices can store up to 100

alarm events in internal memory.

DISPLAYING °F OR °C

• To display the temperature readings in Fahrenheit (°F)

or Celsius (°C)

on device, press the C/F button.

• Note: Changing from °C to °F in the TraceableLIVE®

Cloud, will not change readings on device (see

TraceableLIVE® Cloud instructions).

• Note: Changing from °C to °F on device, will not

change the readings in the TraceableLIVE® cloud.

CONFIGURE WiFi NETWORK: AP PROVISIONING

• Press WiFi button to enable WiFi function. If it is rst

time enabled, WiFi symbol will ash.

• Press and hold WiFi button for 3 secs until device

displays “AP”. To abort, press and hold WiFi button.

• Press WiFi button again, the device will display “AP

UAIT” (AP WAIT).

• After 5 to 10 seconds, “AP rEAdy” (AP ready) will

appear on display.To abort, press and hold CLEAR

button until the device restarts.

NOTE: WiFi conguration will be cleared if aborted at

this stage.

• Use a mobile phone or wireless capable laptop,

connect to Network ID “CC6525-XXXX” or “CC6526-

XXXX”, where xxxx is last 4-digit of the device’s serial

number (S/N).

• Open a web browser, type 192.168.1.1, the setup

webpage will appear:

• From Add Proles section, from the drop-down

list, select the intended Network ID, and then input

security type, password. Please double check these

information are correct. Security type is default to

WPA2.

• Or if the intended Network ID is not shown in the list,

scroll to the last item of the list “Other, please specify:”

and select. A new input box is shown:

• Type Network ID in the box, and then select security

type and type password;

• Click Add button.

• If network is congured successfully, the device

reboots, and is ready to use.

• If network conguration fails, device displays “Err”, and

then press CLEAR button, the device reboots. Make

sure Network ID, password, and security type are

selected right, and try to congure the network again.
