iWave Corazon-AI Manuale utente
Quick Start Guide
R1.0
Corazon-AI
Edge AI Platform
Disclaimer
iWave Systems reserves the right to change details in this
publication including but not limited to any Product specification
without notice.
No warranty of accuracy is given concerning the contents of the
information contained in this publication. To the extent
permitted by law no liability (including liability to any person by
reason of negligence) will be accepted by iWave Systems, its
subsidiaries or employees for any direct or indirect loss or
damage caused by omissions from or inaccuracies in this
document.
Trademarks
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015
Certified Company.
All registered trademarks, product names mentioned in this
publication are the property of their respective owners and used
for identification purposes only.
iW-RainboW-G33D
Introduction
Quick Start Guide (QSG)
This Quick Start Guide (QSG) is designed for users to quickly
understand the Corazon-AI platform and start the evaluation. It
provides the instructions for setting-up the Corazon-AI from
the packed box.
Corazon-AI Overview
The Corazon-AI is an Off-the-self platform which contains all
necessary interfaces & on-board connectors required for a
complete AI/ML Edge solution. This platform can be used as it
is for wide range of Edge AI solutions.
Key Features
Quick Start Guide
01
g Quad Core A53 + Dual Core R5
g 64 bit, 2GB DDR4 with ECC for PS
g 32 bit, 1GB DDR4 for PL
g 8GB eMMC Flash(Boot & OS Storage)
g 4K Display Port
g SPI x 1, CAN x 2, I2C x 1, GPIO header
g Dual USB3.0 TypeA Port
g M.2 KeyB Connector with SATA & USB 3.0
g AI Engine
g DPU 4096 @330MHz for ~1352 GOPs
g DPU 3136 @330MHz for ~1035 GOPs
g Encode/Decode (H.264/H.265)
g 8x 1080p @ 30fps
g 4x 1080p @ 60fps
This Corazon-AI platform is ESD
sensitive. Handle the product only in
accordance with the installation
instructions given in the manual.
Therefore ESD precautions should be
taken care during transport and
Safety
This Corazon-AI platform is designed
by using RoHS and REACH compliant
components and manufactured on
lead free production process.
Check the local regulations for
disposal of electronic products before
disposing.
ESD Protection
Product Disposal
Environmental Compliance
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
Corazon-AI
02
Must use a ESD ground strap or other
grounded source before unpacking or
handling the hardware.
Quick Start Guide
03
Overview of User Guides
QUICK START GUIDE
QSG
vHandling Corazon-AI platform
vUser Guides reference
vCorazon-AI AI/ML Development flow
RELEASE NOTES
RN
vDeliverables content & its overview
vList of supported interfaces/features
vInfo. of supported Vitis AI version
vKnown issues & its fixes
HARDWARE USER GUIDE
H/W
UG vList of interfaces and its overview
vInterface connection procedure
vIO information for B2B connectors
SOFTWARE BSP USER GUIDE
vPetalinux Compilation
vPetalinux binary programming
vIndividual interface validation
vVitis project creation & compilation
S/W
UG
VITIS AI USER GUIDE
VITIS AI
UG vVitis AI package deployment
vAI/ML demo inference validation
vModel compilation & deployment
vQuantization, Pruning, & Training
vPre/post-processing FPGA acceleration
Quick Start Guide
Step 1 - Unpacking
Remove the Corazon-AI platform from antistatic cover and
place it above the ESD free area. Use anti-static pad/mat with
proper grounding to place the Corazon-AI platform. Don't
touch inside surface of the circuit board.
iW-RainboW-G28D
Quick Start Steps
Avoid using board in extreme dust, humidity and temperature
conditions. Also this Corazon-AI platform is not water proof.
Keep away from wet surface.
Package Box
iW-RainboW-G28D
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
Corazon-AI
04
Make sure that, below deliverables are received without any
physical damage.
Corazon-AI with Heat Sink + FAN
Step 2 - What's Inside The Box ?
Enclosure
Optional Accessories
Debug Cable
12V,5A Power Supply DVD Qui ck St ar t G ui de
Quick Start Guide
R1.0
Corazon-AI
Edge AI solutions
SFP Co nn ec to r
Quick Start Guide
05
iW-RainboW-G28D
Step 3 - Read DVD Contents
Given DVD contains below deliverable folders.
1. Binaries
2. Documents
3. Source Code
Delivery binaries are available in Binaries folder and Source
code files are available in Source Code folder. Also Documents
folder contains Hardware User Guide, Software User Guide,
Software Release Note and Quick Start Guide (this guide).
Before moving to next step, one must go through all the
documents including Hardware User Guides and get familiar
about Corazon-AI platform.
Source code can be customized according to user wish and
corresponding binaries can be generated. Once the binaries
generated, user can download the binaries in to the Corazon-AI
platform using JTAG.
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
Corazon-AI
06
Step 4 - Quick View-Corazon-AI Top View
01. PL DDR4 RAM
02. Zynq US+ MPSoC
03. PS DDR4 RAM
04. JTAG Header
05. Display Port Connector
06. HDMI IN Connector
07. HDMI OUT Connector
08. Debug UART Header
09. Dual USB 3.0 Connector
10. Dual Gigabit Ethernet Jack
11. SFP+ Connector
12. Power IN Jack
13. Power ON/OFF Switch
14. RESET Button
15. FAN Header
16. RTC Battery Header
Quick Start Guide
07
17. Board to Board Connector 1
18. Board to Board Connector 2
19. Board to Board Connector 3
20. eMMC
21. SIM Connector
22. Wi-Fi/BT Module
23. M.2 Key B Connector
Step 5 - Quick View-Corazon-AI Bottom View
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
Corazon-AI
08
