Jabra GN 8110 USB-XP Manuale utente
CD-quality sounD.
Plug-anD-Play installation.
JABRA GN8110
JABRA®IS A REGISTERED TRADEMARK OF GN NETCOM A/S
WWW.JABRA.COM
The GN8110 adapter dramatically improves the quality of
computer-based IP telephony by bypassing your computer’s
sound card and letting you connect directly to a USB port. This
lets you enjoy crisper, cleaner PC sound with your GN Netcom
headset.
-Connects headset to PC-based voice applications
-Eliminates sound-card compatibility problems
-Provides distortion-free CD-quality sound
-Certified for use on Windows®operating systems
-Plug-and-play with no software to install
-Connects to any GN Netcom (QD) headset for PC-based IP-
telephony
The GN8110 bridges the gap between your computer and
headset. Used with Windows®operating systems as well as
Mac operating systems 9.0.4 or greater, the GN8110 provides
distortion-free, CD-quality sound for your computer-based IP
and audio applications.
With the GN8110, there’s no software to install. Simply plug the
GN Netcom headset into the adapter, and plug the adapter into
the computer’s USB port. The result is clean, distortion-free
digital audio without any fuss. The adapter is available in two
variants: with Quick Disconnect (QD) for our corded headsets or
an RJ9 plug for use with our wireless headsets.
DATASHEET
Jabra GN8110 QD
Jabra GN8110 RJ9
JABRA GN8110
Jabra GN8110 QD Jabra GN8110 RJ9
Features BeneFits
Industry-certified No compatibility issues. Officially certified for use with Windows®operating systems. Also
compatible with Mac operating systems 9.0.4 or greater. In short, the GN8110 works with
virtually any computer
Plug & play convenience Absolutely no software to install. The GN8110 is as easy to install as it is to use
Compatible with all USB-capable computers Eliminate noise and sound-card compatibility problems
Available in two variants:
Quick Disconnect (QD)
RJ9 plug
Works with most GN Netcom headsets, both corded and wireless
FEatuREs & BEnEFits
technical speciFications
USB interface Compliant with USB 1.1 General and Audio Class specifications
audio speciFications
Sampling rates 6.4 to 48 kHz
Signal-to-noise -92 dB
Speaker channel frequency response 20-20,000 Hz monaural
General speciFications
Headset cord 0.9-1.8 m (3-6 ft) coiled cord with GN Netcom Quick Disconnect (QD) or RJ9 plug
USB cable 0.6 m (2 ft)
USB cable ABS plastic
Case dimensions 107 mm (4.2”) X 25 mm (1.0”) x 22 mm (.87”)
Weight 70g / 2.5 oz. (cable adaptor only)
Power Supplied by USB port. Current draw: <10 mA power-down mode; approx.100 mA operating
Safety UL 1950, FCC Part 15 Class A/B, CE
