Jackson Dishmachine Stand M24STD-6 Manuale utente

Jackson MSC, INC.

P.O. BOX 1060

HWY. 25E

BARBOURVILLE, KY. 40906

FAX (606) 523-9196

PHONE (606) 523-9795

www.jacksonmsc.com

Installation Instructions

FOR JACKSON MODEL:

M24STD-6

Dishmachine Stand

August 7, 2006

P/N 07610-003-26-13 Rev. A

M24STD-6 INSTALLATION INSTRUCTIONS

Installation Instructions 07610-003-26-13

Issued: 08-10-2006 Revised: N/A

Tools Required:

• Standard Allen wrench set

• Tube of food-grade silicon

• Silicon gun

• Rag

Time Requirements:

It is expected that it will take 30 minutes to

install the M24STD-6 dishmachine stand.

Notes:

• Ensure that the dishmachine stand is

level prior to placing the dishmachine

on the stand.

• Never attempt to lift a dishwasher on

your own. Always use other personnel

to help or the appropriate lifting devices

to prevent accident and injury.

Steps:

• Inspect the assembly to ensure that

there has been no freight damage. If

there is any damage, contact the

freight carrier immediately.

• Your package should contain the fol-

lowing:

• Stand platform weldment

• (4) legs

• Instructions

• If any of these items are missing, im-

mediately contact Jackson Technical

Service at 1-888-800-5672.

• Remove the items from the box.

• Ensure that the set screws are located

within the leg sockets. If they are miss-

ing, immediately contact Jackson

Technical Service (See Figure 1).

• Verify that the foot of each leg can be

turned; this is how the stand will be ad-

justed in order to level it. Please note

that when assembled, there should be

a minimum of 6” (152.4mm) of space

between the bottom of the stand and

the finished floor.

• Place the legs fully into the leg sockets

of the platform and tighten down the

set screws to secure them in place.

(See Figure 2).

• Once all of the legs are tightly in place,

flip the dishmachine stand over and set

it down on all four legs. Ensure that the

legs are stable.

• If stable, take a small amount of silicon

and apply it to the set screw to cover

any exposed threads and to fill in the

hole for the Allen wrench. (See Figure

3). Note: do not use excessive

amounts of silicon; only enough to

complete the task.

Figure 1—Leg socket showing set screw

Figure 2—Tightening the legs

M24STD-6 INSTALLATION INSTRUCTIONS

Installation Instructions 07610-003-26-13

Issued: 08-10-2006 Revised: N/A

•To mount the undercounter dishmachine,

remove the feet from the frame bottom by un-

screwing them.

•Set the unit on top of the stand (minus the

feet) on the platform, lining up the holes in the

frame to the corresponding holes in the plat-

form.

•Secure the unit to the platform by rein-

serting and tightening the feet.

•Verify that the unit is level prior to making

any utility connections. If the unit is not level,

it may operate inefficiently.

After Maintenance Actions:

• Wipe down the stand to remove any

excess silicon.

• Once the dishmachine is fully hooked

up and operational (per the manufac-

turer’s instructions), operate the ma-

chine and observe it to ensure that

there is no excessive vibration or any

other source of concern.

Preventative Maintenance:

• Keep the area under the platform free

of dirt, soil and debris.

• Clean the stand regularly with a wet

towel to prevent the build-up of residue

and soil.

Figure 3—Applying silicon
