Jensen VX4010 Manuale utente

7" Single DIN Multimedia Receiver

VD / Built-in Bluet

ooth / Compatible with iPhone /

Compatible with iPod / Pandor

a Link / USB / Aux In

VX4010

4VRMS

RCA Output

Operating Instructions

VX4010

“Made for iPod” and “Made for iPhone” means that an electronic accessory has

been designed to connect specically to iPod or iPhone, respectively, and has

been certied by the developers to meet Apple performance standards. Apple

is not responsible for the operation of this device or its compliance with safety

or regulatory standards. Please note that the use of this accessory with iPod or

iPhone may aect wireless performance.

Android is a trademark of Google Inc.

The Bluetooth®word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such marks by Audiovox is under license. Other

trademarks and trade names are those of their respective owners.

microSD is a trademark or registered trademark of SD-3C, LLC in the United States,

other countries or both.

Pandora is a registered trademark of Pandora Media, Inc.

VX4010

CONTENTS

FEATURES ...............................................................................................................5

CONTROLS AND INDICATORS ...............................................................................8

REMOTE CONTROL...............................................................................................10

USING THE TFT MONITOR....................................................................................16

EXTERNAL DEVICES .............................................................................................17

QUICK START GUIDE ............................................................................................18

EQUALIZER CONTROL MENU ..............................................................................21

SYSTEM SETTINGS ...............................................................................................23

DISC OPERATION .................................................................................................32

RADIO TUNER OPERATION..................................................................................44

USB AND SDHC OPERATION ...............................................................................49

iPod®/iPhone® OPERATION .................................................................................54

AV-IN OPERATION ................................................................................................59

BLUETOOTH OPERATION.....................................................................................60

REAR CAMERA OPERATION.................................................................................68

STEERING WHEEL CONTROLS (SWC) OPERATION .............................................69

PANDORA RADIO OPERATION............................................................................71

CARE AND MAINTENANCE ..................................................................................79

SPECIFICATIONS ..................................................................................................80

NOTES ...................................................................................................................82

VX4010

FCC Statement

1. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that

may cause undesired operation.

2. Changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance of 20 centimeters between the radiator and your body.

VX4010

Thank you for choosing a Jensen product. We hope you will nd the instructions

in this owner’s manual clear and easy to follow. If you take a few minutes to look

through it, you’ll learn how to use all the features of your new Jensen VX4010

Multimedia Receiver for maximum enjoyment. Please save this manual for future

reference.

We recommend having your Jensen VX4010 Multimedia Receiver installed by a

reputable installation shop.

FEATURES

DVD

• Audio Equalizer

• Next Chapter and Previous Chapter

• Play/Pause

• Track Direct Entry

• Disc Menu

• Selection Repeat / Track Repeat

• Disc Audio

• Disc Language

• Pic Control

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• Directory Search (MP3 / WMA Only)

• Burn up to 1500 MP3 and WMA Files onto a DVD+R / RW

• Audible Forward / Reverse Track Search (CD-DA Only)

• Random, Repeat and Intro

• Play, Pause, Stop, Next Track and Previous Track

AM-FM

• USA, China, Japan, Europe, Europe (LW) and Orient (OIRT)

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono

• Local / Distance

• Auto Store / Preview Scan

iPod®/iPhone®

• iPod®/ iPhone® via USB

• High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums

and Songs. Play music and view video/photo* les from your iPod®. *Video/photo

playback requires jLink-USB iPod® interface cable (sold separately).

• Power Management Charges iPod® while Connected

VX4010

Chassis

• 1.0 DIN (Import / ISO-DIN Mountable)

• Motorized Flip-Out / Flip-Up TFT Screen

• 7” High Denition TFT LCD

• 1,152,000 Sub Pixels (800 x 3 X 480)

• Beep Tone Conrmation (ON-OFF Option)

General

• Built-In Bluetooth® providing Hands-Free operation for safety and convenience

and A2DP for streaming music from your smartphone or other Bluetooth®

device.

• One Composite Video Output for Additional Screens

• Front Panel Audio/Video Input

• Ten-Band Tone Equalizer

• Rear Subwoofer Line Output

• Rear Camera Input

• Touch Screen Calibration Mode

• Rotary Encoder Audio Control

Rear Camera

The VX4010 is “camera ready.” Before accessing any camera features, you must

purchase and install a rear video camera.

VX4010

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

WARNING! To reduce the risk of a trac accident (except when using for rear

view video camera) never use the video display function while driving the vehicle.

This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or re, never expose this unit to moisture

or water.

WARNING! Never use irregular discs.

WARNING! To prevent damage to the mechanism inside this unit, avoid impact to

the unit’s monitor.

WARNING! Using an improper fuse may cause damage to the unit and result in

re.

VX4010

CONTROLS AND INDICATORS

OPEN

VX4010 Controls and Indicators

1. LCD Screen and Touch Screen:

Touch icons on this screen to access menus or control functions.

2. Eject ( ) Button:

Press this button to eject a DVD/CD/MP3 disc. Disc play is stopped, the disc is

ejected and the unit will change to radio operation. If the disc is not removed

from the unit and the button is pressed again, the disc will be re-loaded. If the

disc is not removed from the disc slot within 10 seconds of being ejected, it

will be automatically reloaded to prevent it from being accidentally damaged.

VX4010

3. Display (DISP) Button:

Touch to adjust the screen brightness.

Touch and hold to turn the screen o.

When the TFT is closed, press once and repeat to cycle through clock time,

metadata, RDS information, etc. The type of information displayed depends

upon the selected source

AV IN Connector:

This connector accepts a 3.5 mm jack through which signals from various

audio/video devices can be applied to the unit.

5. Open Button:

Press to open/close the TFT/LCD screen.

6. Reset Button:

Press this button to reset the system settings (except password and parental

lock settings) and to correct a system halt or other illegal operation. Use the

tip of a pen to press the Reset button.

Micro SD card slot:

Used to insert microSD cards containing music/video les (MP3, AAC, MPEG,

etc.)

8. USB slot:

Used to connect an iPod®, MP3 player or ash drive connection adapter for

playback of music/video les.

Interface Cover:

Covers the Micro SD card slot, USB slot and Reset button.

10.

Remote Sensor:

Used to receive command signals from the remote control.

11.

Previous ( ) / Next ( ) Buttons:

Press the Previous ( ) button to play the previous track on a disc.

Press the Next ( ) button to play the next track on a disc.

12. Rotary Volume ( ) Knob / Mute Button

Rotate the knob to adjust the volume from 0 to 50.

Press the knob momentarily to mute the audio. Press the knob again to

restore the audio.

13. SRC / Power On/O ( ) Button

Press to turn the unit ON.

When on, press to switch the playing source.

Press and hold to turn the unit o.

14. Disc Slot:

Accepts DVD/CD/MP3 discs. If the unit is turned on, playback begins when a

disc is inserted.

VX4010

REMOTE CONTROL

Remote Control Notes

1. Aim the remote control at the remote sensor on the unit.

Remove the battery or insert a battery insulator if the remote control will not

be used for a month or longer.

3. Do not store the remote control in direct sunlight or in a high temperature

environment. It may not function properly.

4. Under normal operation conditions, battery life is approximately 6 months. If

the remote control does not work, replace the battery.

5. Use button-shaped CR2025 lithium batteries only.

6. Do not recharge or disassemble the battery.

7. Do not heat the battery or expose the battery to re.

8. To avoid risk of accident, store the battery in a place that children can not

reach.

Battery Installation/Removal

1. Slide out the battery compartment cover located on the bottom of the back

of the remote control.

Insert a CR2025 lithium battery into the battery tray. Make sure that the

proper polarity (+ or -) is observed.

3. Align the cover tabs with the remote control and slide the cover in until it

locks.

Slide Out

Slide In

Battery Compartment Cover Removal/Installation

Altri manuali per VX4010

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Jensen Ricevitore per auto

Jensen

Jensen MP7610 Manuale utente

Jensen

Jensen DV2007 Manuale utente

Jensen

Jensen AWM968 Manuale utente

Jensen

Jensen CR1610 Manuale utente

Jensen

Jensen Phase Linear UV10 Manuale utente

Jensen

Jensen Heavy Duty JHD3620 Manuale utente

Jensen

Jensen JCR311 Istruzioni operative

Jensen

Jensen CD315X Manuale di istruzioni

Jensen

Jensen BT1613 Manuale utente

Jensen

Jensen JCV2015BT Manuale utente

Jensen

Jensen JHD1000 Manuale utente

Jensen

Jensen VM9213 - Touch Screen MultiMedia Receiver Manuale utente

Jensen

Jensen CVS0336 Manuale utente

Jensen

Jensen VM9512 - Motorized Touch-Screen Multimedia... Manuale utente

Jensen

Jensen VX7024 Manuale utente

Jensen

Jensen VX3010 Manuale utente

Jensen

Jensen HD5112 Manuale utente

Jensen

Jensen MCD 5110 Manuale utente

Jensen

Jensen MS4200RS - Navigation System With CD Player Manuale

Jensen

Jensen VM9224 Manuale utente

Jensen

Jensen JDV8035 Manuale utente

Jensen

Jensen AWM975 Manuale utente

Jensen

Jensen VM9213 - Touch Screen MultiMedia Receiver Manuale utente

Jensen

Jensen MP6612i Manuale utente

Manuali Ricevitore per auto popolari di altre marche

Motorola

Motorola VWA63 Manuale utente

Nextar

Nextar D3201 Manuale utente

Alpine

Alpine CDE-163BT Manuale utente

Pioneer

Pioneer DEH-P645R Manuale utente

Axxera

Axxera XDMA7600 Istruzioni operative

XM OnyX Manuale utente

Sound Storm

Sound Storm STM93R Manuale utente

Soundstream

Soundstream VIR-5000 Manuale utente

Avson

Avson MKT Platform Manuale utente

Sony

Sony MEX-1HD - Audio Library System Manuale utente

Pioneer

Pioneer DVH-P500UB Manuale utente

JVC

JVC KD-AHD69 Manuale utente

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuale utente

Sony

Sony CDX-4160 - Cd Receiver Manuale utente

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuale utente

VDO

VDO CD 2253 Manuale utente

Volvo

Volvo 13 84 580 Manuale utente

ZENEC

ZENEC ZE-160DVD Manuale utente
