5"x6" Horizontal Swivelhead Bandsaw
The new JET® HBS-56S is the ideal saw
for machine, maintenance, and fabricating
shops where space is limited. Powered
by a full 1/2 horsepower UL motor, rated
at 1720 RPM and three blade speeds;
80, 120, 200 SFPM allow for cutting of
metal, plastic and wood. Equipped with
a variable hydraulic feed system that
delivers a smooth consistent feed
resulting in longer blade life. Mounted
on wheels, this saw has great mobility
in the shop.
jettools.com
5"x6" HORIZONTAL SWIVELHEAD BANDSAW
5"x6" HORIZONTAL SWIVELHEAD BANDSAW
■ Head swivels for a maximum cut at 45 & 60°
■ Hydraulic down feed control
■ Quick action vise
■ Deluxe enclosed stand with handle and wheels
for easy movement
■ Ball bearing drive wheel and blade guides
■ Sealed worm gear transmission
■ UL listed motor
OPTIONAL ACCESSORIES
STOCK NO. 900853
10M 09/05
©2005 WMH TOOL GROUP, Inc. All Rights Reserved.
Replacement Blade
64-1/2" x 1/2" x .025" x 14R-C
414301
Replacement Blade
64-1/2" x 1/2" x .025" x 10R-C
414302
STOCK NUMBER 414457
Model HBS-56S
Round Capacity at 90° (in.) 5
Round Capacity at 45° (in.) 2-3/4
Round Capacity at 60° (in.) 1-3/4
Rectangle Capacity at 90° (in./W x H) 5 x 6
Rectangle Capacity at 45° (in./W x H) 2-3/4 x 4
Rectangle Capacity at 60° (in./W x H) 2-3/16 x 1-3/4
Blade Size (in.) 1/2 x .025 x 64-1/2
Blade Wheel Diameter (in.) 7-1/2
Blade Speeds (SFPM) 80, 120, 200
Bed Height (in.) 29-3/4
Motor 1/2HP UL listed, 115/230V,
1Ph, Prewired 115V
Floor Space Required (in.) 42 x 18
Net Weight (lbs.) 172
