JPW (Tool) AG

Tämperlistrasse 5

CH-8117 Fällanden

Switzerland

Phone +41 (0) 44 806 47 48

Fax +41 (0) 44 806 47 58

www.jettools.com

M-500006101T 2017-10

JCOM-400T

CHOP-OFF SAW

GB

Operating Instructions

CE‐Conformity Declaration

CE‐Konformitätserklärung

Déclaration de Conformité CE

Product / Produkt / Produit:

Chop-off saw

JCOM-400T

Brand / Marke / Marque:

JET

Manufacturer / Hersteller / Fabricant:

JPW (Tool) AG, Tämperlistrasse 5, CH‐8117 Fällanden

Schweiz / Suisse / Switzerland

We hereby declare that this product complies with the regulations

Wir erklären hiermit, dass dieses Produkt der folgenden Richtlinie entspricht

Par la présente, nous déclarons que ce produit correspond aux directives suivantes

2006/42/EC

Machinery Directive

Maschinenrichtlinie

Directive Machines

2014/30/EU

electromagnetic compatibility

elektromagnetische Verträglichkeit

compatibilité électromagnétique

designed in consideration of the standards

und entsprechend folgender zusätzlicher Normen entwickelt wurde

et été développé dans le respect des normes complémentaires suivantes

EN ISO 12100:2010

EN 60204-1:2006+A1:2009+AC:2010,

EN 61000-6-4:2007+A1:2011, EN 61000-6-2:2005,

EN 60204-1:2006/AC:2010,

EN 13898:2003+A1:2009/AC:2010,

EN 61000-3-2:2014, EN 61000-3-3:2013

Responsible for the Documentation / Dokumentations‐Verantwortung / Résponsabilité de

Documentation:

Hansjörg Meier

Head Product‐Mgmt. / Leiter Produkt‐Mgmt. / Resp. Gestion des Produits

JPW (Tool) AG

2016‐05‐24 Alain Schmid, General Manager

JPW (Tool) AG, Tämperlistrasse 5, CH‐8117 Fällanden

Schweiz / Suisse / Switzerland

Project

unit

type

kW

3

400

Hz

50

2810

3380

70/S

58

40

125

9. Assembly Breakdown

10. Parts List for Breakdown

Index No.

Part No. Description Size Qty.

1 JCOM400T-001 Base 1

2 JCOM400T-002 hand wheel 1

3 TS-1523031 Socket set screw M6×10 1

4 JCOM400T-004

Screw fixing seat 1

5 JCOM400T-005 Flat washer 10 10

6 TS-1491041 Hexagon bolt M10×30 6

7 JCOM400T-007 Screw 1

8 JCOM400T-008 Vol 4×12 1

9 JCOM400T-009 Clamping plate 1

10 JCOM400T-010 Plate pin 1

11 JCOM400T-011 External circlip 18 1

12 JCOM400T-012 Angle device 1

13 TS-1491031 Hexagon bolt M10×25 5

14 JCOM400T-014

Enlarged flat washer 10 2

15 JCOM400T-015 Row pin cover 1

16 JCOM400T-016 Conneting base 1

17 JCOM400T-017 Lintel shaft 1

18 JCOM400T-018 Torsional spring 1

19 TS-155010 Flat washer 16 1

20 JCOM400T-020 Self-locking nut M16 1

21 JCOM400T-021 Flat washer 6 12

22 TS-1503031 Socket head cap screw 14

23 JCOM400T-023 Cover plate 1

24 TS-1491021 Hexagon bolt M10×20 1

25 JCOM400T-025 External clamping plate 1

26 JCOM400T-026 Cutting disk 400×32×3.2 1

27 JCOM400T-027 Internal clamping plate 1

28 TS-1490061 Hexagon bolt M8×35 1

29 TS-1550061 Flat washer 8 4

30 JCOM400T-030 Grinding wheel cover 1

31 BB-6205 Bearing 6205 2

32 JCOM400T-032 Spindle 1

33 JCOM400T-033 Bracket 1

34 TS-1540041 Nuts M6 2

35 TS-1490011 Hexagon bolt M8×12 2

36 TS-1540061 Nuts M8 1

37 JCOM400T-037 Internal belt cover 1

38 JCOM400T-038 Hexagon bolt 1

39 JCOM400T-039 Flat key 6×6×20 1

40 JCOM400T-040 Blet cover 1

Parts List for Breakdown

Index No.

Part No. Description Size Qty.

41 JCOM400T-041 Enlarged flat washer 6 4

42 JCOM400T-042 Cap nut M6 2

43 JCOM400T-043 Washer 2

44 JCOM400T-044 Flat key 8×7×30 1

45 JCOM400T-045 Motor pulley 1

46 JCOM400T-046 Shield support 1

47 JCOM400T-047 Motor 3kW,400V,50Hz 1

48 JCOM400T-048 Switch box 1

49 JCOM400T-049 Shield fixing sleeve 1

50 JCOM400T-050 Cross head screw M5×10 4

51 JCOM400T-051 Relay DZ07 1

52 JCOM400T-052 Cross head self-tapping screw M4.2×9.5 2

53 JCOM400T-053 Switch cover 1

54 JCOM400T-054 Button start-stop switch LA38/203 1

55 JCOM400T-055 Emergency switch LAY5 1

56 JCOM400T-056 Cross head self-tapping screw M4×16 3

57 JCOM400T-057 Trigger switch HY15EC 1

58 JCOM400T-058 Handle lower cover 1

59 JCOM400T-059 Handle upper cover 1

60 JCOM400T-060 Handle lever 1

61 TS-1540071 Nuts M10 4

62 JCOM400T-062 V-Belt A876 2

63 JCOM400T-063 Cross head self-tapping screw M4×9.5 1

64 JCOM400T-064 Male line 1

65 JCOM400T-065 Bus bar 1

66 JCOM400T-066 Crank 1
