1 - Introduction
Congratulations!Youhave justpurchased anexcellent grainchopper JF2D, easyto operate
andmaintain.
Besidesgrainchopper,thismachinecanbeconfiguredtoworkasforagechopper.
We thank you for choice of a machine really suitable to your needs, which is made by a
companythatcontinuouslysearchesfortheimprovementofitsproducts.
This Manual supplies the instructions for correct operation, preventive maintenance and
informationonhowtocontacttheTechnicalServiceifnecessary.Beforeoperatethemachine
forthefirsttime,readthesafetyinstructionsandallotherinstructionsinthismanual.
In case of any doubt, please contact with any of ourAuthorized Dealers or with our Post Sale
Department;Wearegoingtobeverygladinhelpingyouonwhateveryouneed.
PostSaleDepartment
Phone ..................................................................................................... (0xx19) 3863-9658
(0xx19) 3863-9642
e-mail ...................................................................................... [email protected]
Website ............................................................................................... www.jfmaquinas.com
The images displayed in this manual are only for illustrative purposes. Thus to facilitate your
viewing, the images show cutaway or the safety shielding removed for displaying it more
clearly. Do not operate the machine under any circumstances without these respective
protectiveshields.
3
English
Content
4
1-Introduction 03
2-Safetyrecommendations 06
2.1-Whenreadingthemanual 06
2.2-Whenoperatingthemachine 07
2.3-Whenmakingmaintenanceinthemachine 07
2.4-Transportontruck 07
3-Machinepresentation 08
3.1-Partsidentification 08
3.2-Operation 09
3.3-Technicalspecifications 10
4-Machinesetup 11
4.1-Machinelevelingandpositioning 11
4.2-Electricfitting:Machinewithmotor 12
4.3-Motorinstallation 13
4.4-Assemblyofthedetachedparts 14
5-Operationadjustments 16
5.1-TooperatetheJF2Dasgrainchopper 16
5.2-TooperatetheJF2Dasforagechopper 18
5.3-Machineworkspeedadjustment 19
6-Stepbystepoperation 20
6.1-Startingthemachineon/off 20
6.2-Operatingthemachineingrainchoppermode 20
6.3-Operatingthemachineinforagechoppermode 21
7-Maintenanceinstructions 22
7.1-Greaselubricatingpoints 22
7.2-Chopperknivessharpening 23
7.3-Gapadjustmentsbetweenknifeandcounterknife 24
7.4-Counterknifereplacement 25
7.5-Changeofgrinderhammers 26
7.6-Pulleyalignment 28
7.7-Belttensionadjustmentandreplacement 29
7.8-Machineconservation 30
8-Stickersfoundonthehead 30
9-Detacheditemsthatcomealongwiththemachine 31
5
Note:
1- JFMáquinasAgrícolasLtdaaimsitsproductstobeconstantly
getting upgraded and improved in addition to having its own right to introduce
changesinitscomponentsandaccessorieswithoutpriornotice.
2- IllustrationsinthisManualaremerelyillustrative.
3- JF offers one free operation training at the factory. Contact JF Training
Department and ask for further information or go to the website
www.jfmaquinas.comandgetaccesstothecourseschedule.
10-Troubleshooting 32
11-Technicalassistance 33
11.1-Machineserialnumber 33
11.2-Warrantyterm 35
11.3-Technicaldeliveryreceipt 37
OPERATION TECHNICAL MANUAL - MILL JF 2D
English
6
2- Safety Recommendations
2.1- While Reading the Manual
Warning Labels
Seating and Torques
Protectors, Closures and Fairings
ObservetherecommendationsofyourTractor'sManual,forasafeandefficientoperation.
Obs.: You must obey and never discard these labels. In case of repainting, you ought to
replacethemwithoriginalitemsasstatedinItem8.
Note:
Itmeansthatadetailwillbepresentedanditmayconcernsoperationorsecurity.
Note:
The machine features several labels containing warnings and/or technical
guidancethatconcernsecurity.
Note:
When seating the screws presented in this manual, use torques and keys present
inthetableofItem12-AdditionalInformation.
Attention:
It means that your life or parts of your body may be in danger. You must pay
attentiontothissign!
Attention:
You must never operate the Harvester without Protectors, Closures and
Fairings.
7
1-Machinemustbeturnedoffforanytypeofmaintenance.
2-Observethespecificationandamountoflubricanttobeusedonthemachine.
Whenever you have to transport the machine for longer distances, when there is need for
usingpublicroads,thetransportmustbedoneontruckortrailer.
Tomoresafety,themachinemustbefixedwithropeonthetruck.
2.3- When making maintenance in the machine
2.4- Transport on truck
1- The JF 2D is designed exclusively to disintegrate
grainsandchopforage.
2-Whensupplythemachine,neverintroducethehands
intothefeedingchute(1).
3-In order toobtain themaximum efficiencyandquality
of chopped or designed material, maintain a constant
anduniformfeeding.
4- To more security fasten the machine on a even and
rigidsurface.
5- Never use the machine to chop tree branches or
anotherrigidmaterial.
6- Never attempt to adjust or repair components with
themachinerunning.
7- Do not leave the machine in a place that can be
operatedbychildrenornotqualifypeople.
2.2- When operating the machine
1
8- The cover belt is not included with the machine when it leaves the factory without a motor
coupled, but its use is MANDATORY as safety NR12 (Item 12.38. Danger areas of the
machineries and equipments must have safety systems, characterized by fixed covers,
mobile covers and safety devices interconnected to ensure health protection and physical
integrityofworkers)andNR31(Item31.12.12 theruralemployerorsimilarareresponsibleto
maintain the security systems in perfect condition and operation, which the total or partial
withdrawal or neutralization of these systems which endanger the physical integrity of
workersconsideredseriousandimminentrisk).
1
OPERATION TECHNICAL MANUAL - MILL JF 2D
English
8
3- Machine presentation
3.1- Parts identification
1-Grainchopper
2-Feedingnozzle
3-Protectionscreen
4-Upperproductoutput
5-Deflector
6-Counteknife
7- Inferior product outlet (desintegrated
grains)
8- Driving electric motors (Refer to page 10
aboutpowerrequirements)
9- On-Off control (machine equipped with
originalelectricmotoronly)
10-Foragechopperknifes(2units)
11-Grinderhammers(6units)
12-Machinebase
1
6
9
4
5
12
2
8
7
311
10
9
3.2- Operation
Sieves kit that come along with the machine
(see sieve chart on page 17)
The JF 2D Mill machine is a simple, strong and
versatible machine, designed to help you on diary
animalfeed.
Themachineofferstwooperationtypes:
A-Cerealsmill:corn,sorghum,soybeanetc.
Forthisfunction,usethegrainchopper(1),loweroutlet
(2) and one of 4 sieves (3). The cereals milling is
performedbyhammers(4),thatrotateonhighspeed.
B- Plants chopper for forage such as corn, grass
(elephantgrass,napier)andsugarcane.
For this usage, to use the feeding nozzle (5), upper
outlet (6) and sealing rubber (7). The gring action
occursbytheknives(8)andcounterknife(9).
1
5
9
7
36
2
8
4
OPERATION TECHNICAL MANUAL - MILL JF 2D
English
10
3.3- Technical specifications
Model: JF 2D Mill Machine
Drive Electricmotor
Powerofthemotor 2to3hp(1,5to2,5kW)
Workspeed 4.000to5.000RPM
Cuttingknives 2units
Grinder hammers 16 units
Driving belt A46
Pulley* diameter which follow the machine:
- To 60 Hz motor (03.100100) 105 mm (2 groves)
- To 50 Hz motor (03.100198) 138 mm (2 groves)
*Onlyapulleyformotoraccompaniesthemachine(50or60Hz)setatthetimeofpurchaseof
themachine.
Impellerpulleydiameter 90mm
Approximatedweight 68Kg
Note: The motor, depending on the power, can weight up 32 Kg.
Dimensions (see picture below)
A(height) 1.337mm
C(lenght) 654 mm
L(width) 648mm
Front view RH side
L
A
C
