Jobsite V-12/AW Manuale utente
12-STEP ALL WEATHER WALL MOUNT VOLUME CONTROL
For Precise Volume
Adjustment in All
Weather Conditions
INSTALLATION & USER GUIDE
V-12/AW
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page a
V-12/AW
12-STEP ALL WEATHER WALL MOUNT VOLUME CONTROL
TABLE OF CONTENTS
Features............................................................................................................................1
Product Overview...........................................................................................................2
Package Contents ..........................................................................................................3
Preparing for Installation..............................................................................................3
Installation.......................................................................................................................4
Operation..........................................................................................................................6
Specifications.................................................................................................................7
Warranty...........................................................................................................................8
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page b
1
FEATURES
IIncludes standard faceplate
IIncludes weather resistant gasket and stainless steel hardware
ISafely connect up to eight speaker pairs to a single amplifier or receiver
IUL listed to comply with local building codes
IStylish indicator knob
I12-step make before break volume control switch design
Installation friendly design:
IAccepts up to 14-gauge wire
ISnap and lock connector secures wire in place without the use of a screwdriver
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 1
PRODUCT OVERVIEW
2
V-12/AW
Figure 1
(a) Knob
(b) Faceplate
(c) Gasket
(d) Volume Control
b
c
d
a
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 2
3
PACKAGE CONTENTS
IV-12/AW volume control x 1
IStandard wall plate x 1
IKnob x 1
IDevice mounting screws x 2
IFaceplate screws x 2
ISnap and lock removable speaker connectors x 2
IGasket x 1
PREPARING FOR INSTALLATION
If you are installing the V-12/AW into an existing wall,
take time to consider any possible obstructions which
may be hidden inside the wall, such as wood or metal
studs, electrical, telephone or other types of wiring,
plumbing, AC or heating conduit. Count the number of
pairs of 4 ohm speakers and the number of pairs of
8 ohm speakers you are connecting. Count pairs of
6 ohm speakers as 4 ohm pairs. Determine the
correct switch position from the impedance charts
below. See figures 2, 3 and 4.
Figure 2 Figure 3 Figure 4
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 3
4
Using Speaker Selectors with IM
Volume Controls
Although IM controls provide volume and on/off at
the volume-control location, they do not give you
central control of speakers playing throughout the
house. Speaker-selection systems give you central
control, but some speaker selectors have non-
defeatable impedance-protection circuits. Combining
IM controls with such a selector will reduce your
maximum volume substantially. To solve this problem,
specify a speaker selector with a defeatable
protection circuit (JobSite models S-4 or S-6). Then
keep the protection circuit off at all times.
Tools Required
I1/8" Slotted screwdriver
I1/4" Slotted screwdriver
INo2 Phillips screwdriver
IWire stripper
IWire labels
INSTALLATION
1. Identify the Speaker wire and Amplifier wire. Label
the wires for future reference.
2. Strip 1/4" of insulation from the end of each wire.
Tightly twist the end of each wire until no frayed
ends remain.
3. Locate the snap and lock
connectors and remove
them if they are plugged
in. See figures 5.
4. Use a small flathead
screwdriver or your
thumb to raise the
locking tabs, exposing the holes on the connector.
5. Insert wire into the appropriate hole and snap
down the locking tabs.
Figure 5
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 4
6. Insert the smooth side of the connector plug into
the smooth side of the V-12/AW socket.
7. Install the V-12/AW into the device ring.
8. Set the Impedance Magnification Switch as
determined by the impedance charts.
9. Set the switches, on all of the controls, to the
same position (1x, 2x, 4x, or 8x).
10. Attach the cover plate.
See installation diagram.
INSTALLATION DIAGRAM
Speakers
Stereo Receiver
V-12/AW
Side View
Output to
Speakers
Input From
Amplifier
5
V-12/AW
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 5
6
OPERATION
1. Make sure the amplifier or receiver power is OFF
and set the volume to minimum.
2. Set the volume on the volume control to maximum
(fully clockwise).
3. If you are using a JobSite speaker-selection
system, locate the on/off button that corresponds
to the speaker pair you wish to play. Set it to the
ON position. Make sure the defeatable protection
circuit is not enabled. See Using Speaker
Selectors with IM Volume Controls, on page 4.
4. Turn ON the amplifier or receiver and select a
source, such as the Tuner or CD player.
5. Slowly turn up the amplifier or receiver volume and
set it to a comfortable – not maximum – listening
level. Don’t overdrive or "clip" your amplifier. If the
sound becomes muddy or distorted, you have
reached the limit of your amplifier’s volume
capability. Reduce the volume at once to avoid
damaging your speakers.
6. Use the volume control to adjust the volume of the
speakers to the desired listening level. If all the
speaker pairs in your system are equipped with
JobSite volume controls, you can set the amplifier
or receiver volume at one position and use the
JobSite controls exclusively.
7. To turn OFF the speakers, turn the knob on the
volume control fully counter-clockwise, or press
the ON/OFF button on your speaker selector.
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 6
7
SPECIFICATIONS
High power rating:
100 watts per channel RMS, 200 watts peak
Adjustable impedance:
1x, 2x, 4x, 8x settings
Total attenuation:
54dB maximum
Wiring requirements:
2 individual runs of 2-conductor 14-18-gauge
speaker wire or 1 run of 4 conductor.
V-T8 volume control connection terminal
recommended
Mounting:
Fits most single gang junction boxes, weather
resistant gasket included
Dimensions:
1-5/8" wide x 2-5/8" high x 2-9/16" deep
Depth behind faceplate:
2-9/16"
Warranty: 10 year limited
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 7
8
LIMITED WARRANTY
JobSite Systems (“JOBSITE”), a Niles Audio
Corporation company, warrants its passive products
(those not requiring AC or battery power) to the
original purchaser to be free of manufacturing
defects in material and workmanship for a period of
ten years from date of purchase.
JOBSITE warrants its passive loudspeaker products
(those not requiring AC or battery power) to the
original purchaser to be free of manufacturing
defects in material and workmanship for a period of
five years from date of purchase.
JOBSITE warrants its indoor/outdoor loudspeaker
products to the original purchaser to be free of
manufacturing defects in material and workmanship
for a period of two years from date of purchase.
JOBSITE warrants its all weather rock loudspeaker
products to the original purchaser to be free of
manufacturing defects in material and workmanship
for a period of five years from date of purchase.
JOBSITE warrants its active products (those
requiring AC or battery power) to the original
purchaser to be free of manufacturing defects in
material and workmanship for a period of two years
from date of purchase.
This Warranty is subject to the following additional
conditions and limitations. The Warranty is void and
inapplicable if JOBSITE deems that the product has
been used or handled other than in accordance
with the instructions provided by the manufacturer,
including, but not limited to, damage caused by
accident, mishandling, improper installation, abuse,
negligence, or normal wear and tear, or any defect
caused by repair to the product other than by
JOBSITE or an authorized JOBSITE wholesale
distributor.
To obtain warranty service, you must write to
DS00406BCN_V12AW.qxp 2/17/05 4:00 PM Page 8
