Initial Setting of App
Installation of App
Go to Google Play or the Apple Store (depending on your smartphone) and download the “airCloud Home” Application.
䈜Please read and agree to “the Terms of Use” on the App.
䈜The App is free. Communication charges will be incurred for download and operation as per the local cell phone provider.
䈜Android is a trademark and registered by Google LLC.䚷䈜 iPhone is a trademark and registered by Apple Inc.
䈜QR code is a trademark and registered by DENSO WAVE Inc.
Groove
䐟Adapter
Manufacturer: Johnson Controls-Hitachi Air Conditioning Wuhu Co., Ltd. No.2 Qiluoshan Road, Wuhu City, Anhui Province 241009, China
䐠Fixing clip
Right side lower cover㻌
of indoor unit
Flat surface area
Note:
• If communication cannot succeed within 2 minute, please follow the instructions of the App to complete the pairing process again.
• If a user in the group has already registered some air conditioning units, the other users in the same group can also control the unit.
• The above is the process for using the AP method to add air conditioner. Please follow the guide on the App if you choose to use WPS method on
step(3).
(1) Click “Create Account”.
(2) Enter your name and click “Continue”.
(3) Enter your phone number and password (or click “E-mail” tab, and
enter your E-mail address and password), read the “terms and
condition” and check on the box, click “Continue".
(4) Enter received verification code you received and click “Continue”.
(5) Click “Auto-Detect My Location” or Enter address details manually,
and click “Finish”.
(6) The account has been created successfully.
Registration on AppFor installation on the outside of the indoor unit
Make sure that the Adapter is properly installed and the air conditioner is plugged in, then follow the steps below to add your air conditioner device
to the App.
(1) Click “Add Air Conditioner” on the top screen after registration and
login your App.
(2) Scan QR code on the bundled SSID&KEY label.
(3) Select “Connect using AP method”.
(4) If the SSID shown on the App is your home router, enter your home
router password, click “Next”. Otherwise, click “Change Wireless
Network”, select your home router enter password and click “Next”.
(5) Press and hold the MODE button for 3 to 7 seconds until Link LED
ÀDVKHV7KH/LQN/('NHHSVÀDVKLQJWLOOFRPPXQLFDWLRQZLWK
the Wi-Fi router is succeeded.
(6) Click “Change Wireless Network”, select the Wi-Fi access point of
the Adapter with SSID printed on the bundled SSID&KEY Label,
input password (the KEY). Click right arrow icon on the screen top
to continue for connecting your smart phone with the Adapter.
(7) Waiting for the Adapter to connect to your home router. When
communication is established, Link LED 1 turns on, Link LED 2
turns off.
(8) Waiting for the Smartphone to connect with your home network. If
your Smartphone is connected to another wireless network then
click on Change Wireless Network & select home network.
(9) Your air conditioner has been successfully configured.
(1) While the power light turns on, keep pressing MODE button
about 15 seconds, until the LED flashes. (After 5 seconds it
will start to flash, but please keep pressing for 15 seconds.)
(2) Make sure all LEDs flash 4 times repeatedly.
(3) Only the power LED turns on after restoring factory setting succeed.
Air Conditioner Registration and Router Connection
Reset the internal settings (restore the factory settings) by pressing and holding MODE button for 15 seconds. Please note that the configuration will
be cleared and new pairing procedure will be required to use the Adapter. Please restore factory setting when discarding this Adapter.
Restore Factory Setting
Note : The first registered user can manage all the users and set access rights as a group owner. Group owner can invite others to register.
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Power LED onLink LED 1 on Power LED on
Link LEDs flash Power LED onLink LED 1 on
(1) (2) (3) (4) (5) (6)
䐠Fixing clip
Hole side
Non-hole side
(1) Please reserve more than 40mm space in the lower part of the indoor
unit as shown on figure (e).
(2) Remove the front cover of the air conditioning unit and the cover of
the electric box. Refer to the air conditioner installation manual for
instructions on removing the front cover and to open the electric box.
(3) The connection to the electronic board should be made as shown in
figure (c), following the same procedure as for installing inside.
(4) Close the cover of the electric box, taking care not to trap the cable.
Close the front cover of the air conditioning unit. Refer to the air
conditioner installation manual for instructions on closing the electric
box and closing the front cover.
(5) Wire the adapter cord outside the indoor unit. Please pull the
connecting cord from the connecting cord outlet as shown on
figure(f), figure(g) and figure(h).
(6) Insert the hole side of the 䐠fixing clip into the groove of 䐟Adapter.
(7) Insert 䐠fixing clip and clamp to the right side lower cover of indoor
unit.
(8) Please confirm the air conditioner installation manual on how to
install the lower cover of indoor unit.
Please reserve more than 40mm space
in the lower part of the indoor unit.
Figure (e)
Power cord
Connecting cord
Figure (h)Figure (f)
Right side lower cover
of indoor unit
MODE POWER
Status Indicator (LED Indicator may light up while the air conditioner is turned off)
Note : Please try to power OFF/ON your air conditioner from power cord when an error occurs.
There will be a slight discrepancy between the LED indicator on the Wi-Fi Adapter and the Wi-Fi Lamp on the indoor unit.
• Adapter and the air conditioner are not
connected or the air conditioner is not
plugged in.
Indoor unit Wi-Fi Lamp: LED OFF
• Power is on.
• The connection with the Wi-Fi router has not
been established.
Indoor unit Wi-Fi Lamp: LED OFF
• Waiting to connect to the Wi-Fi router using
AP mode.
Indoor unit Wi-Fi Lamp: LED blinks 3 times
airCloud Home Adapter Indications
Corresponding Status
Power LED on
Power LED on
Link LED 2 flashes
Power LED on
Link LED 1 flashes
All LEDs are off.
• Waiting to connect the Wi-Fi router using
WPS mode.
Indoor unit Wi-Fi Lamp: LED blinks 2 times
Power LED on
Link LED 1 on
Power LED flash
• The connection between the Adapter and
the router is completed.
• The operation can be conducted through
smartphone.
Indoor unit Wi-Fi Lamp: LED ON
• Restoring factory setting procedure has
started.
Indoor unit Wi-Fi Lamp: LED blinks 4 times
• Power LED flashing 5 times: Air Conditioner
communication error.
Indoor unit Wi-Fi Lamp: LED blinks 5 times
• Power LED flashing with 4sec ON/1sec OFF:
Router connection error.
Indoor unit Wi-Fi Lamp: LED blinks with
4sec ON/1sec OFF
• Power LED flashing with 4sec ON/3sec OFF:
Cloud connection error.
Indoor unit Wi-Fi Lamp: LED blinks with
4sec ON/3sec OFF
airCloud Home Adapter Indications
Corresponding Status
Power LED on
Link LEDs flash
All LEDs flash 4 times
repeatedly.
airCloud Home Adapter Indications
Indoor unit Indications
Wi-Fi Lamp
(Blue)
