Technical Bulletin EDA-2040

Issue Date 0196

Part No. 34-619-18, Rev. E

Code No. LIT-121342

nstallation

The actuator is not position sensitive and can be

mounted in any convenient orientation. Wiring

terminals must be accessible and protected from

moisture and corrosive fumes. No extra mounting

brackets, linkage, or couplers are required for

standard mounting.

Note: The standard length shaft coupler must be

used when the EDA-2040 or ATP-2040 is

used with an EDA-2040-102 Switch Kit.

it Includes

●actuator

●No. 10 thread cutting tapping screw

●position scale

●position indicator

●CBL-2000 Wiring Harness (six female quick

connects with attached cables) for ATP-2040

Note: The CBL-2000 can also be ordered

separately.

ools Required

●screwdrivers, flat-blade (or nut driver) 5/16 in.

and No. 2 Phillips

●Allen wrench (90 degree hex key), 1/8 and

9/64 in. short series

●pliers

●drill, 5/32 in. (4 mm) drill bit

●screwdriver, No. 2 Phillips

●continuity tester (visual, audio, or DVM)

CAUTION: Equipment Damage Hazard.

Disconnect all power supplies

before wiring and follow the

National Electrical Code and all

local regulations to avoid

possible electrical shock or

damage to the equipment.

EDA-2040/ATP-2040 Electric Damper Actuator Installation

2 EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin

etting Actuator Stroke

To set the actuator stroke:

1. Make sure that the damper blade is visually

accessible or its position is permanently marked

on the end of the damper shaft as shown in

Figure 1.

Figure 1: Damper Position Icons

2. Grasp the damper shaft firmly with a pliers and

manually turn the damper in the direction of the

desired close off as shown in Figure 2. Consult

the box manufacturer’s information. Note the

rotation travel (30 to 90 degrees) and direction,

either Clockwise (CW) or Counterclockwise

(CCW), that is required to close the damper.

CW to

Open CCW to

Open

Damper

Shaft

VAV Box

Damper

Blade

Figure 2: Damper Rotation

3. Be aware that some box manufacturers do not

use 90 degree rotation. If the damper rotation is

less than 90 degrees, use a 9/64 in. hex key to

loosen the adjustable CCW end-stop on the

EDA-2040 enough to allow movement. Position

the end-stop as required by the application.

(See Figure 3.)

To CW

End-stop

To CCW

End-stop Ad

ustable

End-stop

OUT

GND

(-) LO

DPT-2015-0

Push

Gear

Release

Figure 3: Positioning to the End-stop

Note: Do not excessively loosen the end-stop as

this may permanently disable the

adjustment.

4. Tighten the end-stop between 20 and 25 in·lb.

5. Lift and hold the manual release lever, and turn

the actuator coupler until it contacts the

mechanical stop. Verify that both set screws are

accessible for tightening later.

IMPORTANT: The manual gear release lever will

not function if the actuator is driven

against a stop. Drive the actuator

1 degree off the stop to allow the

release to function.

Note: If the damper closes in the CCW direction,

the coupler should be rotated to the CCW

mechanical limit. If the damper closes in the

CW direction, the coupler should be rotated

to the CW mechanical limit.

6. If the damper shaft is longer than 2-1/4 inches,

use the standard mounting procedures. If the

damper shaft is shorter than 2-1/4 inches, use

the flush mounting procedures.

EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin 3

ounting

Standard

Observe ranges and limitations stated in the

Specifications section in the

EDA-2040/ATP-2040

Electric Damper Actuator Product Bulletin

in the

Damper and Actual Manual (FAN 268.1).

1. Verify that the damper blade is closed.

2. Place the actuator on the damper shaft so the

damper shaft protrudes through the actuator

coupler as shown in Figure 4.

VAV Box

(-)LO

OUT

GND

DPT-2015

Damper

Shaft

Figure 4: Standard Mounting

3. Place the actuator in the desired mounting

position 1/8 in. (3.2 mm) from the mounting

surface (shown in Figure 5) so that the wiring

connections are easily accessible.

1/8 in.

Gap

1/4 in. Barbed Ports

for Field Supplied

Tubin

EDA-2040 Mounted

to VAV Box

CBL-2000 Cable Harness

for Connection to VAV

Controller

Note: Upper port

(

)

LO.

1/4 in. O.D. Tubin

DPT-2015-0

Quick Connect

Terminals

Figure 5: Actuator Position

4 EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin

4. Use a punch to mark the position of the shoulder

washer on the mounting surface. The shoulder

washer should be at the center of the slot to

allow actuator movement during rotation.

(See Figure 6.)

OUT

GND

(-) LO

DPT-2015-0

Shoulder

Washer

CCW

COM

Anti-rotation

Screw

Figure 6: Anti-rotation Screw with

Shoulder Washer

5. Drill a hole into the mounting surface through the

mark using a drill and 5/32 in. (4 mm) bit.

6. Position the actuator so the shoulder washer is

over the hole; insert the anti-rotation screw, as

shown in Figure 6, and tighten against the

washer.

7. Secure the coupler to the shaft evenly by using

a 1/8 in. hex key to bottom each coupler hex set

screw against the damper shaft.

Note: Maintain 1/8 in. clearance between the

mounting surface and actuator while

tightening the hex socket screws.

(See Figure 5.)

8. After bottoming each hex set screw against the

damper shaft, continue turning the hex key until

obtaining approximately a 30 degree deflection

of the wrench as illustrated in Figure 7

(40 to 65 in·lb). Repeat for the other hex set

screw.

CAUTION: Equipment Damage Hazard.

Do not remove anti-rotation

screw and force damper blade

closed using the actuator. This

puts additional stress on the

gear train and could reduce the

life of the actuator.

30°

(-)LO

OUT

GND

DPT-2015

Figure 7: Tightening Hex Set Screw

9. Lift and hold the manual release lever and turn

the shaft by hand to ensure that the damper can

rotate from its full closed to full open positions.

Proceed to the

Connections

section to continue

installation.

Flush

Note: This application will require the use of

one short shaft coupler (EDA-2040-1002 or

EDA-2040-1003) for each actuator.

1. Manually rotate the damper shaft to gently close

the damper blade.

Short

Damper

Shaft

O-rin

VAV Box

ATP-2040

Short Shaft

Coupler

(-)LO

OUT

GND

DPT-2015

Figure 8: Flush Mounting

2. Install the short shaft coupler into the damper

shaft with the O-ring away from the damper as

shown in Figure 8. The coupler should be 1/8 in.

(3.2 mm) away from the mounting surface.

3. Secure the coupler to the shaft evenly by using

a 1/8 in. hex key to bottom each hex set screw

of the coupler against the damper shaft.

Note: Maintain 1/8 in. clearance between the

mounting surface and the coupler while

tightening the hex set screws.

EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin 5

4. After bottoming each screw against the damper

shaft, continue turning the hex key until obtaining

approximately a 30 degree deflection of the

wrench as illustrated in Figure 7 (40 to 65 in·lb).

Repeat for the other hex set screw.

5. Place the actuator onto the coupler in the

desired mounting position 1/8 in. (3.2 mm) from

the mounting surface as shown in Figure 8 so

that the wiring connections are easily accessible.

6. Mark the center of the shoulder washer on the

mounting surface and then remove the actuator

from the coupler.

7. Drill a 5/32 in. (4 mm) hole into the mounting

surface through the mark.

8. Install the actuator onto the coupler so the

shoulder washer is over the hole, insert the

anti-rotation screw and tighten.

9. Connect a 24 VAC power source to the actuator

(cannot manually rotate a flush mounted

EDA-2040), and drive it to the full open and

closed positions to be sure of damper operation.

Proceed to the

Connections

section to continue

installation.

CAUTION: Equipment Damage Hazard.

Do not remove anti-rotation

screw and force damper blade

closed using the actuator. This

puts additional stress on the

gear train and could reduce the

life of the actuator.

Switch Kit

Note: An EDA-2040 actuator with bosses on the

housing is required for switch mounting.

(See Figure 9.)

Bosses

(-)

OUT

GND

DPT-201

Insert

Screws

Switch Kit

Top

Switch Position

Indicator

Position

Scale

Bottom

Switch

Figure 9: Switch Kit Components

1. Install the standard coupler onto the actuator as

instructed in the

Mounting, Standard

section.

2. Position the switch kit so that the switch kit

coupler fits onto the actuator coupler.

3. Install the two screws to secure the switch kit to

the bosses on the actuator.

4. Verify that the damper is closed.

5. Verify that the position indicator points to the

damper closed position on the scale.

If the position indicator is not pointing to the

damper closed position, lift the scale from the

switch kit, reverse the scale, and install by

inserting its tabs into the recessed slots of the

switch kit. The position scale has two sides as

shown in Figure 10.

CCW

ToClose

To Close

15°

5°

Open

Figure 10: Position Scale Installation

6 EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin

Cam

COM NO NC

Switch Circuit

COM NO NC

Switch Circuit

Figure 11: Switch Circuits

6. Insert the long arm of a hex key into the slots of

the plastic coupler. Lift and hold the gear

release lever to rotate the coupler until the

pointer is located at the position to open/close a

switch depending on application.

Continuity

Tester

Ohmmeter

Figure 12: Tester Connections

7. Connect a continuity tester or ohmmeter to the

Common and Normally Open (NO)/Normally

Closed (NC) terminals of the top switch.

Top

Switch

Bottom

Switch

Cam

Teeth

Continuit

Tester

Ohmmeter

Slots

Figure 13: Tester Connections and Adjustment

8. Use the teeth of the top switch cam to rotate the

cam until a change in switch position is indicated

by the tester.

9. Rotate the switch kit coupler to verify switching

point.

10. Rotate the coupler to the position of desired

bottom switch point.

11. Repeat Steps 7 through 10 for the bottom

switch.

12. Verify that both switches activate at the desired

positions.

DPT-2015 on an EDA-2040 Actuator

Check the EDA-2040 cover for two inside mounting

bosses as shown in Figure 14. If there are none,

you must order the DPT-2015-MNT to mount the

DPT-2015-0 to your EDA-2040. The DPT-2015-0 is

also available assembled to the DPT-2015-MNT as

the DPT-2015-1. Follow the instructions provided

with either of these mounting kits or refer to the

DPT-2015-0 Differential Pressure Transmitter for

VAV Box Application Product/Technical Bulletin

the

Electronic Control Manual (FAN 216).

Inside Mountin

Bosses

Figure 14: EDA-2040 Shown with Two Inside

Mounting Bosses

EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin 7

onnections

Electrical Wiring

The ATP-2040 requires a 24 VAC control signal and

is compatible with a variety of controllers. All wiring

must be in accordance with National Electrical Code

and applicable local code requirements.

CAUTION: Disconnect all power supplies

to the system before wiring to

avoid damage to equipment or

possible electrical shock.

CCW COM CW IN GND OUT

VAC

W hite/ W hite W hite/ Red Black Blue

Oran

e Brown

EDA-2040 DPT-2015

VAC

CBL-2000 Wiring Harness

0.5-4.5

VDC

(

)

14.5-17

VDC

(

)

Common

(

)

Figure 15: Wiring Diagram

A CBL-2000 Wiring Harness is packaged with the

ATP-2040 or can be ordered separately for the

EDA-2040.

Air Pressure (ATP-2040 only)

The pressure sensing probe provided with the VAV

box must be connected to the DPT-2015 using field

supplied 1/4 in. O.D. tubing as follows:

1. Locate the pressure sensing probe provided with

the VAV box and cut two lengths of tubing for

connection to the barbed ports on the

DPT-2015. (See Figure 16.)

2. Connect the tubing from the pressure sensing

probe to the corresponding high and low,

indicated as (-) LO, pressure ports on the

DPT-2015.

CAUTION: Equipment Damage Hazard.

Overpressure limit is 15 in.

W.C. Do not blow into ports

to test the operation as this

may damage the sensing

element.

Note: If the pressure ports are not pointing down,

route the tubing so a portion of it is lower

than the DPT-2015. This creates a trap that

prevents any condensation from entering the

sensor. Also, do not make any sharp bends

in the tubing. This could collapse the tube

and block the pressure path.

EDA-2040 Mounted

to VAV Box

DPT-2015-0

1/4 in. Barbed Ports

for Field Supplied

Tubin

CBL-2000 Cable Harness

for Connection to VAV

Controller

Note: Upper port

(

)

LO.

1/4 in. O.D. Tubin

Figure 16: Air Pressure Connectors

ommissioning

EDA-2040

After wiring is completed, apply power to the

controller and provide signals to the actuator to drive

it at least one complete cycle open and close.

DPT-2015

1. Perform the checkout procedure provided in the

controller instructions to ensure proper operation

of the transmitter.

2. When used with a Johnson Controls VAV Series

controller, the DPT-2015 must be set up and

zeroed using HVAC PRO for Windows. Refer

to the

Variable Air Volume Controller Technical

Bulletin

in the

Controllers Technical Manuals

(FANs 636.3 or 1628.2)

for details.

IMPORTANT: Final commissioning should be

performed when the transmitter is

at normal operating temperatures

and mounted in its normal

operating position.

8 EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin

roubleshooting and Inspection

EDA-2040

1. Make sure the actuator/transmitter is mounted

on the duct and at ambient temperature.

2. Check that all electrical connections are

complete and power is applied.

3. Verify that the flow pickups are connected to the

DPT-2015.

4. Perform the checkout procedures described in

the

Variable Air Volume Controller Technical

Bulletin

in the

Controllers Technical Manuals

(FANs 636.3 or 1628.2)

to verify operation of the

actuator/transmitter.

5. Verify that the damper is fully opening and

closing.

DPT-2015

The DPT-2015 must be auto zeroed at the Johnson

Controls VAV controller. If not operating properly:

1. Make sure the air lines on the DPT-2015 are

connected to their respective high and low ports.

2. Check voltage to ensure it is within the

14.5 to 17 VDC range and the polarity is correct.

3. Disconnect the air lines from the high and low

ports, and place a voltmeter across terminals

OUT and GND. With power applied to the

DPT-2015, if the output is not between

0.4 and 0.6 volts, the transmitter is defective

and should be replaced.

Note: If the transmitter is not mounted vertically,

voltage readings may increase or decrease

by 0.1 volts.

EDA-2040/ATP-2040 Electric Damper Actuator Installation Technical Bulletin 9

Notes

Controls Group

507 E. Michigan Street

P.O. Box 423

Milwaukee, WI 53201 Printed in U.S.A.

Questo manuale è adatto per i seguenti modelli

Altri manuali Johnson Controls Controllori

Johnson Controls

Johnson Controls M100G Manuale utente

Johnson Controls

Johnson Controls CK721-A Guida rapida

Johnson Controls

Johnson Controls TEC3620 Series Manuale utente

Johnson Controls

Johnson Controls VA9204-GG-2Z Series Manuale utente

Johnson Controls

Johnson Controls M9132-AG -1N Series Manuale utente

Johnson Controls

Johnson Controls BMMS-1P Istruzioni operative originali

Johnson Controls

Johnson Controls tyco iSTAR Edge G2 Manuale dell'operatore

Johnson Controls

Johnson Controls FX-PCV1617 Manuale utente

Johnson Controls

Johnson Controls G670 Istruzioni per il montaggio

Johnson Controls

Johnson Controls tyco iSTAR Ultra Manuale dell'operatore

Johnson Controls

Johnson Controls VA-8122 Manuale di servizio

Johnson Controls

Johnson Controls VA-7481-0011 Manuale utente

Johnson Controls

Johnson Controls M9320-AUA-4 Manuale utente

Johnson Controls

Johnson Controls Hitachi C4IRK01 Manuale utente

Johnson Controls

Johnson Controls S1-33103010000 Manuale utente

Johnson Controls

Johnson Controls FAC2611-0U Manuale utente

Johnson Controls

Johnson Controls IQ Keypad-PG Manuale utente

Johnson Controls

Johnson Controls VA-9070 Series Manuale di servizio

Johnson Controls

Johnson Controls VA9208-AG Series Manuale utente

Johnson Controls

Johnson Controls T9800 Series Manuale di servizio

Johnson Controls

Johnson Controls M9108-GG 1N Series Manuale utente

Johnson Controls

Johnson Controls VMA18 Series Manuale utente

Johnson Controls

Johnson Controls PENN P70 Series Manuale utente

Johnson Controls

Johnson Controls LN Series Manuale utente

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
