JONATHAN Y JYL9068A Manuale utente

WARNING

INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR

OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.

Model# JYL9068A

Product Dimensions: L28.5"*W15.75"*H62.5"

CARE AND MAINTENANCE

Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate

vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to

the material. Avoid the use of chemicals and household cleaners as they may damage the finish.

* Please make sure that you have all parts indicated before you begin assembly of this item

* This item should be assembled on a soft surface to prevent scratching the finish during assembly

* To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below

for safe use and installation

NOTICE& IMPORTANT SAFETY INSTRUCTIONS

for safe use and installation

*The external flexible cable or cord of this lamp cannot be replaced;

If the cord is damaged, the lamp shall be destroyed

**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce

the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in

the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Never use with an extension

cord unless the plug can be fully inserted. do not attempt to disregard this safety feature.

Part List and Hardware List

PIECE DESCRIPTION PICTURE QUANTITY

Shade w/ tube

AD1X

PIECE DESCRIPTION PICTURE QUANTITY

Base

Srew

B4X E1X

Bulb

CTube 1X

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware

contents list. If any part is missing or damaged, do not attempt to assemble the product.

Estimated Assembly Time: 6 minutes.

PLEASUE USE TYPE"B" BULB MAX 40-WATT OR CFL BULB MAX 13-WATT OR LED MAX 9-WATT

THERE IS 1 X 4W LED BULB IN THE BOX.

Estimated Assembly Time: 6 minutes.

Step 1 Step 2

Make sure all parts could be aligned before assemble. Insert the bulb(E) into the socket.

Do not rotate lamp body too hard avoid base screw broken. Put the light on a level surface to check if everything is stable.

Insert the Tube(C) into the Base(D) and tighten it with Screws(B),be sure to align

the holes in the Base(D) together with the holes in Tube (C).

Insert the Shade w/ tube(A) into the Tube(C) and tighten it with Screws(B), be sure

to align the holes in the Shade w/ tube(A) together with the holes in Tube (C).

Be careful not to twist the power cord and tighten securely

ENJOY YOUR LAMP
