US-36G2 / Mh-36G2 / PT-B36G2

59508-043-01

1856

Instruction Manual

UHF PLL

TRue DIversity

WIRELESS SYSTEMS

US-36G2

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,

you are recommended to take few minutes to read this instruction manual carefully.

1. Important Caution

2. Features

3. Specication

3-1 Receiver// US-36G2

3-2 Handheld Transmitter // Mh-36G2

3-3 Body-pack Transmitter // PT-36BG2

3-4 Optional Condenser Microphone

4. Part Identication & Accessories

4-1 Receiver // US-36G2

4-2 Handheld Transmitter // Mh-36G2

4-3 Body-pack Transmitter // PT-36BG2

4-4 Optional Condenser Microphone

4-5 Accessories

5. Preparing Procedures & Basic Operation

5-1 Receiver// US-36G2

5-2 Handheld Transmitter // Mh-36G2

5-3 Body-pack Transmitter // PT-36BG2

6. Recommendation

7. Important notice

INDEX

WIRELESS MICROPHONE SYSTEM

1. Important Caution

2. Features

Always make all connections before plugging the unit into an AC power outlet.•

Do not leave the devices in a place neither with high temperature nor high humidity.•

Always do not handle the power cord with wet hands !•

Keep the devices away from re and heat sources.•

Due to the PLL synthesized technology, the system can oer up to 1441 selectable frequencies•

for choosing simultaneously.

6 groups, maximum 23 channels in one group.•

e true diversity reception with 2 independent RF receivers ensure the stable transmission and•

reception.

Adjustable Pilot tone squelch control can eectively reduce the noise.•

Equipped with S.A.W. lter benets the interference-resistant.•

Tuned antennas can benet the stable RF reception.•

Built-in Noise Squelch circuity & Mute function are available to restrain the interference for•

signals.

Rugged metal housing can pass through the dicult environment.

•

Equipped with balanced XLR and balanced output allow great convenience.•

Anti-interference design is available to work with every computer device.•

Transmission power selectable between 10 and 50mW (depends on local regulation).•

3. Specication

3-1 Receiver // US-36G2

3-2 Handheld Transmitter // Mh-36G2

Frequency Preparation........

Carrier Frequency Range..

S/N Ratio.....................................

T.H.D...............................................

Display.............................................

Display Contents.....................

Controls.........................................

Audio Output Level..............

AF Output Impedance........

Squelch...........................................

Operation Voltage..................

Output Connector.................

Dimension(m/m).................

PLL Synthesized Control

502~960 MHz

> 105dB

<0.6%@1KHz

LCD / LED

Frequency, Antenna A/B, Mute Display,

LED Meter, Baery Fuel Gauge

Power On/O, Frequency Up/Down,

Frequency Scan, Audio Level, Lock-on

-12dB

600Ω

Pilot Tone & Noise Mute

12-18 VDC, 200mA

1 XLR Balanced Socket

1 Ø6.3mm balanced phone jack

212.3mm (W)* 38.3mm (H)* 144mm (D)

Frequency Preparation.............

Carrier Frequency Range.......

RF Outputs......................................

Stability................................................

Frequency Deviation.................

LCD Display....................................

Controls..............................................

Spurious Emissions....................

Audio Frequency Response..

Baery..................................................

PLL Synthesized Control

502~960 MHz

10mW / 50mW

(Depend on Local Regulation)

±10KHz

±48KHz

Frequency, Baery Fuel Gauge, Sensitivity

Power On/O, Mode Seing, AF Level, Frequency

Up/Down, Lock-on Mode

<-50 dBC

50~16,000 Hz

UM3, AA 1.5V*2

WIRELESS MICROPHONE SYSTEM

3-3 Body-pack Transmitter // PT-36BG2

3-4 Optional Condenser Microphone

Model No...............................

Connector..............................

Option Connector...........

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-501

4P Mini XLR

100~15,000 Hz

Cardioid

-60±3 dB

2.2kΩ

130dB

Ø10.1mm(W)

* 26.4mm(H)

21.5g

CM-201i

201C4 (4P Mini XLR)

201C3 (3P Mini XLR)

201CS (3.5 stereo plug)

201CR

60~15,000 Hz

Omni-directional

-60±3 dB

2.2kΩ

130dB

Ø5mm(W)* 9mm(H)

20.7g

CM-125

201C4 (4P Mini XLR)

201C3 (3P Mini XLR)

201CS (3.5 stereo plug)

201CR

50~18,000 Hz

Omni-directional

-53±3 dB

4.4kΩ

130dB

Ø4mm(W)* 11mm(H)

7g (cable excluded)

Lavaliere Microphone

Frequency Preparation..............

Carrier Frequency Range........

RF Outputs.......................................

Stability.................................................

Frequency Deviation..................

LCD Display.....................................

Controls...............................................

Output connector.........................

Spurious Emissions.....................

Audio Frequency Response...

Baery...................................................

PLL Synthesized Control

502~960 MHz

10mW / 50mW

(Depend on Local Regulation)

±10KHz

±48KHz

Frequency, Baery Fuel Gauge

Power On/O, AF Level, Frequency Up/Down,

Lock-on Mode

4P mini XLR

<-50 dBC

40~18,000 Hz

UM3, AA 1.5V*2

Headset Microphone

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-235

801C4 (4P Mini XLR )

50~18,000 Hz

Omni-directional

-53±3 dB

1.8kΩ

130dB

155mm(W)

* 134mm(H)

* 157mm(D)

17g (cable excluded)

CX-504

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

285mm(W)

* 55mm(H)

* 111.3mm(D)

56.3g

Model No...............................

Connector...............................

Option Connector...........

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Dimension(mm)..............

Net Weight............................

CM-214

801C4

(4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-60±3 dB

1.8kΩ

130dB

125mm(W)

* 134mm(H)

* 157mm(D)

32.9g

CM-214U

4P Mini XLR

30~18,000 Hz

Cardioid

-68±3 dB

680Ω

130dB

205mm(W)

* 134mm(H)

* 157mm(D)

38.4g

CM-214UL

801C3 (3P Mini XLR)

801C4 (4P Mini XLR)

801CS (3.5 stereo plug)

801CR

100 ~ 18,000Hz

Cardioid

-65±3 dB

1.8kΩ

120dB

125mm(W)

* 134mm(H)

* 157mm(D)

18g (cable excluded)

WIRELESS MICROPHONE SYSTEM

Ear-hook Microphone

Model No...............................

Connector..............................

Option Connector...........

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

CM-801/CM-804i

801C4 (4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

60~15,000 Hz

Omni-directional

-64±3 dB

1.8kΩ

130dB

CM-8015/CM-825i

801C4 (4P Mini XLR)

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

50~18,000 Hz

Omni-directional

-53±3 dB

1.8kΩ

130dB

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For.................................

Model No...............................

Connector..............................

Frequency Response......

Polar Paern..........................

Sensitivity (at 1000Hz)

Impedance.............................

Max. SPL for 1% THD

Good For.................................

CX-500

4P Mini XLR

20~20,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Violin

CX-508W

4P Mini XLR

50~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Winds

CX-500F

4P Mini XLR

20~20,000 Hz

Omni-directional

-58±3dB

1.5kΩ

130 dB

Flutes

CX-520

4P Mini XLR

50~16,500 Hz

Supercardioid

-78±3dB

600Ω

148 dB

Harmonica

CX-516W

4P Mini XLR

30~18,000 Hz

Cardioid

-67±3 dB

220Ω

130 dB

Accordion

Compatible Instrument Microphone

4. Parts Identication & Accessories

4-1 Receiver // US-36G2

Power On/O switch

Up buon (frequency adjustment)

Down buon (frequency adjustment)

Set buon (frequency adjustment)

LCD Display

Volume control

DC socket for connection of main unit

AF output, jack socket (AF UNBAL)

Balanced XLR socket

Antenna input socket

Antenna

AF signal level

RF signal level

13 4

VOL.

MIN. MAX.

DIVERSITY RECEIVER US-36G2

ID:

SQ.

LOCK ATT.ON

MHz

7 10 10

500

1856

8 9
