JTS RU-8011D Manuale utente

59508-084-01

PROFESSIONAL CO., LTD

www.jts.com.tw

Instruction Manual

UHF PLL

With JTS Ultrasonic Synchronizing Technology

One year product warranty

Warranty description

1. Be sure to put the warranty label indicating purchase date on the bottom of

equipment to ensure your interest in maintenance and service.

2. Product warranty, starting on the purchase date indicated on“warranty label”, will

last for one year; if the equipment does not have “warranty label”, the warranty

period is 15 months from the manufacturing date. If a microphone is broken but

not sent back with the equipment, the warranty period is 15 months from the

manufacturing date of the microphone.

3. Within the warranty period, if the equipment is broken under normal use as

instructed in manual, please contact the original selling store for repair.

4. When the product is returned for repair, to facilitate proper determination of

cause of malfunction and of whether repair fee is needed, please ship back the

equipment and microphone together.

5. Within the warranty period, our company provides repair service at no cost ex-

cept for the following conditions that parts and repair may be charged:

a.Damages due to natural disaster or irresistible outside forces.

b.Damages due to drop, water, moisture, corrosion, foreign objects, missing

components.

c.The warranty does not cover consumable parts. (such as microphone capsule,

ball grille etc.)

d.Those without“warranty label” on equipment or with “warranty label” being

damaged and failing to identify warranty period.

6. Please keep the warranty properly. No replacement will be made if the warranty

is missing.

Equipment

serial number

Contact

number

Address

Purchase date

Selling store

stamp Be sure to put store stamp and ll in purchase date for the warranty to be

eective!

Product Model

Customer

name

1. Notes for system operations

2. Features

3. Specications

3-1 UHF PLL single/dual-channel diversity receiver

3-2 UHF PLL hand-held transmitter

3-3 UHF PLL belt-mount transmitter

3-4 Optional condenser microphone

4. Description of parts

4-1 UHF PLL single-channel diversity receiver //

4-2 UHF PLL single-channel diversity receiver //

4-3 UHF PLL dual-channel diversity receiver //

4-4 UHF PLL hand-held transmitter //

4-5 UHF PLL hand-held transmitter //

4-6 UHF PLL body-pack transmitter //

4-7 UHF PLL body-pack transmitter //

4-8 Accessories

4-9 Optional Condenser Microphone

5. Connecting

5-1 How to connect the receiver

5-2 Transmitter installation // / / /

6. Instructions for use

6-1 How to use //

6-2 How to use //

6-3 How to use //

6-4 How to use // /

6-5 How to use // /

7. Notes for the product

Table of Contents

1. Notes for system operations

2. Features

• Before connecting the power, check that the power requirement shown

on the unit is the same as the power output on the adaptor supplied.

• Do not leave the unit at where the humidity and temperature are high.

• Dry your hands before operating the system.

• Keep the unit away from re and heat source.

• Turn the volume to minimum at both the mixer and amplier before

setting up the system.

• 6 groups are provided as default. Every group contains up to 22 default

channels.

• There are in total 1,440 channels to choose from.

• 36MHz bandwidth.

• The patented ultrasonic pairing for synchronized setting of

all parameters

• Channel scan

• Adjustable receiving sensitivity

• Digital volume control

• Automatic microphone power o

3. Specications

3-1 UHF PLL single/dual-channel diversity receiver

Model

Frequency Oscillation

Mode

Phase-locked loop (PLL)

Carrier Frequency Range 470~ MHz

Remoset Frequency Ultrasonic

Diversity Antennas diversity

Bandwidth 36MHz

Signal/Noise Ratio >105dB(A)

Total Harmonic Distortion

(Thd)

<0.6%@1KHz

Receiving Sensitivity -95dBm，S/N>80dB

Image Rejection Ratio >80 dB

Frequency Response 60Hz~15KHz±2dB 50Hz~16KHz±2dB

Antenna Type Fixed antenna BNC detachable

Antenna Booster Power None DC12~15V/100mA

Function Display By LCD

Contents Of Display

Group, channel, antenna

A/B, muting level, AF

indication, RF indication,

channel scanning, output

level attenuation, volume

indication

Group, channel, frequency, battery

level, antenna A/B, muting level, AF

indication, RF indication, channel

scanning, output level attenuation,

volume indication, machine ID code

Control Functions

Power, group, channel,

muting level, channel

scan (on/o), button lock,

volume, output attenuation

(XLR)

Power, group, channel, frequency,

muting level, button lock, volume,

output attenuation (XLR), channel

scan (on/o)

Audio Frequency Output

Level

Ref：±22.5KHz Dev@1KHz Tone

ψ6.3 Phone Jack：-10dBV

XLR Jack：-4dBV(Line)、-24dBV(MIC)

Audio Frequency Output

Impedance

600Ω

Model

Muting Noise muting and tone code locking

Output Port

1 x balanced XLR jack

1 x unbalanced ϕ6.3 jack

2 x balanced XLR

jack

2 x unbalanced

ϕ6.3 jack

Power Supply

DC12~15V/300mA 12~15V DC /

500mA

Dimension (Mm) 212.3mm (W) x 38.3mm (H) x 144mm (L)

3-2 UHF PLL hand-held transmitter

Model

Frequency Oscillation Mode Phase-locked loop (PLL)

Carrier Wave Frequency Range 470~60MHz

Remoset Frequency Ultrasonic

RF Power Output 10mW/50mW(as per local regulations)

RF Stability <±10KHz＠Fc

Modulation Frequency Shift ±48KHz

Harmonic Radiation <-50dBc

Functions Mute, auto o, input level attenuation, sensitivity

adjustment, low power indication

Display By LED LCD+LED

Controls

Power, mute Power, mute, group, channel, frequency,

sensitivity adjustment, input level

attenuation, auto o, button lock

Battery AA alkali battery or MiNH rechargeable battery x 2

Charging No Yes

Dimension 51mm (W) x 269mm (H) x 26mm (L)

Model

Frequency Oscillation

Mode

Phase-locked loop (PLL)

Carrier Wave Frequency

Range

470~60MHz

Remoset Frequency Ultrasonic

RF Power Output 10mW/50mW(as per local regulations)

RF Stability <±10KHz＠Fc

Modulation Frequency

Shift

±48KHz

Harmonic Radiation <-50dBc

Functions Mute, auto o, input level attenuation, sensitivity

adjustment, low power indication

Display By LED LCD+LED

Input Port 4 pin Mini XLR

Controls

Power, mute Power, mute, group, channel,

frequency, sensitivity

adjustment, input level

attenuation, auto o

Battery AA alkali battery or MiNH rechargeable battery x 2

Charging No Yes

Dimension 62mm (W) x 97mm (H) x 20mm (L)

3-3 UHF PLL body-pack transmitter

3-4 Optional condenser microphone

Lavaliere microphone

Headset microphone

Model CM-501 CM-201i CM-125i

Connector 4-pin mini XLR 4-pin mini 4-pin mini XLR

Frequency Response 100~15,000 Hz XLR60~15,000 Hz 50~18,000 Hz

Polar Pattern Cardioid Omni-directivity

Sensitivity (at 1000Hz) -60 ± 3dB -60 ± 3dB -53 ± 3dB

Impedance 2.2K Ω 4.4K Ω

Max. SPL for 1% THD 130dB

Dimension (mm) Ø10.1mm (W) x

26.4mm (H)

Ø5mm (W) x

9mm (H)

Ø4mm (W) x

11mm (H)

Net Weight 21.5g 20.7g 7g (cable not included)

Model CM-214i CM-214Ui CM-214ULi

Connector

801C4

(4P Mini XLR)

4P Mini XLR 801C3 (3P Mini XLR)

801C4 (4P Mini XLR)

801CS (3.5 stereo plug)

Option

Connector

801C3 (3P Mini XLR)

801CS (3.5 stereo plug)

801CR

Frequency Response 60~15,000 Hz 30~18,000 Hz 100 ~ 18,000Hz

Polar Pattern Omni-directional Cardioid

Sensitivity (at 1000Hz) -60±3 dB -68±3 dB -65±3 dB

Impedance 1.8kΩ 680Ω 1.8kΩ

Max. SPL for 1% THD 130dB 120dB

Dimension(mm)

125mm(W) x

134mm(H)x

157mm(D)

205mm(W)x

134mm(H)x

157mm(D)

125mm(W)x

134mm(H)x

157mm(D)

Net Weight 32.9g 38.4g 18g (cable excluded)
