ENGLISH
Read the Operating Instructions carefully before use!
SAFETY INSTRUCTIONS
Turn off the repeller if a pet is playing in the protected area.
Also turn off the repeller to save the battery if there is a person in the protected area.
Do not immerse the repeller in water or any other liquid.
Do not change or tamper with the repeller's internal components. Do not cover or paint over the
speaker at the front. This can damage the repeller and cause malfunction.
The PIR system is activated by the movements of the animals (and their thermal radiation).
Make sure the lens is clean. Do not touch the lens with your fingers. Wipe it clean with a damp
cloth. Do not use petrol, alcohol or thinner.
If the repeller is used indoors, the dog or cat must have somewhere else they can go.
TECHNICAL DATA
Dimensions 114 x 88 x 60 mm
Weight 180 grams (repeller + mounting shelter)
Operating voltage 1 x 9 volt alkaline battery
Idle current 0.16 mA
Shut-off delay for ultrasound Approx. 25 seconds
Heat-up time Approx. 30 seconds
Frequency Approx. 23,000 Hz
Protected area 70° fan-shape up to a distance of 9 metres
(see the lower illustration in the original
manual)
Accessories Screws, plastic post (45 cm)
ASSEMBLY
11. Disconnect the main module from the mounting shelter by inserting a thin, blunt blade down into
the rear of the unit and twisting carefully. The repeller then slides out of the shelter.
12. Open the battery cover on the rear of the repeller and insert a new 9 volt alkaline battery.
13. Reinstall the dog and cat repeller in the shelter. You can use the screw supplied to secure the
mounting shelter in the screw hole on the plastic post if you want to place the repeller 30-40 cm
above ground level. You can also screw the shelter in its mounting hole on a wall or post 30-90 cm
above the ground.
14. Turn the power switch to ON. The built-in red LED indicator inside the IR lens comes on after
heating up for approximately 30 seconds to confirm that the repeller is activated.
15. Leave the repeller turned on for 24 hours.
Replace the battery if the red LED does not come on when the repeller detects movement within the
protected area. Turn the switch to OFF and repeat steps 1 and 2 above.
HANDLING
Description
This PIR and ultrasonic dog and cat repeller conveniently and effectively keeps dogs, cats, hares and
squirrels away from your garden, lawn and other outdoor areas, without harming the animals.
The repeller uses sophisticated PIR (passive infrared) technology to monitor a 70º fan-shaped area up to
9 metres in length, for an effective range of approximately 50 square metres. Any animals (or people)
encroaching this area are detected. When the system is triggered, the repeller emits an ultrasound signal
at a frequency of 23,000 Hz to scare away the intruder.
The PIR technology allows the service life of the battery (1 x 9 volt alkaline battery) to be optimised.
Battery operation means you can position the repeller wherever you want. For example, on the wall
outside your house or at ground level using the enclosed plastic post.
The repeller is weather-proof, although you should disconnect it from the mounting shelter and bring it
inside if severe stormy weather is approaching.
The ultrasound is inaudible to humans, but causes animals discomfort. They react by moving away from
the source of the discomfort as quickly as possible.
