Juniper NFX250 Manuale utente
Quick Start
NFX250
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 5
Step 3: Keep Going | 7
Step 1: Begin
IN THIS SECTION
Meet the NFX250 | 2
Install the NFX250 | 2
What Else Do I Need? | 3
Install the NFX250 in a Two-Post Rack | 3
Power On | 4
In this guide, we provide a simple, three-step path, to quickly get you up and running with your new NFX250. We’ve
simplified and shortened the installation and configuration steps, and included how-to videos. You'll learn how to install
the NFX250 in a rack, power it up, and deploy it on your network using the CLI.
Meet the NFX250
The Juniper Networks®NFX250 Network Services Platform integrates routing, switching, and security functions on a
single platform. With the NFX250, you can provision secure, fast, custom service delivery on demand.
Install the NFX250
IN THIS SECTION
What’s in the Box? | 2
You can install the NFX250 on your desktop, on a wall, or in a two-post or four-post rack. The accessory kit that ships in
the box has the brackets you need to install the NFX250 in a two-post rack. In this guide, we show you how to install the
NFX250 in a two-post rack. If you need to install the NFX250 in a four-post rack, you’ll need to order a four-post rack
mount kit.
What’s in the Box?
•NFX250 Network Services Platform device
•AC power cord for your geographic location
•AC power cord retainer clip
•Two rack mount brackets
•Eight mounting screws to attach the mounting brackets to the NFX250
•Four rubber feet (for desktop installation)
2
What Else Do I Need?
•Someone to help you mount the NFX250 in the rack.
•Four rack mount screws to secure the mounting brackets to the rack
•A number 2 Phillips (+) screwdriver
•An Ethernet cable with RJ-45 connectors attached and an RJ-45 to DB-9 serial port adapter
NOTE: We no longer include a DB-9 to RJ-45 cable or a DB-9 to RJ-45 adapter with a CAT5E copper cable
as part of the device package. If you require a console cable, you can order it separately with the part number
JNP-CBL-RJ45-DB9 (DB-9 to RJ-45 adapter with a CAT5E copper cable).
Install the NFX250 in a Two-Post Rack
Here’s how to install the NFX250 in a two-post rack:
1. Review General Safety Guidelines and Warnings.
2. Attach the ESD grounding strap to your bare wrist and to a site ESD point.
3. Secure the mounting brackets to the sides of the NFX250 using eight screws and the screwdriver. You’ll notice there
are three locations on the side panel where you can attach the mounting brackets: front, center, and rear. Attach the
mounting brackets to the location that best suits where you want the NFX250 to sit in the rack.
3
4. Lift the NFX250 and position it in the rack. Line up the bottom hole in each mounting bracket with a hole in each rack
rail, making sure the NFX250 is level.
5. While you’re holding the NFX250 in place, have a second person insert and tighten the rack mount screws to secure
the mounting brackets to the rack rails. Make sure they tighten the screws in the two bottom holes first and then
tighten the screws in the two top holes.
6. Check that the mounting brackets on each side of the rack are level.
Power On
1. Attach a grounding cable to earth ground and then attach it to the NFX250’s grounding points.
2. Turn off the power switch on the NFX250 rear panel.
3. On the rear panel, insert the L-shaped ends of the power cord retainer clip into the holes in the bracket on the power
socket. The power cord retainer clip extends out of the chassis by 3 inches.
4. Insert the power cord coupler firmly into the power socket.
5. Push the power cord into the slot in the adjustment nut of the power cord retainer clip. Turn the nut until it is tight
against the base of the coupler and the slot in the nut is turned 90° from the top of the device.
4
6. If the AC power source outlet has a power switch, turn it off.
7. Plug in the AC power cord to the AC power source outlet.
8. Turn on the power switch on the NFX250 rear panel.
9. If the AC power source outlet has a power switch, turn it on.
10. Verify that the power LED on the NFX250 front panel is green.
Step 2: Up and Running
IN THIS SECTION
Connect and Configure | 5
Now that the NFX250 is powered on, let’s get you up and running on the network!
Connect and Configure
You’ll need to do the initial configuration of the NFX250 through the console port using the CLI. Before you begin
connecting and configuring the NFX250, make sure the serial port on your laptop or PC are set to the defaults:
•Baud Rate—9600
•Flow Control—None
•Data—8
•Parity—None
•Stop Bits—1
•DCD State—Disregard
Here’s how to connect and configure the NFX250 to the network from the console port:
5
1. Connect the console port (labeled CON on the NFX250 front panel) to a laptop using the RJ-45 cable and RJ-45 to
DB-9 adapter (not provided). The Juniper Device Manager (JDM) CLI is displayed.
2. Log in as root. There is no password. If the software booted before you connected the cable to the console port, you
might need to press the Enter key for the prompt to appear.
login: root
3. Start the CLI.
root@jdm% cli
4. Enter configuration mode.
root@jdm> configure
5. Add a password to the root administration user account. Enter a plain text password.
[edit]
root@jdm># set system root-authentication plain-text-password
New password: password
Retype new password: password
6. (Optional) Give the NFX250 a name. If the name includes spaces, enclose the name in quotation marks (“ ”).
[edit]
root@jdm# set system host-name host-name
7. Configure the IP address and prefix length for the device management interface.
[edit]
root@jdm# set interfaces jmgmt0 unit 0 family inet address address/prefix-length
NOTE: jmgmt0 is the out-of-band management network interface in JDM.
To configure an IPV6 address, type root@jdm# set interface jmgmt0 family inet6 address address v6_address.
6
NOTE: jmgmt0 is the management port labeled MGMT on the NFX250 front panel.
8. Configure the default gateway.
[edit]
root@jdm# set routing-options static route default next-hop address
9. Commit the configuration to activate it on the device.
[edit]
root@jdm# commit
10. Connect the NFX250 to the Internet (WAN ports 0/12 and 0/13).
The ISP assigns an IP address to the NFX250 through Dynamic Host Configuration Protocol (DHCP).
11. Connect your laptop to a LAN port (ports 0/0 to 0/11).
The DHCP server running on the NFX250 assigns an IP address to your computer.
12. To verify your connectivity, open a browser window and navigate to https://www.juniper.net.
Step 3: Keep Going
IN THIS SECTION
What’s Next? | 8
General Information | 8
Learn With Videos | 9
Congratulations! Your NFX250 is ready to go. Here are some things you can do next.
7
What’s Next?
ThenIf you want to
See Activate Junos OS Licenses in the Juniper Licensing
Guide
Download, activate, and manage your software licenses
to unlock additional features for your NFX series device
See Prerequisites to Onboard Virtual Network Functions
on NFX250 (NextGen) Devices
Set up another device
See Configuring JDM User Accounts and AuthenticationConfigure JDM User Accounts and Authentication
See the Network Management and Monitoring GuideConfigure network management protocols and
technologies
See Software Upgrade Path for NFX250 DevicesManage software upgrades
General Information
ThenIf you want to
Visit the NFX250 Documentation page in the Juniper
TechLibrary
See all documentation available for the NFX250
See the NFX250 Network Services Platform Hardware
Guide
Find more in-depth information about installing the
NFX250
See How to Configure the NFX250 and How to Configure
the NFX250 (NextGen)
Find more in-depth information about configuring the
NFX250
Visit the Security Design CenterSee, automate, and protect your network with Juniper
Security
8
Learn With Videos
Our video library continues to grow! We’ve created many, many videos that demonstrate how to do everything from
install your hardware to configure advanced Junos OS network features. Here are some great video and training resources
that will help you expand your knowledge of Junos OS.
ThenIf you want to
See Learning with Juniper on the Juniper Networks main
YouTube page
Get short and concise tips and instructions that provide
quick answers, clarity, and insight into specific features
and functions of Juniper technologies
Visit the Getting Started page on the Juniper Learning
Portal
View a list of the many free technical trainings we offer
at Juniper
Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the
United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the
property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper
Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. Copyright © 2023
Juniper Networks, Inc. All rights reserved. Rev. 04, August 23.
