D6 – Quick Reference Guide
2
D6 – Quick Reference Guide
D6 – Quick Reference Guide
J
These short instructions do not replace the ‘D6 Instructions for Use’.
Make sure you read and observe the safety information and war-
nings first in order to avoid hazards.
Ten minutes after milk preparation, the D6 prompts you to perform
milk system rinsing.
Precondition: M-RINSE / CAPPUCC. is displayed (example).
TPlace a receptacle under the fine foam frother.
TTouch the Maintenance symbol cfor approximately
2 seconds until OPEN SWITCH appears.
TTurn the switch to the mposition.
The fine foam frother is rinsed.
CLOSE SWITCH
TTurn the switch to the °position.
CAPPUCC. (example)
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
TUse only original JURA maintenance products.
EJURA milk system cleaner is available from specialised dealers.
Precondition: CAPPUCC. is displayed (example).
TTouch the P symbol for approximately 2 seconds until
RINSE appears on the display.
TPress the Rotary Switch to enter the programme item.
M-RINSE
TTurn the Rotary Switch until M-CLEAN is displayed.
TPress the Rotary Switch.
CLEANER / WATER
TRemove the milk pipe from the milk container or milk cooler.
Rinsing the fine foam
frother
Cleaning the fine foam
frother
CAUTION
3
D6 – Quick Reference Guide
TPour 250 ml of fresh water into a receptacle and add 1 capful
of milk system cleaner.
TImmerse the milk pipe in the receptacle.
TPlace a receptacle under the fine foam frother.
TPress the Rotary Switch.
M-CLEAN, OPEN SWITCH, the light segment on the
switch lights up.
TTurn the switch to the mposition.
The fine foam frother and the milk pipe are cleaned.
CLOSE SWITCH
TTurn the switch to the °position.
WATER
TRinse the receptacle thoroughly, fill it with 250 ml of fresh
water and immerse the milk pipe in the water.
TEmpty the other receptacle and place it under the fine foam
frother once more.
TPress the Rotary Switch.
OPEN SWITCH
TTurn the switch to the mposition.
The fine foam frother and the milk pipe are rinsed with fresh
water.
CLOSE SWITCH
TTurn the switch to the °position.
CAPPUCC. (example)
To make sure the fine foam frother works properly, and in the inte-
rests of hygiene, it must be dismantled and rinsed daily if you have
been preparing milk. Your D6 will not prompt you to dismantle and
rinse the frother.
TRemove the milk pipe and rinse it thoroughly under running
water.
TCarefully remove the fine foam frother from the Connector
System©by twisting slightly.
Dismantling and rinsing
the fine foam frother
4
D6 – Quick Reference Guide
TDismantle the fine foam frother into its individual parts.
TRinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250 ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
TRe-assemble the fine foam frother.
EEnsure that all individual parts are correctly and firmly con-
nected to ensure optimum operation.
TFirmly attach the fine foam frother to the Connector Sys-
tem©.
Your D6 no longer has to be descaled if you are using the CLARIS
Smart filter cartridge.
EOnce the filter cartridge stops working (depending on the
water hardness setting), the D6 will prompt you to change the
filter.
ECLARIS Smart filter cartridges are available from specialised
dealers.
Precondition: FILTER / CAPPUCC. is displayed (example).
TOpen the water tank cover.
TRemove and empty the water tank.
TOpen the filter holder and remove the old CLARIS Smart
filter cartridge.
TInsert a new CLARIS filter cartridge Smart into the water
tank, exerting slight pressure.
TClose the filter holder. It will click into place audibly.
TFill the water tank with fresh, cold water and reinsert the
tank.
The machine has automatically detected that you have just
inserted/changed the filter cartridge.
OPEN SWITCH, the light segment on the switch lights
up.
TPlace a receptacle under the fine foam frother.
Inserting/changing the
filter
5
D6 – Quick Reference Guide
TTurn the switch to the mposition.
FILTER RINSING, water flows out of the fine foam fro-
ther.
Rinsing of the filter stops automatically.
CLOSE SWITCH
TTurn the switch to the °position.
CAPPUCC. (example)
After 180 preparations or 80 switch-on rinses, the D6 will prompt
you to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
TUse only original JURA maintenance products.
EThe cleaning programme lasts approximately 20 minutes.
EDo not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
EJURA cleaning tablets are available from specialised dealers.
Precondition: CLEAN / CAPPUCC. is displayed (example).
TTouch the Maintenance symbol cfor approximately
2 seconds.
EMPTY TRAY appears on the display.
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
PRESS RINSE
TPlace a receptacle under the coffee spout.
TTouch the Maintenance symbol c.
CLEANING, water flows out of the coffee spout.
The operation is interrupted, ADD TABLET.
TOpen the cover of the filler funnel for the cleaning tablet.
Cleaning the machine
CAUTION
6
D6 – Quick Reference Guide
TInsert a JURA cleaning tablet into the filler funnel.
TClose the cover of the filler funnel.
TTouch the Maintenance symbol c.
CLEANING, water flows out of the coffee spout several
times.
The operation stops automatically.
EMPTY TRAY
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
CAPPUCC. (example)
The D6 builds up deposits of limescale over time and automatically
prompts you to descale it when necessary. The degree of calcifica-
tion depends on the hardness of your water.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
TAvoid contact with the skin or eyes.
TRinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dama-
ged and/or traces could be left behind in the water.
TUse only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
TAllow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
TClean up any splashes immediately.
EThe descaling programme lasts approximately 45 minutes.
EJURA descaling tablets are available from specialised dealers.
Precondition: DESCALE / CAPPUCC. is displayed (example).
TTouch the Maintenance symbol cfor approximately
2 seconds.
EMPTY TRAY appears on the display.
Descaling the machine
JCAUTION
CAUTION
CAUTION
CAUTION
7
D6 – Quick Reference Guide
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
AGENT IN TANK
TRemove and empty the water tank.
TCompletely dissolve 3 JURA descaling tablets in a receptacle
holding 500 ml of water. This may take several minutes.
TPour the solution into the empty water tank and insert it
into the machine.
OPEN SWITCH, the light segment on the switch lights
up.
TPlace a receptacle under the fine foam frother.
TTurn the switch to the mposition.
DESCALE appears and water flows out of the fine foam
frother repeatedly. The Maintenance symbol cflashes
during the descaling operation.
The operation is interrupted, CLOSE SWITCH.
TTurn the switch to the °position.
DESCALE. The descaling operation is continued.
The operation is interrupted, EMPTY TRAY.
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
FILL TANK
TEmpty the receptacle and place it under the coffee spout
and fine foam frother.
TRemove the water tank and rinse it thoroughly.
TFill the water tank with fresh, cold water and reinsert the
tank.
OPEN SWITCH, the light segment on the switch lights
up.
TTurn the switch to the mposition.
DESCALE
The operation is interrupted, CLOSE SWITCH.
TTurn the switch to the °position.
DESCALE
The operation is interrupted, DESCALE.
Water flows out of the coffee spout.
EMPTY TRAY
8
D6 – Quick Reference Guide
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
CAPPUCC. (example)
EIf the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition: FILL BEANS is displayed.
TPress the On/Off button Qto switch the D6 off.
TOpen the bean container cover and remove the aroma pre-
servation cover.
TClean the bean container with a soft, dry cloth.
TFill the bean container with coffee beans and close the
aroma preservation cover.
TClose the bean container cover.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
TRemove the water tank.
TIf you use a CLARIS Smart filter cartridge, remove this.
TCompletely fill the water tank and dissolve 3 JURA descaling
tablets in it.
TLeave the water tank with the descaling solution for several
hours (e.g. overnight).
TEmpty the water tank and rinse it thoroughly.
TIf you use a CLARIS Smart filter cartridge, insert this again.
TFill the water tank with fresh, cold water and reinsert the
tank.
Cleaning the bean
container
Descaling the water tank
D6_Kurz/en/201804
