JVC KSAX3002 - Compact Power Amplifier Manuale utente
Product Highlights:
KS-AX3002
Bridgeable 2-Channel Power Amplifier
- Max. Power Output of 370W
- Continuous Power Output: 65W RMS x 2 at 4 ohms
- 2- or 1-Channel Operation
- Class-AB Circuit
- PWM Regulated MOS-FET Power Supply
- Frequency Response: 5Hz - 50000Hz (0, -3dB)
- S/N: 76dBA
- THD: Less than 0.04% at 1kHz
- HPF (150Hz, -12dB/oct)
- LPF (80Hz, -12dB/oct)
- Variable Input Level Control (0.3 - 6V)
- Gold-Plated Input Terminals (Power)
- Gold-Plated RCA Jacks
- Speaker Input Connector
- Protection Circuitry (Thernmal/Short Circuit/
Overload/DC Offset)
- Anti-Pop Circuit
- LED Indicator
JVC ISD - j@net Product Information as of 02/Sep/2008
Design and specifications subject to change without notice.
KS-AX3002
Bridgeable 2-Channel Power Amplifier
JVC ISD - j@net Product Information as of 02/Sep/2008
Amplifiers
Amplifier
Continuous Power Output 65W x 2
(RMS) at 4 ohms, 20Hz
to 20,000Hz, less than
or equal to 1% THD+N
(CEA-2006 compliant)
Operation Channel 1 or 2
Bridgeable Yes
Maximum Power Output 370W
RMS Power Output 90W x 2 into 2 ohms less
than or equal to 1% THD+N,
130W x 1 into 4 ohms at
less than or equal to 1%
THD+N
MOS-FET Power Supply Yes
Input Level Control Yes
HPF 150Hz, -12dB/oct
LPF 80Hz, -12dB/oct
Variable Input RCA Level 0.3 - 6V
Control
Variable Speaker Input Yes
Control
Gold-Plated Input 2 Pairs
Terminals (Power)
Power Supply Block 3 Pairs (Gold-Plated)
Terminals
Speaker Out Block 4 Pairs x 1 (Gold-Plated)
Terminals
Speaker Input Connector 6 Pairs, 3 Wires
Protection Circuitry Yes
(Thermal / Short
Circuit / Overload / DC
Offset)
Anti-Pop Circuit Yes
LED Illumination Yes
Frequency Response (+0, 5Hz - 50kHz
-3dB)
Signal-to-Noise Ratio 76dBA
(reference: 1W into 4
ohms), CEA-2006
Compliant
Load Impedance 4 ohms
Allowance 2 - 8 ohms
Allowance (Bridged) 4 - 8 ohms
Distortion (at 1kHz) Less than 0.04%
