For canceling the display demonstration, see page 6.
INSTRUCTIONS
GET0553-001A
[UI]
CD RECEIVER KD-G336S
Cover_KD-G336S[UI]f.indd 1Cover_KD-G336S[UI]f.indd 1 1/19/08 11:13:00 AM1/19/08 11:13:00 AM
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
How to reset your unit
• Your preset adjustments will also be erased.
How to forcib y eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
Warning:
If you need to operate the unit while driving, be
sure to look ahead carefully or you may be involved
in a traffic accident.
Caution on vo ume setting:
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
[European Union only]
EN02-07_KD-G336S[UI]f.indd 2EN02-07_KD-G336S[UI]f.indd 2 1/19/08 11:13:46 AM1/19/08 11:13:46 AM
3
How to use the M MODE button
If you press M MODE, the unit goes into functions
mode, then the number buttons and ¢/4
buttons work as different function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To use these buttons for their origina functions
again after pressing M MODE, wait for 5 seconds
without pressing any of these buttons until the
functions mode is cleared or press M MODE again.
Detaching the contro pane
Attaching the contro pane
CONTENTS
Contro pane .................................. 4
Remote contro er — RM-RK50 ........... 5
Getting started ................................ 6
Basic operations ................................................... 6
Radio operations ............................. 7
Disc operations ................................ 8
Playing a disc in the unit ..................................... 8
Sound adjustments .......................... 10
Genera settings — PSM .................. 11
Maintenance ................................... 13
More about this unit ........................ 14
Troub eshooting .............................. 16
Specifications .................................. 17
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• top the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
EN02-07_KD-G336S[UI]f.indd 3EN02-07_KD-G336S[UI]f.indd 3 1/19/08 11:13:51 AM1/19/08 11:13:51 AM
4
u RND (random) button
i M MODE button
o (control panel release) button
; Disc information indicators—
TAG (Tag information), (trac /file), (folder)
a DISC indicator
s Playbac mode / item indicators—RND (random),
(disc), (folder), RPT (repeat)
d Tuner reception indicators—MO (monaural),
ST (stereo)
f S.BASS (super bass) indicator
g EQ (equalizer) indicator
h Tr (trac ) indicator
j Source display / Volume level indicator / Time
countdown indicator
k Main display
l Sound mode (iEQ: intelligent equalizer)
indicators—JAZZ, ROCK, HIP HOP, CLASSIC, POPS,
USER
Parts identification
Display window
Control panel
1 0 (eject) button
2 Loading slot
3 (standby/on/attenuator) button
4 Remote sensor
DO NOT expose the remote sensor to strong light
(direct sunlight or artificial lighting).
5 SOURCE button
6 Display window
7 BAND button
8 EQ (equalizer) button
9 ¢/4 buttons
p Control dial
q SEL (select) button
w DISP (display) button
e MO (monaural) button
r SSM (Strong-station Sequential Memory) button
t Number buttons
y RPT (repeat) button
EN02-07_KD-G336S[UI]f.indd 4EN02-07_KD-G336S[UI]f.indd 4 2/13/08 2:44:29 PM2/13/08 2:44:29 PM
5
Remote controller — RM-RK50
Insta ing the ithium coin battery
(CR2025)
Aim the remote contro er direct y at the remote
sensor on the unit. Make sure there is no obstac e
in between.
Warning:
• Do not install any battery other than CR2025 or
its equivalent; otherwise, it may explode.
• Do not leave the remote controller in a place
(such as dashboards) exposed to direct sunlight
for a long time; otherwise, it may explode.
• tore the battery in a place where children
cannot reach to avoid risk of accident.
• To prevent the battery from over-heating,
cracking, or starting a fire:
– Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
– Do not leave the battery with other metallic
materials.
– Do not poke the battery with tweezers or similar
tools.
– Wrap the battery with tape and insulate when
throwing away or saving it.
Main e ements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5 U (up) / D (down) ∞ buttons
• Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the MP3/WMA discs.
3 VOL – / VOL + buttons
• Adjusts the volume level.
4 OUND button
• elects the sound mode (iEQ: intelligent
equalizer).
5 OURCE button
• elects the source.
6 2 R (reverse) / F (forward) 3 buttons
• earches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the tracks if pressed briefly.
EN02-07_KD-G336S[UI]f.indd 5EN02-07_KD-G336S[UI]f.indd 5 1/19/08 11:13:53 AM1/19/08 11:13:53 AM
6
Basic settings
• ee also “General settings — P M” on pages 11 and
12.
1
2
1 Cance ing the disp ay demonstrations
elect “DEMO,” then “DEMO OFF.”
2 Setting the c ock
elect “CLOCK H” (hour), then adjust the hour.
elect “CLOCK M” (minute), then adjust the
minute.
3 Finish the procedure.
To check the current c ock time whi e the
power is turned off
Clock time is shown on the
display for about 5 seconds. ee
also page 12.
Getting started
Basic operations
~ Turn on the power.
Ÿ
* You cannot select “CD” as the playback source if
there is no disc in the unit.
For FM/AM tuner
⁄ Adjust the vo ume.
@ Adjust the sound as you want. (See
pages 10 and 11.)
To drop the vo ume in a
moment (ATT)
To restore the sound, press the
button again.
To turn off the power
Volume level appears.
EN02-07_KD-G336S[UI]f.indd 6EN02-07_KD-G336S[UI]f.indd 6 1/19/08 11:13:54 AM1/19/08 11:13:54 AM
7
When an FM stereo broadcast is hard to
receive
Reception improves, but stereo effect will be lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO indicator
goes off.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequentia
Memory)
1 Se ect the FM band (FM1 – FM3) you want to
store into.
2
3
“ M” flashes, then disappears when automatic
presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Radio operations
~
Ÿ
Start searching for a station.
When a station is received,
searching stops.
To stop searching, press the
same button again.
To tune in to a station manua y
In step above...
1
2 Se ect a desired station frequency.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Lights up when monaural mode is activated.
EN02-07_KD-G336S[UI]f.indd 7EN02-07_KD-G336S[UI]f.indd 7 1/19/08 11:13:55 AM1/19/08 11:13:55 AM
8
Disc operations
Playing a disc in the unit
~ Turn on the power.
Ÿ
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject the
disc
• Press SOURCE to listen to
another playback source.
To fast-forward or reverse
the track
To go to the next or
previous tracks
To go to the next or previous folders (only
for MP3 or WM discs)
Manual presetting
E .: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
1
2
3
Listening to a preset station
1
2 Select the preset station (1 – 6) you want.
To check the other information while
listening to an FM or M station
Preset number flashes for a while.
Clock Ô Frequency
EN08-13_KD-G336S[UI]f.indd 8EN08-13_KD-G336S[UI]f.indd 8 1/19/08 11:14:10 AM1/19/08 11:14:10 AM
9
To locate a particular track (for CD) or folder
(for MP3 or WM discs) directly
To select a number from 01 – 06:
To select a number from 07 – 12:
• To use direct folder access on MP3/WMA discs, it
is required that folders are assigned with 2-digit
numbers at the beginning of their folder names—
01, 02, 03, and so on.
To select a particular track in a
folder (for MP3 or WMA disc):
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Changing the display information
While playing an audio CD or a
CD Text
While playing an MP3 or a WM disc
• When “T G DISP” is set to “T G ON”
(see page 12)
• When “T G DISP” is set to “T G OFF”
: Clock with the current track number
: Elapsed playing time with the current
track number
: Corresponding indicator lights up on the
display
*1 If the current disc is an audio CD, “NO NAME” appears.
*2 If an MP3/WMA fi e does not have Tag information,
fo der name and fi e name appear. In this case, the
TAG indicator wi not ight up.
EN08-13_KD-G336S[UI]f.indd 9EN08-13_KD-G336S[UI]f.indd 9 1/19/08 11:14:15 AM1/19/08 11:14:15 AM
10
Sound adjustments
You can select a preset sound mode suitable to the
music genre (iEQ: intelligent equalizer).
Indication (For)
B S*1MID*2TRE*3S.BS*4
USER
(Flat sound) 00 00 00 OFF
ROCK
(Rock or disco music) +03 00 +02 ON
CL SSIC
(Classical music) +01 00 +03 OFF
POPS
(Light music) +02 +01 +02 OFF
HIP HOP
(Funk or rap music) +04 –02 +01 ON
J ZZ
(Jazz music) +03 00 +03 OFF
*1 : Bass; *2 : Middle; *3 : Treble; *4 : Super bass
djusting the sound
You can adjust the sound characteristics to your
preference.
1
2
Preset values
Selecting the playback modes
You can use only one of the following playback modes
at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode Plays repeatedly
TRK RPT : The current track.
FLDR RPT * : All tracks of the current folder.
RPT OFF : Cancels.
7 Random play
Mode Plays at random
FLDR RND * : All tracks of the current folder,
then tracks of the ne t folder and
so on.
DISC RND : All tracks of the current disc.
RND OFF : Cancels.
* On y whi e p aying an MP3 or a WMA disc.
: Corresponding indicator lights up on
the display
EN08-13_KD-G336S[UI]f.indd 10EN08-13_KD-G336S[UI]f.indd 10 1/19/08 11:14:16 AM1/19/08 11:14:16 AM
Indice
Altri manuali JVC Ricevitore per auto
JVC
JVC KD-G126 Manuale utente
JVC
JVC KD-A725 Manuale utente
JVC
JVC KW-R900BT Manuale utente
JVC
JVC KD-AR7000 Manuale utente
JVC
JVC KD-R423 Manuale utente
JVC
JVC KD-G120 - Radio / CD Player Manuale utente
JVC
JVC KD-R336 Manuale utente
JVC
JVC KD-S1501 Manuale utente
JVC
JVC KD-G416 Manuale utente
JVC
JVC KD-S621 Manuale utente
