JVC SPEAKER SYSTEM SP-SB101 Manuale utente

LVT1304-002A

[US]

SP-SB101

INSTRUCTIONS: SPEAKER SYSTEM

Connection / /

1

2

3

ENGLISH

Thank you for purchasing JVC speaker.

Before you begin using the speaker, please read the

instructions carefully.

SP-SB101 is not magnetically shielded.

If it is located nearby the TV or monitor, it will probably cause

color distortion on the screen.

To avoid this, do not place the speaker nearby the TV or

monitor.

7Caution

Be sure to insert the core of the speaker cord fully into the

terminal.

When installing the speaker on the wall;

• Be sure to have it installed on the wall by a qualified

personnel.

DO NOT install the speaker on the wall by yourself to avoid

unexpected damage from its falling off the wall due to

incorrect installation or weakness in wall structure.

• Care must be taken in selecting a location for speaker

installation on a wall. Injury to personnel or damage to

equipment may result if the speaker installed interfere with

daily activities.

7Specifications

Type : 1-way bass-reflex type

Speakers : 8 cm cone

Power handling capacity : 100 W

Impedance : 6 Ω

Frequency range : 80 Hz – 20 000 Hz

Sound pressure level : 73 dB/W•m

Dimensions (W ×H ×D) : 111.5 mm ×148 mm ×106.5 mm

Mass : 0.44 kg

Accessories : Speaker cord (10 m)

Design and specifications subject to change without notice.

Twist / /

Remove / /

Through the hole / /

Black / / Red / /

Black / / White / /

01-02_SP-SB101_002A_1.p65 2/16/05, 4:02 PM1

0305NSMMDWHCE

EN, CS, AR

© 2005 Victor Company of Japan, Limited

01-02_SP-SB101_002A_1.p65 2/16/05, 4:02 PM2
