Subwoofers

drvn Series Subwoofers

400W

RMS

1400W

Peak Power

✹High Response

(High-Compression Urethane Surround)

High-Compression Urethane Surround allows

woofers to produce a more linear excursion

resulting in more bass output.

Dual Voice

Coil

Single Voice

Coil

The drvn Series subwoofers deliver dynamic sound with more aggressive-looking design. The dual voice coil CS-GD1210 comes

with a large magnet for powerful sound, while the butyl rubber surround provides strong deep bass. The CS-G1210 features

superior sound in the most audible range with quick-responding high-compression urethane surround.

Key Benefits

CS-GD1210

12” (30cm) Dual Voice Coil Subwoofer Unit

✹High Sound Pressure

(Butyl Rubber Surround)

Butyl Rubber Surround allows long-throw

linearity with control and stability at the

excursion limits.

CS-G1210

12” (30cm) Subwoofer Unit

250W

RMS

1200W

Peak Power

Sound Dynamics

Design

Sound Dynamics

Design

Strong &

Deep Bass

Strong &

Deep Bass

CS-GD1210

CS-G1210

Butyl Rubber

Surroound

Strong &

Quick Bass

Strong &

Quick Bass

CS-GD1210 CS-G1210

High-Compression

Urethane Surround

NTK-0929-19

Key Specifications

CS-GD1200 CS-G1200

Size 12” (30 cm) 12” (30 cm)

Power Handling Capacity (Peak) 1400W 1200W

Power Handling Capacity (RMS) 400W 250W

Sensitivity 86.5dB/W.m 87.5dB/W.m

Frequency Response 20 - 2,000Hz 25 - 2,500Hz

Impedance 4Ω+ 4Ω(Dual Input) 4Ω

Fs 39.8Hz 41Hz

Qts 0.837 0.961

Vas 1.23 ft3 1.77 ft3

Magnet Mass 62.6 oz 39.0 oz

Hole Cutout Diameter Dia. 10 31/32” (278 mm) Dia. 10 31/32” (278 mm)

Mounting Depth 5 25/32” (146.4 mm) 5 13/32” (136.6 mm)

Weight (NET) 5.1kg (11.3 lbs.) 3.7kg (8.2 lbs.)

✹Cutaway View

Dimensions

Recommended Enclosure Size

(CS-GD1210/G1210)

0.75-1.5 cu/ft

(1 cu/ft recommended)

Sealed Type

1-1.8 cu/ft

(1.2 cu/ft recommended)

Ported Type

Recommended System

CS-GD1210 CS-G1210

CS-VS608 CS-VS608

Front

Rear

Front

Rear

CS-V6938 CS-V6938

KS-AX3204

drvn Series Subwoofers

KW-AV71BT

KS-AX3201D

CS-GD1210

13 inch (330 mm)

12-1/16 inch (306 mm)

7/32 inch (5.2 mm) x 8 HOLES

21/32 inch

(16.6 mm)

5-25/32 inch

(146.4 mm)

6-5/32 inch

(156 mm)

10-29/32 inch (276.5 mm)

CS-G1210

13 inch (330 mm)

12-1/16 inch (306 mm)

7/32 inch (5.2 mm) x 8 HOLES

21/32 inch

(16.6 mm)

5-13/32 inch

(136.6 mm)

10-29/32 inch (276.5 mm)

5-17/32 inch

(140 mm)

CS-GD1210

3D Structure and Sputtering

Olefin Diaphragm

Aggressive Design Gasket

Butyl Rubber Surround

Pulp Cone

High Linearity Spider

Dual Voice Coil

Long Stroke and Vented Pole Yoke

Large Strontium

Magnet 62.6 oz
