ENGLISH
Connections:
a.)
Power Adapter
Audio Out (To speaker)
Audio In (To PC audio)
8 pin VGA in (To PC)
VGA out (To PC monitors)
• PIPFunction:Completeconnections(1)–(5).Playgames,workandchatwithyourfriendsonMSNallat
thesametime.
b.)
• ComponentVideoInput
• MVIInput
(Composite/S-video)
• LEDlight
Redlight:Stand-bymode
Greenlight:Poweron
Touch Button Panel
1. PowerOn/Off
2. SwitchSource/Enter
3~4. OSDmenu(Press3and4simultaneously)/Navigation-up/down
5~6. VolumeDown/Up/Navigation-left/right
3
Remote Control:
19
10
11
12
13
14
15
2
3
4
5
6
7
8
1. Mute
2. Menu
3. Navigationbutton
4. ESC
5. Source
6. Favorite
7. Numberkey
8. Recall
9. PowerOn/Off
10.
Preview
11.OK
12.Sleep
13.
Stereo
14.PIP
15.Information
Thesefunctionsareoptionaldependingonthemodelofthedevice
Start Screen:
Start Screen Setup
Whenyoupoweronthegamebox,thestartscreenwillappear.
YoucanchooseyourlanguageforthemenuandOSDsettingshere.
Advanced OSD Settings:
Therearethreesections:Sound,ColorandSetup.
PresstheSetupbuttonontheremotecontrolanditwilldisplaythemainmenuandsubmenuaslistedbelow.
1. Presstoselectanitem.
2. PressOKtostartediting
3. Movebuttons to adjust or edit it.
4. PressESCtoexitsettings.
Sound:
Chooseanaudiosource.Youcanselectavideosource(Composite,S-videoandComponentvideo)orPC
sourcefromthissetting.
4
MainMenu Submenu Function
Sound
Balance AdjustbalancevolumeofLeftorRightspeakers.
Background • VideoMode:ThesoundsourcefromVideoinputs.
• PCMode:ThesoundsourcefromPC.
Color:
YoucanadjustBrightness,Sharpness,Saturation,ContrastandHueforbestpicturequality.
MainMenu Submenu Function
Color
Brightness Adjustthebrightnessoftheimage.
Pressthebutton to adjust it.
Contrast Adjustthecontrasttochangetheamountofblackandwhiteintheimage.
Pressthebuttontodecreaseorincreaseit.
Saturation
Adjustvideoimagefromblackandwhitetofullysaturatedcolour.
Pressthebuttontodecreaseorincreasetheamountofcolourinthe
image.
Sharpness Adjustthesharpnessoftheimage.
Pressthebuttontodecreaseorincreaseit.
Hue
Adjustthecolourbalanceofredandgreen.
Pressthebuttontodecreaseorincreasetheamountofgreeninthe
image.
Setup:
Inthissection,youcansetupyourlanguages,resolutionadjustmentandOSDposition.
MainMenu Submenu Function
Setup
OSDposition Presstheor buttontomovetheOSDintherightposition.
DisplayModes Selectadisplayresolutionformonitors.
Languages SelectalanguagefortheOSDmenu.
Transparency PressthebuttontoadjustthetransparencytomaketheOSDeasier
to see.
Sleep Thissleeptimerallowsyourboxtoturnoffautomatically.
Version Firmwareversion.
Active PIP:
Press (PIPfunction)ontheremotecontroltoactivatethePIPfunction.TomakethePIPmodework
properly,makesureyourcomputer’sVGAresolutionandfrequencyareconguredaccordingtofollowing
table.
Resolution Frequency(Hz)
800x600 60.75
1024x768 60.75
1280xl024 60.75
1440x900 60.75
5
Resolution Frequency(Hz)
1600x1200 60
1680x1050 60
1920x1080 60
1920x1200 60
*Note:ThePIPfunctiondoesnotworkwithcomponentconnection.
Adjust PIP:
Adjust PIP size
PresstheOKbuttonontheremotecontroltoadjustthePIPwindowsizes.Therearethreedifferentsizesof
PIPwindowstochoosefromasshowninthefollowingpictures(1/4,1/9,1/16).
1/4PIPsize 1/9PIPsize 1/16PIPsize
Move PIP position
Press (Menubutton)andthenthedirectionkeyontheremotecontroltomovethePIPwindow’sposition.
Safety precautions:
Toreduceriskofelectricshock,thisproductshouldONLYbeopenedbyan
authorizedtechnicianwhenserviceisrequired.Disconnecttheproductfrommains
andotherequipmentifaproblemshouldoccur.Donotexposetheproducttowaterormoisture.
Maintenance:
Cleanonlywithadrycloth.Donotusecleaningsolventsorabrasives.
Warranty:
Noguaranteeorliabilitycanbeacceptedforanychangesandmodicationsoftheproductordamagecaused
duetoincorrectuseofthisproduct.
General:
Designsandspecicationsaresubjecttochangewithoutnotice.
Alllogosbrandsandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveholdersand
areherebyrecognizedassuch.
Keepthismanualandpackagingforfuturereference.
Attention:
Thisproductismarkedwiththissymbol.Itmeansthatusedelectricalandelectronicproducts
shouldnotbemixedwithgeneralhouseholdwaste.Thereisaseparatecollectionssystemforthese
products.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
6
Declaration of conformity
We,
NedisB.V.,DeTweeling28,5215MC,’s-Hertogenbosch
TheNetherlands
Tel.:0031735991055
Email:[email protected]
Declarethatproduct:
Brand:KÖNIG ELECTRONIC
Model:GAME-HDBOX1
Description:FullHDGameBox
Isinconformitywiththefollowingstandards:
EN55022: 2006+A1: 2007, Class B EN61000-3-2: 2006 EN61000-3-3: 2008
EN55024: 1998+A1: 2001+A2: 2003 IEC61000-4-2: 2008 IEC61000-4-3: 2008
IEC61000-4-3-2008 IEC61000-4-4: 2004 IEC61000-4-5: 2005
IEC61000-4-6: 2008 IEC61000-4-8: 2009 IEC61000-4-11: 2004
IEC60950-1 IEC62321: 2008
EUDirective(s):
2004/108/EC
2005/32/EC
‘s-Hertogenbosch,20-6-2010
Mrs.:J. Gilad
PurchaseDirector
Copyright©
