König SEC-APW10 Manuale utente
SEC-APW10
WIRELESS ALARM
Description PIR sensor:
1. PIR Sensor
2. Battery LED Indicator
3. Battery Compartment
4. AC Adapter Socket
Battery installation:
1. The battery compartment is
accessed from the rear of the
PIR sensor by removing the
screw from the bottom and lifting
the back cover.
2. Insert 4x AA size batteries
(not included) according the
correct polarity and replace the
back cover.
Wall Mounting:
1. Remove the back plate.
2. Mount the back plate to the desired position to the wall.
3. Clip the unit to the back plate.
4. Secure the PIR sensor to the back plate by fastening the screw
on the bottom.
ENGLISH
INSTRUCTIONS
Description alarm:
1. Siren
2. Switch for alarm/chime
3. Mounting hole
4. AC Adapter Socket
5. Battery Compartment
Battery Installation:
1. Slide the cover off from the backside of the alarm.
2. Insert 3x AA batteries in the battery compartment following the
polarity diagram inside of the battery compartment. Replace the
cover.
Switch for alarm/chime:
Chime Position: a chime sounds 3 times each time
motion is detected.
Alarm Position: an alarm sounds continuously when
motion is detected. Alarm will automatically turn of after
+/-30 seconds.
Off Position: no signal will sound when motion
detected.
Placement of the alarm:
The alarm can be placed anywhere within 15~20m range of the PIR
sensor.
Alarm operation:
The PIR sensor will automatically activate the alarm when
movement is detected in the secured area. When activated,the
alarm will sound.
Settings:
The system has 3 selectable built-in security codes. Therefore it’s
possible to use up to 3 systems in one area. You may change the
codes to prevent interaction when using more than one pair of
systems.
To change the security code of the PIR sensor:
1. Open the back plate of the PIR sensor.
2. Locate the switch in the battery compartment
(see figure A).
3. Set the switch in desired position.
4. Close the back plate.
To change the security code of the alarm:
1. Open the back plate of the alarm.
2. Locate the switch in the battery compartment
(see figure B).
3. Set the switch in desired position.
4. Close the back plate.
It’s important to select the same code settings on the PIR sensor
and alarm in order to establish correct communication
Remark: if the LED indicator is constantly on, it means that the
batteries need to be replaced.
Warning:
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician if service is required. Do not
expose the product to water of moisture.
Warranty:
No guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect use
of this product.
General:
Designs and specifications are subject to change without notice.
www.konigsecurity.info
