Kärcher B 120 W Manuale utente

QUICKSTART

5.965-499.0 07/14

B 120 W

몇WARNING

Theseareonlybriefinstructions!Pleasereadtheoperatinginstructionsaccompanying the appliancepriorto using

or maintaining the appliance.

The non-compliance with the operating and safety instructions may lead to damage of the appliance and to risks

for the operator and other persons.

Start up

1AB CA Unplug the charger from the mains.

Wind the mains cable around the cable

holders.

B Fresh water

Open the closure of the fresh water tank.

Fill up fresh water (maximum 60 °C) until

the lower edge of filling nozzle.

C With automatic filling system

"Auto Fill-In" fresh water tank:

Connect the hose to the automatic filling

system and open the water supply

(max. 60 °C, max. 5 bars).

2A B A Model with dosing equipment "Dose"

Place the detergent bottle into the holder.

Close the bottle lid.

Insert the suction hose of the dosing equip-

ment into the bottle and screw on the lid.

B Model without dosing equipment "Dose"

Add the detergent to the fresh water reser-

voir.

QUICKSTART

5.965-499.0 07/14

Operation

A Turn the program selection switch to "OFF".

B Plug in the Intelligent Key.

C Preselectthe speedon thedrive speedrotary

knob.

D Turn the programme selection switch to

transport mode.

E Release parking brake.

F Drive forwards:

Press the driving lever to the front.

G Drive backwards:

Press the driving lever to the rear.

Operation

2A B Cleaning Programs

A eco!efficiency mode

Wet clean the floor and vacuum up dirt water.

B Normal mode

Wet clean the floor and vacuum up dirt water.

C Increased brush contact pressure

Wet clean the floor (with increased brush

contact pressure) and vacuum up dirt water.

D Intense mode

Wet clean the floor and allow the detergent to

react.

E Vacuum mode

Suck in the dirt fleet.

F Polishing mode

Polishing the floor without the application of

liquid.

3AA Set the water quantity at the regulating valve

according to the dirt level and the type of

flooring.

QUICKSTART

5.965-499.0 07/14

Finish operation

1BCA Turn the program selection switch to "OFF".

B Remove the Intelligent Key.

2ABA Drain water.

B Remove bulk waste container and empty it.

3AB A Remove the coarse dirt sieve from the

wastewater reservoir and clean it.

B Check the fluff filter, clean if required

4AB A Press the lock of the wastewater reservoir

in and close the cover of the wastewater

reservoir so that a gap remains open to

facilitate drying.

B Lock parking brake.
