KAM Mini Par 12 USB Manuale utente
Version 1.0
Mini Par 12 USB
KML409
1
Unpacking Instructions
Read Manual before Operation
Please note the warnings in bold which will ensure the safe and smooth operation. These
warnings are important to a certain extent.
Attention! Indicates a skill or other useful information for special situations.
Caution! Prevent damage or injury from incorrect operation.
Warning Data
Carefully unpacking the carton, checking contents to ensure that all parts are in good
condition. Inform the shipper immediately and retaining packing
material for inspection if any parts damaged from shipping or device damaged.
Keep packing materials as evidence for shipper’s confirmation.
Attention!
This unit is in perfect condition before delivery; please check all accessories when
unpacking the unit. User should follow this user manual to operate this unit, and make
sure that you are clear on all LED safety information and unit operation before power it on.
Any wrong operation will make this unit out of warranty.
Carefully moving after receiving it, checking whether there is any damage from shipping,
and all the accessories in it.
Before operating this device, please read the manual thoroughly, and retain for future use.
Unpacking Instructions
Warning!
If the external flexible cable or cord of this luminaire is damaged, it should be replaced by a
special cord or cord exclusively available from the manufacturer or his service agent.
Shields, lenses or ultraviolet screens should be changed if they have become visibly
damaged to such an extent that their effectiveness is impaired, for example by cracks or
deep scratches.
The lamps should be changed if it has become damaged or thermally deformed.
NAME
LED system
Power Adaptor
USB A to Type-C cable
IR remote controller
User manual
1set
1pc
1pc
1pc
1pc
QTY
2
Safety Instructions
Safety Instructions
0.2in
To protect the environment, please try to recycle the packing material as much as possible.
The KML409 is for indoor use only, IP20. Use only in dry locations. Keep this device away
from rain and moisture, excessive heat, humidity and dust. Do not allow contact with water
or any other fluids, or metallic objects.
Don’t throw this product away just as general trash, please deal with the product follow the
abandon electronic product regulation in your country.
Locate the fixture in a well ventilated spot, away from any flammable materials and/or
liquids. The fixture must be fixed at least 50cm from surrounding walls.
To avoid condensation to be formed inside, allow this unit to adapt to the surrounding
temperatures when bringing it into a warm room after transport. Condensation
sometimes prevents the unit from working at full performance or may even cause
damages.
Don’t cover any ventilation openings as this may result in overheating.
Don’t install it on flammable object.
Don not use it when maximum ambient temperature is higher than 40 degree.
Unplug the unit when it is not used for a longer time or before replacing the bulb.
Don’t open the top cover to avoid unit damage.
Please use the original packing when the device is to be transported.
Never expose the lens to direct sunlight, even for a short
period, This may damage the light effect or even cause fire!
◆
◆
◆
◆
◆
◆
◆
Overhead Rigging
3
Attention! The installation must be carried out by qualified service personal only.
Improper installation can result in serious injuries and /or damage to property.
Overhead rigging required extensive experience! Working load limits should be
respected, Certified installation materials should be used, the installed device should
be inspected regularly for safety.
Make sure the area below the installation place is free from unwanted persons during
rigging, de-rigging and servicing.
Locate the fixture in a well ventilated spot, far away from any flammable materials
and/or liquids. The fixture must be fixed at least 50cm from surrounding walls
The device should be installed out of reach of people and outside areas where persons
may walk by or be seated.
The device should be well fixed; a free swinging mounting is dangerous and may not
be considered!
Do not cover any ventilation opening as this may result in overheating
Before the first time use, it must be inspected by professional staff to make sure safety,
inspection regularly every year.
◆
◆
◆
◆
Please use the included power adaptor and check that
power outlet to make sure the input voltage and frequency
are the same as the rated. This device can be powered by
DC 5V/2A through USB Type-C plug that is most
popular charger for mobile phones or other electronic
devices.
Power Adaptor
◆
◆
Before rigging make sure that installation area can hold the 10 times weight of device.
Using the steel rope which can hold 12 times weight of device, through the eye-bolt for
assisting hang installment.
Adjust Angle
ON/OFF
Product diagram
4
No.
1
2
3
4
5
Function
Operation instructions
Name
IR receiver
Hanging bracket
Lense
USB Type-C socket
Modes
The receiver of remote controller
For hanging and angle adjustment
Color effect output
Connect to the power adaptor or PartySet plug
Auto mode
Sound mode
Green and Blue 30%
Red
Green
Green and Blue
Red and Green 30%
Blue
Red 55% and Green 30%
Red and White
Red and Green
White
IR Controller
4
1
2
3
5
Close/Auto/Sound
WhiteBlue, Green, Red,
5
Product Infomation
Product parameter
Model
Light source
Operating modes
Dimensions
Weight
Power input
Power consumption
Maximum working temperature
Mini Par-12 USB-C4
Auto/Sound/IR remote control
156×53.6×171mm
0.25kg
5V/2A USB Type-C
14W
104ºF(40ºC)
Product description
The KAM KML409 is a fantasy LED effect light that includes powerful RGBW four-color LED to
creates constantly rotating multicolor light beams. It can be used with fog or haze to create the
party atmosphere and can be operated in Auto show, Sound activated or IR remote modes. It
can work as one controlled unit of the PartySet system as well.
156mm
171mm
53.6mm
©2022 JHS. Specifications are subject to change without prior notice. Made in China.
6
UK DISTRIBUTOR
John Hornby Skewes & Co. Ltd.
Salem House, Parkinson Approach, Garforth,
Leeds LS25 2HR, United Kingdom.
www.jhs.co.uk
UK
CA c� ✓ � •
-•
� RoHS
