Kärcher Puzzi 8/1 C Manuale utente

QUICKSTART

5.964-158.0 02/12

Warning

These are only brief instructions! Please read and comply with these instructions prior to using or servicing your

appliance.

The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers

for the operator and other persons.

Start up

1ABCA Insert the coupling of the fresh water

hose into the fresh water connection

of the appliance and lock into place.

B Insert the suction hose into the suction

hose connection on the appliance.

2A B A Connect the fresh water hose to the

elbow of the manual nozzle.

B Connect the suction hose to bender of

the manual nozzle.

Operation

1ABCA Remove the lid.

B Remove the wastewater container from

the appliance.

C Refill the wastewater container with fresh

water.

2ABCA Fill in fresh water.

B Fill detergent solution/the tab including i

ts water soluble packaging into the fresh

water reservoir. The fill level must not

exceed the "MAX" mark. After 5 minutes,

the tab will be completely dissolved.

C Insert dirt water reservoir into the appliance

and attach lid.

3ABCA Press the spray switch to turn on the

detergent pump.

B Press the suction switch to turn on the

suction turbine.

C If the dirt water reservoir is full, switch

off the suction and spray switches.

Puzzi 8/1 C

1EN

QUICKSTART

5.964-158.0 02/12

4A B A Use the lever on the bender to spray on

detergent solution.

B Spray and suction off detergent solution

in one work cycle.

5A B A Highly soiled spots should be presoaked

and the detergent solution should soak

5 to 10 minutes.

B Vacuum up the detergent solution in the

course of the second work step.

Finish operation

1ABCA Switch off the vacuuming and spraying

switches.

B Remove the lid.

C Empty the wastewater reservoir.

2ABCA Fill the fresh water tank with clear water

and to rinse/clean the appliance.

B Spray the accessories into the wastewater

tank, along with fresh water

(approx. 1-2 minutes)

C Empty the fresh water reservoir and

switch the appliance off.

D Empty the wastewater reservoir.

3ABCA Shortly activate the lever on bender to

decrease the pressure. Pull the coupling

backwards.

B Place the lid loosely to let the appliance dry

out.

Operation

2 EN
