KEBCO C6 E22 BM-RVL Manuale utente

EMBEDDED IPCS

INSTRUCTIONS FOR USE | E22 BOX/PANEL

Original Manual

Document 20146638 EN 01

PREFACE

Preface

The described hard- and software are developments of the KEB Automation KG. The

enclosed documents correspond to conditions valid at printing. Misprint, mistakes and

technical changes reserved.

Signal words and symbols

Certain operations can cause hazards during the installation, operation or thereafter.

There are safety informations in the documentation in front of these operations. Security

signs are located on the device or machine. A warning contains signal words which are

explained in the following table:

DANGER Dangerous situation, which will cause death or serious injury in case of

non-observance of this safety instruction.

WARNING Dangerous situation, which may cause death or serious injury in case of

non-observance of this safety instruction.

CAUTION Dangerous situation, which may cause minor injury in case of non-ob-

servance of this safety instruction.

NOTICE Situation, which can cause damage to property in case of non-obser-

vance.

RESTRICTION

Is used when certain conditions must meet the validity of statements or the result is

limited to a certain validity range.

Is used when the result will be better, more economic or trouble-free by following

these procedures.

More symbols

► Thisarrowstartsanactionstep.

• / - Enumerations are marked with dots or indents.

=> Cross reference to another chapter or another page.

Note to further documentation.

www.keb.de/nc/search

PREFACE

Laws and guidelines

KEB Automation KGconrmswiththeECdeclarationofconformitywiththeCEmark

on the unit name plate, that the device complies with the essential safety requirements.

The EC declaration of conformity can be downloaded on demand via our website. Fur-

therinformationisprovidedinchapter"Certication".

Warranty

The warranty on design, material or workmanship for the acquired device is given in the

current terms and conditions.

Hereyouwillndourcurrenttermsandconditions.

www.keb.de/terms-and-conditions

Furtheragreementsorspecicationsrequireawrittenconrmation.

Support

Through multiple applications not every imaginable case has been taken into ac-

count. If you require further information or if problems occur which are not treated de-

tailed in the documentation, you can request the necessary information via the local

KEB Automation KG agency.

The use of our units in the target products is beyond of our control and therefore

exclusively the responsibility of the machine manufacturer, system integrator or

customer.

Theinformationcontainedinthetechnicaldocumentation,aswellasanyuser-specic

advice in spoken and written and through tests, are made to best of our knowledge and

information about the application. However, they are considered for information only

without responsibility. This also applies to any violation of industrial property rights of a

third-party.

Selection of our units in view of their suitability for the intended use must be done gener-

ally by the user.

Tests can only be done within the application by the machine manufacturer. They

must be repeated, even if only parts of hardware, software or the unit adjustment

are modied.

The customer may use the instruction manual as well as further documents or parts from

it for internal purposes. Copyrights are with KEB Automation KG and remain valid in its

entirety.

Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their

respectiveownersandarelistedinthefootnoteontherstoccurrence.
