Ken A Vision T-1941 Manuale utente

Comprehensive Polarizing

Scope

Instruction Manual

T-1941

Thank you for purchasing a Comprehensive Polarizing

Scope

Packing List

Dust Cover

Fuse

10x Widefield Eyepiece with Graduated Cross Hair

Instruction Manual

Warranty Card & Sheet

Application

The Ken-A-Vision Comprehensive Polarizing Scope has a multitude

of applications. A primary use of polarizing microscopes is in geological

applications such as the studying of rock thin sections. A polarizing

microscope used with anisotropic materials allows the study of the

absorption color and boundaries between minerals of differing refractive

indices. Additionally, isotropic and anisotropic materials can be

differentiated in specimens such as natural and industrial minerals

(manufactured, refined or extracted). Every day materials such as

ceramics, polymers, and cements can be examined for their structure.

More recently many highly ordered biological materials such as wood,

starch, urea, DNA and collagen reveal new structural properties when

examined under polarized light.

Polarized light is a contrast-enhancing methodology that can improve

the quality of images obtained with birefringent materials, and may be

better than images obtained with darkfield or brightfield illumination,

phase contrast or fluorescence microscopy.

The Ken-A-Vision Comprehensive Polarizing Scope may be used

both as a polarizing microscope (both analyzer and polarizer filters in light

pathway) or as a brightfield microscope with the filters rotated out of

position.

SPECIFICATIONS

Specifications subject to change without notice

Cross hair reticle (graticule) marks the center of the field of view

Catalog Number T-1941

10x Widefield Eyepiece with cross hair reticle

(graticule) X

Monocular Head X

3 Hole, Reversed Nose Piece X

4x, 10x, 40xR DIN Objective Lenses X

Coarse and Fine Coaxial Focal Adjustment X

Rotating Stage with Clips; Marked in 360 ° Increments X

Stage Marked in 360 ° Increments X

Analyzer Filter (may be rotated in or out) X

Polarizer Filter (may be rotated in or out) X

Illuminator 20 Watt Halogen Bulb (with light rheostat) X

Rheostat (variac) for Light Intensity Adjustment X

Adjustable Abbé Condenser X

Iris Diaphragm X

Bertrand Lens Optional

Compensators/Retardation Plates Optional

Microscope Preparation

Open packing box carefully, and lift microscope out of shipping

container. Remove all packing materials on eyepieces, stage, and

illuminator.

Check the coarse focus tension. The knobs are oversized, designed

for better gripping. The coarse (larger) focus knob should turn easily to

change the focus. The stage should move up and down when either the

coarse or fine adjust knobs are turned. Watch the up-down motion of the

stage; it should not drift or slip on its own.

Check the stage stop feature. The stage stop is a knurled thumb

screw with a lock nut found on the main frame, just behind the stage. To

check the stage stop, place a prepared slide in normal position for

viewing. Place the 40x objective into viewing position and move the

coarse focus knob until the object and stage are as close together as they

can be WITHOUT TOUCHING. Look through the eyepiece at the slide,

and get the specimen into focus. The objective should be very close to

the slide, but not touching. If the stage stop is not set correctly, loosen the

locking nut and thumb screw, and reset the stage stop, tightening both

when correct position is attained.

Microscope Use and Instructions

Visit the Ken-A-Vision Web site http://www.ken-a-vision.com/pdf/

MicroscopePrimer.pdf, for a Microscope Primer on general microscope

usage.

Power Switch

Plug your microscope into a power source. This microscope has an

on/off switch at rear right of the microscope. On the left side of the

Microscope is a rheostat for adjustment of light intensity. Be sure it is

turned up once microscope is on.

Rotating Circular Stage

Your Ken-A-Vision Comprehensive Polarizing Scope comes

equipped with a 360-degree rotatable circular stage for performing

orientation studies in polarized light. This stage has a goniometer divided

into 1-degree increments.

It is important that the stage is centered within the optical axis. Find

the two centering knobs located on the front of the stage, sticking out

about 45 degrees from the center line. To center the optical axis, while

looking through the microscope eyepiece, first reduce the iris diaphragm

to its minimum level. Using the adjusting centering knobs while looking

through the eyepiece, be sure that a uniform field of light is present with

no shadows at any edge of the field. The condenser is spring loaded at

the back of the stage and may be pushed in using the knurled center

knob. Once the optical axis is aligned, the diaphragm may now be

reopened to full diameter.

The viewfield of the microscope was factory set, and will rotate with a

little deviation off of center.

Just above the nose piece find a slot in the body tube. Note that it is

positioned between the polarizer and the analyzer polarizing lenses and

by convention runs in a southeast-northwest direction. The primary

purpose of this slot is to allow insertion of an accessory or retardation

plates between the polarizer and analyzer, in a specific orientation with

respect to the polarizer and the analyzer lens vibrational directions.

(Additional notes and descriptions of various kinds of compensators may

be found at www.ken-a-vision.com in a short primer on polarized light and

polarizing microscopy).

Focus

The basic principle involved in Polarizing Microscopy is to take

advantage of the fact that over 90 percent of all solid substances (aniso-

tropic) have optical properties that vary depending upon the orientation of

the incident light with the crystallographic axis. As specimens are exam-

ined under polarized light, there are refractive indices created which are

dependent upon both the propagation direction of light through the sub-

stance and on the vibrational plane coordinates due to the polarizing

lenses. The anisotropic specimen will act as a beam splitter, dividing light

rays into two parts. The polarizing microscope exploits this interference

of the split light rays as they are re-united along the same optical pathway.

Place a specimen slide under the stage clips. Using the coarse

adjust knob, lower the stage until the specimen is in focus. Use the

smaller fine adjust knob to now sharpen the focus and attain maximum

resolution. This first step may be done with the polarizing filters in or out

of the light pathway.

Using the Comprehensive Polarizing Scope - Polarizing

Microscopy

Good practice is to check your Comprehensive Polarizing Scope by

doing the following quick exercise. Do this without any specimen in the

light pathway to be sure that the polarizer and analyzer filters are correctly

aligned.

The polarizer lens is located in a filter holder attached to the

illuminator, below the condenser of the microscope. It is capable of being

rotated 360-degree (360°). Below the front of the polarizer is a small line

indicating a "zero" or starting point. Align the 0° mark on the polarizer

with that 'zero' line. When the polarizer is aligned with that mark, the lens

is said (by convention) to be set to East-West (abbreviated E-W). Now

rotate the analyzer polarizing lens into position within the eye tube. The

convention here is that the vibrational direction of this lens is in the North-

South orientation (abbreviated N-S). In this position, light from the

illuminator will be mostly, if not entirely blocked (extinguished), and if you

look through the microscope it should be dark at even the brightest light

setting.

Now rotate the polarizer and try to determine the point when the most

light comes through the two filters. This should occur at 90°. Total

extinction should reoccur at 180°, and maximum light again at 270° with

total extinction again at 360° or 0°. Accuracy of this alignment is

important, when retardation and/or compensation plates are inserted into

the optical path for measurement purposes.

The iris condenser, supplied as part of the Abbé condenser, controls

the angle of the illumination cone that passes through the microscope's

light pathway. Reducing the opening size of this iris diaphragm

decreases the cone angle and increases the contrast of images

observed. For polarization studies and for greatest accuracy, use the

dimmer (variac) switch to change the intensity of illumination, rather than

the iris diaphragm.

Eyepiece

The widefield eyepiece is locked into place to avoid loss. A set of

crossed, perpendicular lines are mounted in the eyepiece.

The analyzer filter is provided within the eyepiece tube, directly below

the eyepiece. This must be in the eye tube when using the microscope as

a polarizing scope, and may be rotated out of the light line, when using

the scope as a Brightfield illuminated microscope.

Care and Maintenance

Your microscope is a fine precision instrument and should be treated

with care. When not in use, it should be protected from dust by the plastic

cover provided. Lenses and eyepieces should be cleaned periodically

with optical lens tissue which is soft and lint free. Painted surfaces can be

cleaned with a moistened cloth.

Ken-A-Vision has quality technicians on staff to repair or service your

microscopes. Ken-A-Vision recommends service every two years for

optimal life of the product. Contact Ken-A-Vision at 1.816.353.4787,

Extension 5620 for more details.

Technical Specifications for Model No. T-1941

Comprehensive Polarizing Scope

For the technical specifications on the Comprehensive Polarizing Scope,

visit the Ken-A-Vision Web site http://www.ken-a-vision.com/t1941.asp

5615 Raytown Road • Kansas City, MO 64133 U.S.A.

Tel.: 816-353-4787 • Fax: 816-358-5072

email:info@ken-a-vision.com • www.ken-a-vision.com

INS-SC8POL

Accessories

If you are interested in purchasing accessories or replacement parts for

your Comprehensive Polarize Scope visit our Web site,

http://store.kenavision.com/catalog/ or contact your local Ken-A-Vision

Dealer.

Ken-A-Vision reserves the right to make design improvements and other changes in accordance with the

latest technology. There is no obligation to make changes in products already manufactured. Patents

PRODUCT SERVICE

TUV

geprufte

sicherhelt

Indice

Altri manuali Ken A Vision Microscopio

Ken A Vision

Ken A Vision T-19541C Manuale utente

Ken A Vision

Ken A Vision Professor ESH101 Manuale utente

Ken A Vision

Ken A Vision PrepScope T-1252C Manuale utente

Ken A Vision

Ken A Vision Professor Stereo ESH200 Manuale utente

Ken A Vision

Ken A Vision Vision T-2200C Series Manuale utente

Ken A Vision

Ken A Vision Professor ESH101 Manuale utente

Ken A Vision

Ken A Vision VisionScope 2 Manuale utente

Ken A Vision

Ken A Vision Digital Comprehensive Scope 2 Manuale utente

Ken A Vision

Ken A Vision Comparison Scope 2 T-19241C Manuale utente

Ken A Vision

Ken A Vision Professor Stereo ESH200 Manuale utente

Ken A Vision

Ken A Vision T-1953B Manuale utente

Ken A Vision

Ken A Vision T-1754 Manuale utente

Ken A Vision

Ken A Vision VisionScope T-2400 Manuale utente

Ken A Vision

Ken A Vision Comprehensive Scope 2 T-19011C Manuale utente

Ken A Vision

Ken A Vision T-19011C Manuale utente

Ken A Vision

Ken A Vision PupilCAM 1402KEM Manuale utente

Ken A Vision

Ken A Vision Video Flex® except 2000 series Manuale utente

Ken A Vision

Ken A Vision T-1922C Manuale utente

Ken A Vision

Ken A Vision Vision Scope 2 T-22XXX Series Manuale utente

Ken A Vision

Ken A Vision CoreScope T-1701C Manuale utente

Ken A Vision

Ken A Vision Comprehensive T-1901C Manuale utente

Ken A Vision

Ken A Vision Comprehensive Scope 2 Manuale utente

Ken A Vision

Ken A Vision T-1955 Manuale utente

Ken A Vision

Ken A Vision Professor ESH101 Manuale utente

Manuali Microscopio popolari di altre marche

Thermo Scientific

Thermo Scientific Nicolet iN10 Guida

National

National DC3-163 Manuale utente

KERN Optics

KERN Optics OPE-1 Manuale utente

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Manuale utente

Prior

Prior Lux POL Manuale utente

Opitec

Opitec Smartscoop 115615 Manuale utente

KERN

KERN OPO-1 Manuale utente

Topcon

Topcon SP-1P Manuale utente

Motic

Motic PA43 Manuale utente

Leica

Leica DVM5000 Guida utente

MshOt

MshOt MZ62 Manuale utente

KERN Optics

KERN Optics OZR-5 Manuale utente

VWR

VWR VisiScope 384 Series Manuale utente

Nikon

Nikon ECLIPSE E200 POL Manuale utente

Leica

Leica DI C800 Manuale

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuale utente

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuale utente

Olympus

Olympus SZ61 Manuale utente
