INSTRUCTION MANUAL

UHF FM TRANSCEIVER

TK-3501

B62-2606-10

THANK YOU

We are grateful you have chosen KENWOOD for your PMR 446

applications.

This Instruction manual covers only the basic operations of your PMR446

(Private Mobile Radio). Ask your dealer for information on any customized

features they may have added to your radio.

OPERATING CONDITIONS

Open locations (no obstructions) : Up to 9.0 km

Note:

◆The above range is based on ﬁeld testing and may vary with your

operating conditions and individual transceiver.

NOTICES TO THE USER

Refer service to qualiﬁed technicians only.

Safety: It is important that the operator is aware of, and

understands, hazards common to the operation of any

transceiver.

Firmware Copyrights

The title to and ownership of copyrights for ﬁrmware embedded in

KENWOOD product memories are reserved for JVC KENWOOD

Corporation.

PRECAUTIONS

• Do not charge the transceiver and battery pack when they are wet.

• Ensure that there are no metallic items located between the

transceiver and the battery pack.

• Do not use options not speciﬁed by KENWOOD.

• If the die-cast chassis or other transceiver part is damaged, do not

touch the damaged parts.

• If a headset or headphone is connected to the transceiver, reduce

the transceiver volume. Pay attention to the volume level when

turning the squelch oﬀ.

• Do not place the microphone cable around your neck while near

machinery that may catch the cable.

• Do not place the transceiver on unstable surfaces.

• Ensure that the end of the antenna does not touch your eyes.

• When the transceiver is used for transmission for many hours, the

radiator and chassis will become hot. Do not touch these locations

when replacing the battery pack.

• Do not immerse the transceiver in water.

• Always switch the transceiver power oﬀbefore installing optional

accessories.

• The charger is the device that disconnects the unit from the AC

mains line.The AC plug should be readily accessible.

Turn the transceiver power oﬀin the following locations:

• In explosive atmospheres (inﬂammable gas, dust particles, metallic

powders, grain powders, etc.).

• While taking on fuel or while parked at gasoline service stations.

• Near explosives or blasting sites.

• In aircraft. (Any use of the transceiver must follow the instructions and

regulations provided by the airline crew.)

• Where restrictions or warnings are posted regarding the use of radio

devices, including but not limited to medical facilities.

• Near persons using pacemakers.

iii

• Do not disassemble or modify the transceiver for any reason.

• Do not place the transceiver on or near airbag equipment while the

vehicle is running.When the airbag inﬂates, the transceiver may be

ejected and strike the driver or passengers.

• Do not transmit while touching the antenna terminal or if any metallic

parts are exposed from the antenna covering.Transmitting at such a

time may result in a high-frequency burn.

• If an abnormal odor or smoke is detected coming from the

transceiver, switch the transceiver power oﬀimmediately, remove

the battery pack from the transceiver, and contact your KENWOOD

dealer.

• Use of the transceiver while you are driving may be against traﬃc

laws. Please check and observe the vehicle regulations in your area.

• Do not expose the transceiver to extremely hot or cold conditions.

• Do not carry the battery pack with metal objects, as they may short

the battery terminals.

• Danger of explosion if the battery is incorrectly replaced; replace only

with the same type.

• When attaching a commercial strap to the transceiver, ensure that

the strap is durable. In addition, do not swing the transceiver around

by the strap; you may inadvertently strike and injure another person

with the transceiver.

• If a commercially available neck strap is used, take care not to let the

strap get caught on nearby machine.

• When operating the transceiver in areas where the air is dry, it is

easy to build up an electric charge (static electricity).When using

an earphone accessory in such conditions, it is possible for the

transceiver to send an electric shock through the earphone and to

your ear. We recommend you use only a speaker/microphone in

these conditions, to avoid electric shocks.

Information concerning the battery pack:

The battery pack includes ﬂammable objects such as organic

solvent. Mishandling may cause the battery to rupture producing

ﬂames or extreme heat, deteriorate, or cause other forms of

damage to the battery. Please observe the following prohibitive

matters.

• Do not disassemble or reconstruct the battery!

The battery pack has a safety function and protection circuit to avoid

danger. If they suﬀer serious damage, the battery may generate heat

or smoke, rupture, or burst into ﬂame.

• Do not short-circuit the battery!

Do not join the + and – terminals using any form of metal (such as a

paper clip or wire). Do not carry or store the battery pack in containers

holding metal objects (such as wires, chain-necklaces or hairpins). If

the battery pack is short-circuited, excessive current will ﬂow and the

battery may generate heat or smoke, rupture, or burst into ﬂame. It will

also cause metal objects to heat up.

• Do not incinerate or apply heat to the battery!

If the insulator is melted, the gas release vent or safety function is

damaged, or the electrolyte is ignited, the battery may generate heat

or smoke, rupture, or burst into ﬂame.

• Do not leave the battery near ﬁre, stoves, or other heat

generators (areas reaching over 80°C/ 176°F)!

If the polymer separator is melted due to high temperature, an

internal short-circuit may occur in the individual cells and the battery

may generate heat or smoke, rupture, or burst into ﬂame.

• Avoid immersing the battery in water or getting it wet by other

means!

If the battery becomes wet, wipe it oﬀwith a dry towel before use. If

the battery’s protection circuit is damaged, the battery may charge

at extreme current (or voltage) and an abnormal chemical reaction

may occur. The battery may generate heat or smoke, rupture, or

burst into ﬂame.

• Do not charge the battery near ﬁre or under direct sunlight!

If the battery’s protection circuit is damaged, the battery may charge

at extreme current (or voltage) and an abnormal chemical reaction

may occur. The battery may generate heat or smoke, rupture, or

burst into ﬂame.

• Use only the speciﬁed charger and observe charging

requirements!

If the battery is charged in unspeciﬁed conditions (under high

temperature over the regulated value, excessive high voltage or

current over regulated value, or with a remodeled charger), it may

overcharge or an abnormal chemical reaction may occur.The battery

may generate heat or smoke, rupture, or burst into ﬂame.

• Do not pierce the battery with any object, strike it with an

instrument, or step on it!

This may break or deform the battery, causing a short-circuit.The

battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not jar or throw the battery!

An impact may cause the battery to leak, generate heat or smoke,

rupture, and/or burst into ﬂame. If the battery’s protection circuit

is damaged, the battery may charge at an abnormal current (or

voltage), and an abnormal chemical reaction may occur.The battery

may generate heat or smoke, rupture, or burst into ﬂame.

• Do not use the battery pack if it is damaged in any way!

The battery may generate heat or smoke, rupture, or burst into ﬂame.

• Do not solder directly onto the battery!

If the insulator is melted or the gas release vent or safety function is

damaged, the battery may generate heat or smoke, rupture, or burst

into ﬂame.

• Do not reverse the battery polarity (and terminals)!

When charging a reversed battery, an abnormal chemical reaction

may occur. In some cases, an unexpected large amount of current

may ﬂow upon discharging.The battery may generate heat or smoke,

rupture, or burst into ﬂame.

• Do not reverse-charge or reverse-connect the battery!

The battery pack has positive and negative poles. If the battery pack

does not smoothly connect with a charger or operating equipment,

do not force it; check the polarity of the battery. If the battery pack is

reverse-connected to the charger, it will be reverse-charged and an

abnormal chemical reaction may occur. The battery may generate

heat or smoke, rupture, or burst into ﬂame.

• Do not touch a ruptured and leaking battery!

If the electrolyte liquid from the battery gets into your eyes, wash your

eyes with fresh water as soon as possible, without rubbing your eyes.

Go to the hospital immediately. If left untreated, it may cause eye-

problems.

• Do not charge the battery for longer than the speciﬁed time!

If the battery pack has not ﬁnished charging even after the regulated

time has passed, stop it.The battery may generate heat or smoke,

rupture, or burst into ﬂame.

• Do not place the battery pack into a microwave or high

pressure container!

The battery may generate heat or smoke, rupture, or burst into ﬂame.

• Keep ruptured and leaking battery packs away from ﬁre!

If the battery pack is leaking (or the battery emits a bad odor),

immediately remove it from ﬂammable areas. Electrolyte leaking

from battery can easily catch on ﬁre and may cause the battery to

generate smoke or burst into ﬂame.

• Do not use an abnormal battery!

If the battery pack emits a bad odor, appears to have diﬀerent

coloring, is deformed, or seems abnormal for any other reason,

remove it from the charger or operating equipment and do not use it.

The battery may generate heat or smoke, rupture, or burst into ﬂame.

CONTENTS

UNPACKING AND CHECKING EQUIPMENT ...................................1

PREPARATION...................................................................................2

ORIENTATION....................................................................................6

BASIC OPERATIONS ........................................................................8

VOICE OPERATED TRANSMISSION (VOX) .....................................9

BACKGROUND OPERATIONS........................................................10

CHANNEL SETUP MODE................................................................11

PROGRAMMABLE FUNCTIONS.....................................................17

ALL RESET MODE ..........................................................................20

TROUBLESHOOTING GUIDE .........................................................21

OPTIONAL ACCESSORIES ............................................................22

UNPACKING AND CHECKING EQUIPMENT

Carefully unpack the transceiver. If any of the items listed

below are missing or damaged, ﬁle a claim with the carrier

immediately.

SUPPLIED ACCESSORIES

• Battery charger/ AC adapter (KSC-35S) ................................. 1

• Li-ion Battery pack (KNB-63L) ................................................1

• Cap.........................................................................................1

• Belt clip ................................................................................... 1

• Quick Reference Guide........................................................... 1

Note:

◆Refer to “PREPARATION” {p.2} for accessory installation

instructions.

PREPARATION

INSTALLING/ REMOVING THE BATTERY PACK

◆Do not short the battery terminals or dispose of the battery by ﬁre.

◆Never attempt to remove the casing from the battery pack.

◆Install the battery pack after cleaning the battery pack contacts

and the transceiver terminals.

1To install the battery pack, align the

base of the battery pack with the

transceiver, then press the battery

pack into place until the lock lever is

secure.

2To remove the battery pack,

push the lock lever up, then pull

the battery pack away from the

transceiver.

Lock lever

Altri manuali per ProTalk tk-3501

Indice

Altri manuali Kenwood Ricetrasmettitore

Kenwood

Kenwood TH-25A Series Manuale utente

Kenwood

Kenwood TK-3130 - ProTalk XLS UHF Manuale utente

Kenwood

Kenwood Nexedge NX-820H Manuale utente

Kenwood

Kenwood TH-79A Manuale utente

Kenwood

Kenwood TK-280 Manuale utente

Kenwood

Kenwood TK-7108 Manuale utente

Kenwood

Kenwood NEXEDGE NX-700 series Manuale utente

Kenwood

Kenwood TK-5220 K Manuale utente

Kenwood

Kenwood NEXEDGE NX-700 series Manuale utente

Kenwood

Kenwood TH-77A Manuale utente

Kenwood

Kenwood TK-5210 Manuale utente

Kenwood

Kenwood TK-2140 Istruzioni per il montaggio

Kenwood

Kenwood TS-680S Manuale utente

Kenwood

Kenwood UBZ-LF14 Manuale utente

Kenwood

Kenwood TK-5210 Manuale utente

Kenwood

Kenwood UBZ-LH14 Manuale utente

Kenwood

Kenwood TK-7180 Manuale utente

Kenwood

Kenwood TS-660 Manuale utente

Kenwood

Kenwood TM-255A/E Manuale utente

Kenwood

Kenwood NX-203 Manuale utente

Kenwood

Kenwood TH-K7 Manuale utente

Kenwood

Kenwood TK-7100 Manuale utente

Kenwood

Kenwood TS-930S Manuale utente

Kenwood

Kenwood TK-2107G Manuale utente

Manuali Ricetrasmettitore popolari di altre marche

Yaesu

Yaesu FT-7B Manuale utente

Texas Instruments

Texas Instruments TLK10232 Manuale utente

Mizuho

Mizuho MX-2 Guida del prodotto

Blitz

Blitz MJ-398U Manuale utente

Utilicom

Utilicom LongRanger 2050 Manuale utente

Standart

Standart HX290UKA Manuale utente

Altronix

Altronix Pace1PTM Manuale utente

Kirisun

Kirisun PT2208 Manuale utente

ELECRAFT

ELECRAFT KX2 Manuale utente

Zodiac

Zodiac K3 Manuale utente

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuale utente

Siemens

Siemens PSO 4000 Manuale utente

Midland

Midland G8E-BT Manuale

ComNav

ComNav Mariner X2 Manuale utente

Uniden

Uniden UH820 Series Manuale utente

Standard Horizon

Standard Horizon HX320E Manuale utente

Em-Trak

Em-Trak A100 Manuale utente

HPE

HPE Aruba QSFP28 Manuale utente
