Kernel KN-5000C Manuale utente
This manual applicable to KN-5000C/
KN-5000D.
Preface
Dear users, first of all, thanks for your trust and using 308nm Excimer
System manufactured by our company.
Please read this manual and attached documentations carefully
before your first installation and using this system.
To improve capability and reliability of equipment, we will
continuously upgrade our product (including hardware and software). We
will announce you immediately if any amendments are made. Thanks in
advance if you correct it after finding any mistake or oversight.
This manual contains content protected by copyright law, all rights
reserved, without prior written approval, shall not be any part of this
manual copy, photographic copy, photocopy, or translated into other
language
Version: V1.1
Important Notice
Please carefully read the instructions in the “safety requirements”,
“Note”and the special warnings “ “ part of the content.
If you have any problem or need help in using, please contact our
technical service center for help in time. We will give you technical
support or arrange professional technical expert for service at the first
time.
Use correctly can extend the life of equipment, also make fully
usability of equipment by farthest.
Abnormal operation may do harm to equipment or personal safety.
Our company is irresponsible for abnormal condition, hazards to
equipment or personal injury caused by operations that are absolutely
prohibited as specified in this document. Disclaims any responsibility for
safety, reliability or performance of this equipment by not observing the
instructions!
Any faults arising from such non-observance will invalidate the
warranty!
Contents
1Safety requirements and precautions......................................1
1.1 Safety Information ........................................................................... 1
1.2 Precautions ........................................................................................ 3
2Overview ..........................................................................................8
2.1 Product introduction....................................................................... 8
2.2 Structural composition ................................................................. 12
2.3 Identifier declaration..................................................................... 16
2.4 Characteristic parameters ............................................................ 17
3Installation.....................................................................................19
3.1 Unpacking inspection ................................................................... 19
3.2 Environmental requirements....................................................... 20
3.3 Power requirements ...................................................................... 21
3.4 Connection....................................................................................... 23
4Operation.......................................................................................28
4.1 Preparation before treatment..................................................... 28
4.2 Control panel................................................................................... 35
4.3 Software operation........................................................................ 41
5Maintenance..................................................................................63
5.1 Inspection......................................................................................... 63
5.2 Maintenance.................................................................................... 65
5.3 Cleaning............................................................................................ 66
5.4 Disinfection...................................................................................... 68
5.5 Storage.............................................................................................. 68
5.6 Transportation and storage......................................................... 69
5.7 Fuses replacement ......................................................................... 70
6Common failures analysis and exclusion ..............................71
7After Service..................................................................................75
Appendix A Irradiation intensity.....................................................77
Appendix B Skin type .........................................................................79
Appendix C Preset output dose of the MED skin test...............79
Appendix D Conversion of irradiation dose/irradiation time .82
Appendix E Patient log.......................................................................84
Appendix F Electromagnetic compatibility statement.............. 86
KN-5000C Packing List .......................................................................95
KN-5000D Packing List.......................................................................96
1
1Safety requirements and precautions
1.1 Safety Information
⚫Please note that the following conditions should not be treated with
UV radiation: patients with solar dermatitis, lupus erythematosus,
malignant tumors, xeroderma pigmentosum, Bloom syndrome and
dermatomyositis, pregnant women, and other patients that are not
suitable for UV irradiation treatment.
⚫Excessive UV exposure can damage the eyes and skin, and even cause
diseases such as cataracts or skin tumors. Patients and operators must
wear special UV goggles when using the equipment, and try to avoid
looking at the UV radiation source in output state directly. The genital
area of the male patient, especially the testicle, should be tightly
covered.
⚫Do not use the equipment in an environment where flammable or
explosive materials are placed, such as anesthesia, in order to prevent
