KGuard Security A88RH Istruzioni per l'installazione

DVR

SUPPORT MANUAL

ENGLISH

Contents

DVR Support Manual

Contents

Mobile Device Access ......................................................................................... 3

Android®Phones...................................................................................................................... 3

Blackberry®Phones ................................................................................................................. 5

iPhone®Phones ....................................................................................................................... 7

Symbian®Phones................................................................................................................... 10

Windows® Mobile Phones..................................................................................................... 12

.............................................................................................. 14

AVI Converter......................................................................................................................... 14

Playback Tool ......................................................................................................................... 15

Supported Devices List ..................................................................................... 17

HDD Support List.................................................................................................................... 17

Mobile Phones Support List................................................................................................... 19

USB Device Support List......................................................................................................... 20

ENGLISH

Mobile Device Access

DVR Support Manual

Mobile Device Access

Android®Phones

2 Open the Android Market Asee.

2a. On the Market search bar, enter “Asee

Select the “ASEE Click FREE. Click OK.

ENGLISH

Mobile Device Access

4 Click

No. Item

1Address

Enter the IP address assigned to the DVR.

Consult your network administrator or ISP

2Port

Enter the server port number that you

DVR User Manual for details.

3Device Name Enter the desired DVR name.

4User ID in the DVR menu. Refer to your DVR User

Manual for details.

5Password in the DVR menu. Refer to your DVR User

Manual for details.

5 Click Back to view the main screen.

No. Item Icon

1Display Screen - Displays the channel.

2PTZ Control

Click the icons to adjust the zoom (for PTZ camera only).

Click the icons to adjust the aperture (for PTZ camera only).

Click to adjust the camera focus (for PTZ camera only).

Click to play or pause channel viewing.

Click to view the channel in full screen.

Click to capture the screen shot. The screen shot is saved in the path sdcard\

MeyePic.

DVR Support Manual

ENGLISH

Mobile Device Access

No. Item Icon

available by clicking .

Blackberry®Phones

2 Open the App World

2a. Search for “Asee”.

Select the “ASEE Click Install. Login with your BlackBerry ID.

DVR Support Manual

ENGLISH

Mobile Device Access

No. Item

1Title Enter the desired DVR name.

2Address

Enter the IP address assigned to the DVR. Consult

your network administrator or ISP to obtain this

3Port the DVR menu. Refer to your DVR User Manual for

details.

4Channel Total Select the DVR maximum channel capacity.

5User ID menu. Refer to your DVR User Manual for details.

6Password menu. Refer to your DVR User Manual for details.

7Network Type Select the network to use to connect to the DVR

(WiFi/3G).

5 Click Login to view the main screen.

No. Item Icon

1Display Screen - Displays the channel.

Click to play or pause channel viewing.

Click to view the channel in full screen.

Click to capture the screen shot and then select the storage memory where to

available by clicking .

PTZ Control Click the icons to adjust the zoom (for PTZ camera only).

Click the icons to adjust the aperture (for PTZ camera only).

Click to adjust the camera focus (for PTZ camera only).

DVR Support Manual

ENGLISH

Mobile Device Access

iPhone®Phones

2 Open the App Store Asee+.

2a. On the search bar, enter “Asee+

Select the “ASee+ Click FREE. Click INSTALL.

4 Click to open the Device Manage page, then click Add.

DVR Support Manual

ENGLISH

Mobile Device Access

No. Item

1Device Name Enter the desired DVR name.

2Address

Enter the IP address assigned to the DVR.

Consult your network administrator or ISP

3Port

Enter the server port number that you

DVR User Manual for details.

4User ID in the DVR menu. Refer to your DVR User

Manual for details.

5Password in the DVR menu. Refer to your DVR User

Manual for details.

6Max Channel Enter the maximum channels that can be

connected to the DVR.

5 Click OK. The Device Manage screen appears again. Click the device name to view the main screen.

Viewing Channels

1 Click of the window to assign a channel. The Device List screen appears. Click >to display the channel list.

Click . Click >. Channel list

DVR Support Manual

ENGLISH

Mobile Device Access

2 Click a channel to assign to the window.

3 Repeat the above procedures to assign other windows.

Switching Screen Modes

By default, the channels are displayed on a 4-window display. To view a channel in full screen, double-tap the window.

4-Window Display Full Screen Display

Double-tap to

toggle display.

No. Item Icon

1Display Screen - Displays the channels.

Click to stop viewing channels.

Click to capture the screen shot. The screen shot is saved in the photo album.

4PTZ Control

Click the icons to adjust the zoom (for PTZ camera only).

Click the icons to adjust the aperture (for PTZ camera only).

Click to adjust the camera focus (for PTZ camera only).

DVR Support Manual

ENGLISH

Mobile Device Access

Symbian®Phones

2 Open the Ovi Store Asee.

2a. On the search bar, enter “Asee

Select the “ASEE Click Download. Download complete.

Note:

before proceeding.

3 Click Launch from the Ovi screen or click the

4 Click

No. Item

1IP

Enter the IP address assigned to the DVR.

Consult your network administrator or ISP

2Port

Enter the server port number that you

DVR User Manual for details.

3User Name in the DVR menu. Refer to your DVR User

Manual for details.

4Password in the DVR menu. Refer to your DVR User

Manual for details.

5Alias Enter the desired DVR name.

5 Click Back to view the main screen.

DVR Support Manual
