Kimex 013-3265 Manuale utente

Support mural articulé pour écran TV

37´´-80´´

MANUEL DE MONTAGE

40kg

(88lbs)

RATED

+3° -3°

+5°

-15°

75x75/100x100/100x150

100x200/150x100/150x150

200x100/200x200/300x200

300x300/400x200/400x300

400x400/600x400

013-3265

80"

MAX

±60°

Use with products heavier than the rated weights indicated may result in instability causing possible injury.

Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury.

Safety gear and proper tools must be used. This product should only be installed by professionals.

This product is designed to be installed on solid concrete walls, masonry walls or wood stud walls.

Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.

Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.

This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of

purchase for a replacement.

Check that the product is secure and safe to use at regular intervals (at least every three months).

W-B (x6) W-C (x6)W-A (x6)

60mm

2.4"( )

60mm

(2.4")

ø10mm

(ø 3 /8")

ø 4.5mm

(ø 3/16")

55mm

2.2"( )

55mm

(2.2")

A (x1) B (x2) C (x1)

M8x30

M-D

(x4)

M6x30

M-C

(x4)

M6x14

M-B

(x4)

M5x14

M-A

(x4)

M8x50

M-E

(x4)

M-F (x4) M-G (x8) M-H (x8)

X X

√

X X

√

M-A

M-F

M-B

M-F

M-E

M-F

M-C

M-F

M-D

M-G

M-H

W-C

W-A

W-B

W-A

W-C
