KINGSONG KS-16S Manuale utente

KS-16S

User

Manual

WARNING

Electric unicycle is designed for the outdoors and short distance personal

transport.

SAFETY IS THE NUMBER ONE PRIORITY!

PLEASE RIDE UNDER LOCAL LAW!

The user manual below is a quick and convenient guide of safety & item

functions/features to end user. We can’t ensure all types of situation emergen-

cy are covered. Therefore, we STRONGLY remind you to read this guide very

carefully, and ride with attention to ensure your safety.

Riding like all outdoor activities comes with it’s risks. You risk serious danger

and injury if you fall, collide or lose of control when riding, please ride with

caution and at your own risk.

Thanks you for purchasing King Song smart electric unicycle!

Contents

1. Product Details--------------------------------------------------------01

2. Safety--------------------------------------------------------------------04

3. Features-----------------------------------------------------------------06

4. Precautions and Preparation---------------------------------------07

5. Battery-------------------------------------------------------------------10

6. Maintenance-----------------------------------------------------------12

7. Warranty----------------------------------------------------------------13

1. Product Details

1.1 Diagram: KS-16S

1. Trolley Bar

2. Auxiliary Button

3. Charging Port

4. Power ON/OFF Button

5. Light Sensor

6. RGB Light

7. Pad

8. Speaker

9. Pedal

10. illuminating Light

11. Tire

16 x 2.125 inches

4.7 inches

18.2 x 7.7 x 19.9 inches

1200W

≈7h

Input AC 80~240V, Output DC 67.2V 2A

265 lbs

-10℃/+45℃

≤ 30°

≈49.7 miles

21.7 mph

12.4 mph

16S

Tire Size

Distance from

ground

Product Size

Rated Power

Charging Time

Charger Voltage

Max Load

Operating

Temperature

Climbing Angle

Mileage

Top Speed

Rated Speed

Model No

1.2 Specifications

1x Charger, 1x Manual, 1x Warranty card,

1x QC certificate

38.4 lbs

Standard

Accessory

Net Weight

1.3 Main Functions

• Light sensor: Detecting light intensity, Lights on when it is

dark, otherwise, it keeps off.

• BT/Speaker: BT makes us can access to riding information

in app like mileage etc; Audio BT is activated automatically

when power on, you can enjoy music during riding.

• Integrated trolley bar: wheels can be pushed to move

rather than lift up with this integrated trolley bar make the

wheel easier to be carried on.

• USB Port: Portable electrics can be charged Via this USB.

• RGB Light: Shinning during riding, indicates the battery

level while it is on and stop.

• Over side-lean protection: When the lean angle of wheel

exceeds 45°, motor will stop running and will recovery

automatically once back it vertically.

• Buzzer and voice prompt: To ensure safety, there will be

voice prompt to alert rider: over-voltage, over-power, low

battery etc. Voice prompt can be shut off through app, but

buzzer beeps can’t be.

• Tilt-back protection: When over-speed, low-battery, high

temperature, the pedal will title back to prevent further

acceleration.

2. Safety

As an outdoor sport and auxiliary transport device, serious

injury may occur any time during riding.

PLEASE BE CAUTIOUS ALL THE TIME, LEARN AND

PRACTISE STEP BY SETP BEFORE IT REGULARLY. READ

THE INSTRUCTIONS THROUGHLY AND CAREFULLY TO

LIMIT THE RISK OF INJURY.

2.1 Important

• Do not make rapid acceleration or deceleration or over

Incline forward or lean backwards.

• Do not use the EUC if there are any risks of accidental

fails.

• When there is alarm of over power, over voltage, low

battery, please decelerate at once.

2.2 Attention

• Please wear helmet, gloves. Elbow/Knee pads or other

protection garments.

• Please check the device before ever ride to make sure no

parts are loose or damaged.

• When there are crowded pedestrians, please slow down to

match their walking speed.

• When carry the device, please make sure the power is off.

• Do not ride on highways or any other prohibited places.

• Do not ride on wet, slippery surfaces, especially snowy

roads.

• Any person under 12 is strictly prohibited to use the EUC.

• Do not ride in bleak winter conditions.

• Riding backwards is dangerous. Try to avoid riding

backwards unless safety guaranteed.

• Don’t jump with the EUC.

Other sudden unpredictable risks may occur during use,

please ride with care. King Song will not be responsible for

any injuries caused by improper operations of the device.

3. Features

3.1 Integrated trolley bar

3.2 Front illuminating light & Rear Brake light

3.3 APP

• For Android app: Please access to our official website:

www.kingsongpro.com, android app can be downloaded.

• For IOS app: Please download from apple store,

‘kingsong’ is the exact one.

KingSong APP(Android) KingSong APP(IOS)

3.4 Riding Mode

Riding Mode refers to the torque during start-off and braking.

Expert Mode / Riding Mode / Learner Mode decelerate,

turning and so on.
