Kirisun DP586 Manuale utente
DP586 DMR Two Way Radio User Manual
II
I
User Manual
DP586
DMR Two Way Radio
We are very grateful for your purchasing Kirisun brand DMR Two Way Radio produced by
Kirisun Communications Co., Ltd.
We believe Kirisun two-way radio, which always incorporates the latest technology, can bring
great convenience to your life and work. We also believe that the quality and function of Kirisun
two-way radio can meet your demands for reliable communication.
DP586 DMR Two Way Radio User Manual
1
Notice to user
◆Copyright
Kirisun and our authorized partners own the intellectual property of all the parts of this product (include
accessories). Any design and materials may not be modified, copied, extracted or translated without the
authorization of Kirisun or its authorized parities.
Due to the update or modification of the product, Kirisun owns the right to change the specifications of
software and hardware described in this manual without further notice. Specifications and information
contained in this manual are for reference only.
◆Safety Information
Compliance with RF Exposure Standards
Your radio is designed and tested to comply with a number of national and international standards and
guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio
complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at
operating duty factors of up to 50% transmitting. In terms of measuring RF energy for compliance with the
IEEE and ICNIRP exposure limits, your radio radiates measurable RF energy only while it is transmitting
(during talking), not when it is receiving (listening) or in standby mode.
DP586 DMR Two Way Radio User Manual
2
Your radio complies with the following of RF energy exposure standards and guidelines
Institute of Electrical and Electronic Engineers (IEEE) C95.1-1992
Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
◆Using the designated accessories
Use the antenna, battery, adapter or charger supplied or sold by Kirisun only, or otherwise it causes damage
to the product.
If you want to purchase or replace the accessories, please contact your local dealer or Kirisun.
◆Area restrictions
1. To avoid of the problems caused by electromagnetic interference or electromagnetic compatibility, turn off
the radio in any facilities where posted notices instruct you to do so, such as hospital and other health care
facilities. Turn off the radio when on board an aircraft, if instructed to do so.
2. In the vehicle with an air bag, do not place the radio in the area over an air bag or in the air bag
deployment area.
3. Turn off the radio before entering any area with a potentially explosive atmosphere or blasting caps.
DP586 DMR Two Way Radio User Manual
3
4. Do not operate the radio, disassemble or charge the battery in the potentially flammable and explosive
atmosphere (such as gas station, coal gas station, etc.).
5. Do not place the radio under the direct sunlight or near the area with heating devices.
6. Do not place the radio in the area with great dust, moisture or drips, or on the unstable surface.
◆Operating Attentions
Antenna
Do not use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with
your skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily injury, such as burns, if a conductive material such as
jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot. Excessive care in handling any charged battery,
particular when placing it inside a pocket, purse, or other container with metal objects. To reduce the
potentially damage, do not expose the battery in the fire, or disassemble and extrude the battery.
To realize the best performance of the battery, change the battery once a year.
Maintenance
DP586 DMR Two Way Radio User Manual
4
Do not disassemble the radio by yourself. This product can only be maintained by the professional
technicians.
Contact us or your local dealer for help if you want to re-develop or modify the radio.
DP586 DMR Two Way Radio User Manual
5
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device ,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
DP586 DMR Two Way Radio User Manual
6
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
SAR warning
Output power listed is rated conducted. This device must be restricted to work-related operations only in an
Occupational/Controlled RF exposure environment and must operate with a duty factor not exceeding 50%.
This transmitter may operate with the antenna(s) documented in this filing in Push-to-Talk and body-worn
configurations. RF exposure compliance is limited to the specific belt-clip and accessory configurations as
documented in this filing and the separation distance between user and the device or its antenna shall be at
least 2.5 cm. All qualified end-users of this device must have the knowledge to control their exposure
conditions and/or duration to comply with occupational/controlled Exposure limit and requirements. The
highest reported SAR values for Face-held, body-worn and simultaneous transmission conditions are 3.408
W/Kg, 3.531 W/Kg and 3.717 W/Kg respectively.
This device contains Bluetooth, BLE and Two Way Radio transmitters.
DP586 DMR Two Way Radio User Manual
7
Technical Parameters
PMR:
Operation Frequency Range: 400 to 470MHz
Rated Output Power: High Power: 4W / Low Power: 1W
Modulation Type: Analog: FM / Digital: 4FSK
Channel Separation: Analog: 12.5kHz
Digital: 12.5kHz
Bluetooth:
Supported Type: Bluetooth 4.2 EDR+BLE
Modulation: EDR: GFSK, π/4QPSK, 8DPSK / BLE: GFSK
Operation Frequency: 2402 to 2480MHz
Channel Number: EDR: 79 / BLE: 40
Channel Separation: EDR: 1MHz / BLE: 2MHz
GPS:
Modulation: MSK
Operation Frequency: 1575.42MHz
DP586 DMR Two Way Radio User Manual
8
Waste Electrical and Electronic Equipment recycling
This symbol on the product or its packaging indicates that this product must not be disposed of as
household or commercial waste. Some countries have set up collection and recycling systems for
waste electrical and electronic products. By ensuring that this product and its packaging is disposed
of correctly, you will help prevent potentially negative consequences for the environment and
human health, and help conserve natural resources. Please dispose of your waste product according to your
national and local regulations. Contact your service provider or Kirisun for information about disposing of this
product in your region of the world.
Disposing of batteries
Your radio is supplied with a rechargeable lithium-ion battery. This symbol on the battery and its
packaging indicates that it must not be disposed of with household or commercial waste. Please
dispose of your waste batteries according to your national and local regulations. Contact your
service provider or Kirisun about recycling batteries in your region of the world.
US Markets
DP586 DMR Two Way Radio User Manual
9
DP586 Quick Reference
Brief Introduction
1．Attaching the antenna: put the antenna into the antenna interface, and rotate the antenna clockwise
to fix it.
2．Powering on: rotate the power/volume knob to power on the radio.
3．Channel Selection: rotate the channel selection knob to select channel.
4．Powering off: rotate the power/volume knob clockwise to power off the radio
