KitchenAid 5KHM5110 Manuale utente
Hand Mixer
5KHM5110
W11606021A.indb 1W11606021A.indb 1 5/10/2022 10:51:01 AM5/10/2022 10:51:01 AM
2
PARTS AND FEATURES
1Non-tip Heel Rest
2Swivel Lock Power Cord
3Cord Strap
4Comfort Designed Handle
5Easy-to-use Speed Control
6Oversized Beater Ejector Button
7Air Vents
8Stainless Steel Beater
916-wire Whisk
1
2
3
456
7
89
W11606021A.indb 2W11606021A.indb 2 5/10/2022 10:51:02 AM5/10/2022 10:51:02 AM
3
ENGLISH
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result inpersonal injury.
2. To protect against risk of electrical shock, do not put Hand Mixer in water or other
liquid.
3. This appliance is not intended for use by persons, (including children), with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instructions concerning
use of the appliance by a person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent, or similarly qualied persons in order to avoid a hazard.
6. Never leave the appliance unattended while it is inoperation.
7. Turn the appliance to OFF/0, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the plug
and pull from the outlet. Never pull from the power cord.
8. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas
and other utensils away from all accessories during operation to reduce the risk of
injury to persons and/or damage to the Hand Mixer.
9. Do not operate the Hand Mixer with a damaged cord or plug, or after the Hand
Mixer malfunctions, or is dropped or damaged in any manner. Return the Hand
Mixer to the nearest Authorised Service Facility for examination, repair, or
electrical or mechanical adjustment.
10.The use of attachments/accessories not recommended or sold by KitchenAid may
cause re, electric shock, or injury.
11.Do not use the Hand Mixer outdoors.
W11606021A.indb 3W11606021A.indb 3 5/10/2022 10:51:02 AM5/10/2022 10:51:02 AM
4
PRODUCT SAFETY
ELECTRICAL REQUIREMENTS
Voltage: 220-240 V
Frequency: 50-60 Hz
Wattage: 85 W
NOTE: If the plug does not fit in the
outlet, contact a qualified electrician. Do
not modify the plug in any way. Do not use
an adapter.
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
This product is designed for household use only.
12.Do not let the cord hang over the edge of table or counter.
13.Do not let the cord contact hot surface, including the stove.
14.Remove any accessories from Hand Mixer before washing.
15.Allow the appliance to cool completely before putting on or taking off parts, and
before cleaning the appliance.
16.Refer to the “Care and Cleaning” section for instructions on cleaning the surfaces
in contact with food.
17.This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, ofces and other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
W11606021A.indb 4W11606021A.indb 4 5/10/2022 10:51:02 AM5/10/2022 10:51:02 AM
5
ENGLISH
SPEED CONTROL GUIDE
/ 0
The 5-speed Hand Mixer should always be set on the lowest speed to start
mixing. Move to higher speeds as needed.
SPEED ATTACHMENT DESCRIPTION
1
Stainless Steel
Beater
For slow stirring, combining, and starting
all mixing procedures. Use this speed to stir
in nuts, chocolate chips, shredded cheese,
onions, olives, and other chunky ingredients.
Mix flour and other dry ingredients with liquids
or other moist mixtures. Helps avoid ingredient
splash out.
2
Stir batters and gelatin mixtures. Combine
heavy mixtures, such as cookie dough. Mix
light cream cheese spreads. Mash potatoes.
3Combine heavy cream cheese mixtures. Mash
squash.
4/5 Blend butter and sugar. Mix muffins, quick
breads, cake batters, and frostings.
NOTE: The Stainless Steel Beater accessories are not designed for mixing and kneading
bread dough.
ACCESSORY USES
Stainless Steel Beater Cookie dough, cake batter
16-wire whisk
Whip heavy cream and mousse mixtures
Beat egg whites and meringue mixtures
ACCESSORY GUIDE
W11606021A.indb 5W11606021A.indb 5 5/10/2022 10:51:02 AM5/10/2022 10:51:02 AM
6
NOTE: An accessory shaft without a collar
may be used in either opening (A or B).
Those with a collar may only be used in the
larger opening (B).
CD
Paired accessories (beaters, optional
dough hooks) include one accessory with
a collar (D), and one without (C). Single
accessories, like the 16-wire Whisk, come
without a collar (C).
Wash all accessories in warm, soapy water
before use. Be sure the Hand Mixer is
unplugged before cleaning, and putting on
or taking off parts.
PRODUCT ASSEMBLY
ATTACHING THE ACCESSORIES
1
Insert the accessory shaft with the collar
(D) into the larger opening (B) of the
Hand Mixer. Align the flanges on the
shaft with the slots in the opening. Push
to lock into place
D
2
B
A
Insert the accessory without a collar (C)
into the smaller opening (A). Align and
push to lock into place.
B
W11606021A.indb 6W11606021A.indb 6 5/10/2022 10:51:03 AM5/10/2022 10:51:03 AM
7
ENGLISH
/ 0
This KitchenAid Hand Mixer will beat faster and more thoroughly than most other Electric
Hand Mixers. Therefore, the beating time in most recipes must be adjusted to avoid
over beating. Beating time is faster due to larger beater sizes.To help determine the
ideal beating time, observe the batter or dough and beat only until it has the desired
appearance described in your recipe, such as “smooth and creamy”. To select the best
beating speeds, use the “Speed Control Guide” section.
PRODUCT USAGE
OPERATING THE SPEED CONTROL
PRODUCT DISASSEMBLY
REMOVING THE ACCESSORIES
2
1
Make sure the Speed Control is in the
“OFF/0” position by sliding it backward
as far as possible. “OFF/0” will be visible
on the speed control pad. Then plug the
Hand Mixer into an electrical outlet.
If the Hand Mixer is running, stop
the Hand Mixer by sliding the Power
switch to “OFF/0”. Then unplug from
the electrical outlet.
Press the ejector button to release
the accessories from the Hand Mixer,
then remove them.
/ 0
1
W11606021A.indb 7W11606021A.indb 7 5/10/2022 10:51:03 AM5/10/2022 10:51:03 AM
8
PRODUCT USAGE
To increase the Hand Mixer speed, slide
the Speed Control forward. To decrease
the Hand Mixer speed, slide the Speed
Control backward. See “Speed Control
Guide” section.
3
Start mixing at the lowest speed by
sliding the Speed Control forward to the
first position mark, which is Speed 1.
2
/ 0
When finished, slide speed control to
“OFF/0”. Unplug the Hand Mixer before
removing the accessories.
4
W11606021A.indb 8W11606021A.indb 8 5/10/2022 10:51:03 AM5/10/2022 10:51:03 AM
9
ENGLISH
CARE AND CLEANING
CLEANING THE HAND MIXER BODY
Electrical Shock Hazard
Do not put in water.
Doing so can result in death or
electrical shock.
NOTE: Do not immerse Hand Mixer in
water.
IMPORTANT: Allow the appliance to cool completely before putting on or taking off
parts, and before cleaning the appliance.
Always unplug Hand Mixer before
cleaning. Wipe power cord and Cord
Strap with damp cloth. Dry with a soft
cloth.
Wipe Hand Mixer with a damp cloth. Dry
with a soft cloth.
21
W11606021A.indb 9W11606021A.indb 9 5/10/2022 10:51:04 AM5/10/2022 10:51:04 AM
10
TROUBLESHOOTING
First try the solutions suggested here and possibly avoid the cost of service.
©2022 All rights reserved.
PROBLEM SOLUTION
If Hand Mixer Malfunctions or
fails to operate:
Check if the Hand Mixer is plugged in. Check if the fuse
in the circuit to the Hand Mixer is in working order. If you
have a circuit breaker box, make sure the circuit is closed.
Try unplugging the Hand Mixer, then plug it back in.
If the problem cannot be fixed
with the steps provided in this
section:
Contact KitchenAid or an Authorised Service Centre.
Do not return the Hand Mixer to the retailer - they do not
provide service.
CLEANING THE ACCESSORIES
Always remove beaters and whisk from
Hand Mixer before cleaning. Wash in top
rack of dishwasher, or by hand in warm,
soapy water. Rinse and wipe dry.
1
CARE AND CLEANING
W11606021A.indb 10W11606021A.indb 10 5/10/2022 10:51:04 AM5/10/2022 10:51:04 AM
