Kleenmaid CH17 Manuale utente
COOKTOP
c o l l e c t i o n
Instructions for Use
and Warranty Details
Ceramic Cooktops CH17 - Ceramic Touch Control 600 mm
CH18 - Ceramic Touch Control 780 mm
Congratulations on the purchase of your
new Kleenmaid appliance.This appliance
has been designed and manufactured to
give you years of reliable performance.
For best results, carefully read the
instructions on how to install your new appliance. Correct
installation will avoid delays and unnecessary service calls.
Once installation is complete, read this booklet and get to
know the controls and the features of your new appliance.
If you need further information call our
Customer Care Centre
1300 652 100
We reserve the right to alter the specifications with no
influence on the operation of the appliance. This instruction
manual cannot be reason for claim.
CONTENTS
General description ............................................................ 2
Description of sensors ........................................................ 3
Description of timer...............................................................4
Operating....................................................................... 5,6,7,8
Safety........................................................................................... 9
Considerations........................................................................ 9
Using pans .............................................................................. 10
Cleaning ................................................................................. 11
Installation ................................................................. 12,13,14
Wiring Diagram..............................................................15,16
Warranty and Service.........................................................17
WARNING
1
• Repair of any fault in your hob must be carried out only by an
Authorized Repair Agent, otherwise the guarantee is not
valid.
• The technical details and identification of the appliance are
shown on the specifition plate.
Consult this plate before proceeding with electrical
connection.
• Electrical connection must be carried out by a specialist
familiar with the laws and official regulations governing such
installation in your State.
2
GENERAL DESCRIPTION
DOUBLE HOTPLATE
....
..
....
....
MODEL
CH17
MODEL
CH18
Control
sensors
Control
sensors
DOUBLE HOTPLATE
3
DESCRIPTION OF SENSORS
MODELS: CH17 and CH18
Double hotplate control point
Double hotplate sensors
Hotplate pilot light
Selected power display
Residual heat display
Power sensors
from 0to 9
from 9to 0
Blocking sensor
ON/OFF
Blocking control point
DESCRIPTION OF TIMER
The double hotplate is equipped with a minute timer (1to
99) that automatically switches off the heat and sounds an
alarm at the end of the selected time.The double hotplate
can operate with or without programming.
Setting the timer
Touch the sensor +/- sensor for the clock to set
numbers of minute duration required. To change the
timer rapidly, keep your finger on the +/- sensor.
Warning function
When the double hotplate is not switched on, the timer
operates as a warning. If the double hotplate is switched
on after pre-selection has been made, it also acts as a
warning.When the set time has elapsed it will give a
warning signal which can be switched off by operating
one of the sensors.
Stopping the program
Touch the sensor until the minute display reaches 00.
Operation of timer
With the double hotplate active, if a specific time is pre-
selected, it will act as a timer and switch off the double
hotplate once this time has elapsed. An audible signal will
advise that the time has expired.
Switch off the warning by operating one of the sensors.
Note:
When operating as a timer, the pilot light switches on 00.
When operating as a warning, the light does not switch on.
Display and sensors
4
MODEL-CH-18
5
OPERATING
Sensors
The vitroceramic cooking surface is fitted with sensors that are touch-
sensitive and also react to the presence of a reflective object.
The hotplates are operated by touching the corresponding sensors with your
fingers.
Take care to touch only one sensor at a time, otherwise they will not react to
the touch.
Setting up
While the cooking surface is inoperative, the indicators for all sensors are
switched off.
Starting up
Touch the ON/OFF sensor for 3 seconds. The power 0displays will light
up. If no power is selected within five seconds, the hotplate will automatically
switch off and must be switched on again.
Keep the sensors clean and do not place objects on them. The sensors may
misinterpret dirt or objects placed on them as finger contacts.
OPERATING
Selecting power. - /+
Each hotplate has - / +. power sensors. Touching these allows the power to
be adjusted in the range 1 to 9.
To alter the power while the hotplate is on, touch - / +sensors to obtain the
required power level.
Switching off a hotplate. -
Touch the hotplate’s -sensor until it shows 0. If the hotplate is hot, Hwill
light up.
¡Warning!
If a power cut occurs while the residual heat display is on, remember that
when power is restored the display will not reappear even though the
hotplate is still hot.
Residual heat display H.
When activated but with level 0,the corresponding displays shows 0and
H.alternatively.
While a hotplate is still hot but switched off, the display will show H.
Depending on the power that was used, this display may remain on for up to
approximately 30 minutes.
Do not touch the area of the hotplate. THERE IS A RISK OF BURNING.
6
7
Hotplate blocking function.
The blocking of the hotplates prevent accidental changes while they are
operating. The initial selections are maintained and the indicators remain
active. The hotplates should be blocked to prevent children from operating
them or to prevent the effects of accidental contact with containers or tools.
Press the blocking sensor until its pilot light comes on.
Unblocking
Touch the blocking sensor until its pilot light switches off.
OPERATING
Double hotplate
The rear right sensors operate a small central circuit . To operate the
outer part, touch the double hotplate sensor until its pilot light comes
on. Switch off by touching the sensor until the pilot light switches off.
Focus hotplate - Model CH18
When the sensors for the rear left are operated, note that only its circular
circuit will operate. To switch on the outer part at the same time, touch the
source hotplate sensor 0 until its control point switches on.
To switch off the focus hotplate, touch the focus hotplate sensor 0 until
the control point switches off.
Automatic programming 9.
(quick heating)
Each control area includes an automatic programming function.
This programming allows the corresponding maximum temperature to be
reached quickly and maintained automatically.
Selection.
Touch the sensor +once to turn on its decimal point, if it is in position 9.
the display will show 9.
Pre-selection is active for 10 seconds to allow the required power level to be
selected.
Touch the sensor -to reduce it to the required level (levels 3.to 6.are
recommended).
Once the automatic heating temperature is reached, a short warning will
sound and the decimal point will switch off. The hotplate will continue to
operate normally.
To cancel the automatic programming, touch the -sensor and the decimal
point will switch off.
OPERATING
8
