Kodak ESP 3.2 Manuale utente
Eastman Kodak Company
Rochester, NY 14650 U.S.A.
© Eastman Kodak Company, 2011.
MC/MR/TM: Kodak, EasyShare.
Printed in China. Imprimé en Chine.
Impreso en China.
all-in-one printer • Imprimante tout-en-un
User Guide • Guide d'utilisation
4K3033
www.kodak.com/go/aiosupport i
ENGLISHENGLISH
1KODAK ESP 1.2 and 3.2 All-in-One Printers
Your KODAK All-in-One Printer combines ease-of-use and affordable inks to provide
high-quality pictures and documents.
Now … Print from anywhere!
■Print from your smartphone, tablet, or computer using Google Cloud Print™ enabled
apps*.
■Send documents to your printer using any email service with KODAK Email Print
Service*.
For more information, see the Extended User Guide at
www.kodak.com/go/esp1_2manuals or www.kodak.com/go/esp3_2manuals.
Resources
Support is available! Go to www.kodak.com/go/esp1_2support or
www.kodak.com/go/esp3_2support for:
■Answers to questions
■Software and firmware upgrades
■Extended User Guide
■And more!
If you prefer, you can chat online, send us an email, or call for technical support.
Go to www.kodak.com/go/contact.
* A Google account is required. The device and printer must be connected to the Internet. Subject to
service availability.
ii www.kodak.com/go/aiosupport
Contents
ENGLISH
1 Printer Overview ................................................................................1
Components ................................................................................................1
Control panel — ESP 1.2 Printer ..................................................................4
Control panel — ESP 3.2 Printer ..................................................................5
Home Center Software ................................................................................6
Paper...........................................................................................................6
Paper types ............................................................................................7
Paper sizes .............................................................................................7
Loading paper ........................................................................................8
2 Basic Functions ................................................................................11
Printing......................................................................................................11
Printing documents...............................................................................11
Printing pictures ...................................................................................12
Copying .....................................................................................................15
Scanning....................................................................................................16
3 Troubleshooting ...............................................................................17
Basic troubleshooting.................................................................................17
Getting help on the Web............................................................................21
4 Safety and Warranty Information .....................................................22
Safety Information...................................................................................... 22
Warranty Information.................................................................................24
Declaration of Conformity...........................................................................26
www.kodak.com/go/aiosupport 1
1Printer Overview
This printer lets you print, copy, and scan pictures and documents.
Components
1 Left paper-edge guide* 4 Paper output tray
2 Paper guard 5 Output tray extender
3 Paper input tray
*Right paper-edge guide not shown. When you move
one guide, both guides move.
3
1
2
5
4
Printer Overview
2www.kodak.com/go/aiosupport
6 Scanner glass 9 Memory card slot
7 Scanner lid 10 Wi-Fi connectivity LED
8 Control panel 11 Power button
6
11
8
9
7
10
Printer Overview
www.kodak.com/go/aiosupport 3
12 Power cord connection port 14 Access door
13 USB port 15 Printhead with ink cartridges installed
14
15
12 13
Printer Overview
4www.kodak.com/go/aiosupport
Control panel — ESP 1.2 Printer
Feature Description
1 LCD Displays pictures, messages, and menus
2 Navigation buttons Used to navigate menus, scroll through pictures
3 OK button Selects a menu item and allows you to continue with the
current operation
4 Start button Begins copying, scanning, maintenance tasks, and file
transfer
5 Cancel button Stops the current operation and returns to the previous
menu
6 Back button Displays the previous screen or the next highest screen in
the menu
7 Home button Displays the main menu
7
6
5
1
2
2
3
2
4
Printer Overview
www.kodak.com/go/aiosupport 5
Control panel — ESP 3.2 Printer
Feature Description
1 LCD touch screen Displays icons, pictures, messages, help, and menus
2 Cancel button Stops the current operation and returns to the previous
menu, and closes the Help screen
3 Start button Begins copying, scanning, maintenance tasks, and file
transfer
4 Help button Displays context-sensitive help
5 Back button Displays the previous screen or the next highest screen in
the menu
6 Home button Displays the main menu
6
5
4
1
2
3
Printer Overview
6www.kodak.com/go/aiosupport
Home Center Software
KODAK Home Center Software is installed with your KODAK All-in-One Printer Software,
unless you chose otherwise. The Home Center icon will appear on your desktop.
On a computer with WINDOWS Operating System (OS), you can use Home Center
Software to browse and edit pictures, print, copy, scan, order supplies, access the
Extended User Guide, and configure your all-in-one printer from your computer.
On a computer with MAC OS, you can use Home Center Software to scan, order supplies,
access the Extended User Guide, and configure your printer from your computer.
Paper
For the best photo printing results, use KODAK Photo Papers, which are optimized to
work with KODAK All-in-One Printers.
For the best document printing results, use KODAK Papers or a paper with
the COLORLOK Technology logo on the package. Use only paper that is designed for
inkjet printers.
