DCS Pro Back Plus

Quick Reference

Displaying and Navigating the Menu Bar

Using the Image LCD and Digital Buttons

Turn the Image LCD on .........................................Press the OK button.

Select a highlighted menu option ..........................Press the OK button.

Enable Region of Interest box (Zoom mode).........Press the OK button.

Implement a zoom (Zoom mode) ..........................Press the OK button.

Delete an image (Delete mode).............................Press the OK button.

Toggle the Menu bar on/off....................................Press the Menu button.

Turn the Image LCD off .........................................Press the Cancel button.

Dismiss a menu without implementing change .....Press the Cancel button.

Disable Region of Interest box (Zoom mode)........Press the Cancel button.

Navigate through images in all Display modes

(except Zoom mode when Region of

Interest box is on) .............................................Press the left or right side of the 4-way switch.

Using the Image LCD and Digital Buttons (continued)

Navigate the Menu bar and display menus ...........Press the left or right side of the 4-way switch.

Navigate a drop-down menu .................................Press the top or bottom of the 4-way switch.

Change to a different Display mode ......................Press the top or bottom of the 4-way switch.

Move the Region of Interest box (Zoom mode) .....Press any edge of the 4-way switch.

Connecting to a Computer with

Two IEEE 1394 Ports

IEEE

1394 cable

Computer AC AC adapter

DCS Pro Back

Plus

Connecting to a Computer with

One IEEE 1394 Port

Connecting to a Computer Using Battery Power

Compatible

Battery

Computer

IEEE

1394 cable

Battery cable

DCS Pro Back Plus

Computer

AC adapter

IEEE

1394 hub

DCS Pro Back

Plus

IEEE

1394 cable

Folder icon

Menu icon

Status screen icon

Video icon

Tag icon

Contrast icon

EASTMAN KODAK COMPANY

Rochester, New York 14650

Kodak and Kodak Professional are trademarks.

Printed in U.S.A. P/N 6B5811 9/01

Rear

PWR CANCEL

MENU OK

DCS Pro Back Plus

Front (attaches to camera body)

Image LCD

Power button

Sides Inserting/Removing a CF Card

To Insert:

1. Open the Card door.

2. Insert a card in the slot and press firmly

until you feel the card seat. (When using

a single card, you can use either slot.)

3. Insert a second

card, if needed.

(The first card

inserted is the

active card.)

4. Close the Card

door.

To Remove:

1. Open the Card door.

CAUTION: Do not remove the card when

the Card Busy LED is flashing. Doing so

could destroy all the image files on the

card.

2. Press the Eject button next to the card

to be ejected.

Connecting to a Battery

in Portable Mode

Connecting to an AC Adapter

in Portable Mode

Battery Cable

Compatible

Battery

DCS Pro Back Plus

AC adapter

Camera Ready LED

Image LCD Tilt Latch

Cancel button

Menu button

Four-way switch

OK button

Filter Latch IR Filter*

Slots for connecting to camera

body or MAMIYA Interface Plate

*To obtain correct focus you must use either an IR filter or

an anti-aliasing filter which is available as an accessory.

Lens Sync

Cable jack

Flash Sync

Cable jack

IEEE 1394

Port

Battery

Connection

jack

Card1 Eject button

Card2

Busy LED

Card2 slot

Card1 slot

Card door

S-Video

Output jack

Card2 Eject

button

Card1 Busy

LED

Remote Shutter

release jack
