Kodak Digital Frame 1 Manuale utente
www.kodak.com/go/digitalframesupport 1
ENGLISH
See your extended user’s guide – for more information about using your frame,
visit www.kodak.com/go/digitalframesupport.
Remote control
Button Press to
power* turn on/off the picture frame.
home return to the home screen.
pics/music toggle between viewing pictures and selecting music.
menu display menu choices.
back return to the previous screen.
stop a slide show, display thumbnails.
OK accept the current selection.
4-way navigate through pictures or menus.
zoom magnify the picture.
rotate rotate the picture, 90°clockwise each press.
select mark pictures for an operation.
slide show play a slide show.
play/pause play/pause a video or slide show.
rewind rewind a video.
fast forward fast forward a video.
stop stop a video, display the first frame.
stop a slide show, display thumbnails.
volume decrease (-) or increase (+) the volume.
mute mute audio.
back
OK
menu
First, turn on the
power switch on the
frame.
*
Remove tab to
activate the
remote.
*
2www.kodak.com/go/easysharecenter
ENGLISH
Front View
Back/Left Side View
1Speakers 5Memory card slot - SD, MS, xD, MMC
2Wall mount hangers 6On/Off switch
3Frame stand 7Remote control holder (removable)
4Memory card slot - CF, MD
1 LCD screen
2 Faceplate
3 Remote control sensor
3
2
1
6
4
7
2
5
1
1
2
3
Slide the holder
into slots.
www.kodak.com/go/digitalframesupport 3
ENGLISH
Top/Right Side View
1Picture/music toggle 8USB connector (connect to computer, also connect
camera/USB device - with adapter cable.)
2Play/Pause
3Stop/Back 9Volume control
4Menu 10 Headphone jack
5OK 11 DC-In (12 V)
6 Down 12 Reset button
7Up
8
9
6432
11
5
10
71
12
4www.kodak.com/go/easysharecenter
ENGLISH
Setting up your wireless network
See the Wireless Setup Guide
Follow the directions in the
Wireless Setup Guide
to:
■Install the software on your computer.
■Set up your frame and wireless network.
■View pictures over your wireless network.
Connecting the power cable
CD packaged
with your frame.
Your power cable (included with the frame) may be
different from the one pictured. Use the plug that
accommodates your type of power outlet.
www.kodak.com/go/digitalframesupport 5
ENGLISH
Turning on the frame
Setting your language
back
OK
menu
Press the switch
to On.
Then use the remote control
to turn the power off and
on.
1. 2.
2.
1.
OK to accept.
to change.
The language
setup screen
appears the first
time you turn on
the frame.
back
OK
menu
A slide show starts from sample
pictures pre-loaded in internal
memory.
6www.kodak.com/go/easysharecenter
ENGLISH
Viewing your first pictures
To play a slide show from a memory card or USB device, insert the card or
device (see step on the next page).
If a slide show is already playing (for example,
from the pre-loaded sample pictures), your slide
show starts automatically.
If you are at the Home screen (page 8), press
on the remote control to highlight your
picture source, then press to start the slide
show.
— To play music with your pictures or slide
shows, see page 12.
To view pictures from your computer over your wireless network, see the
Wireless Setup Guide
and your extended user’s guide.
6
www.kodak.com/go/digitalframesupport 7
ENGLISH
Inserting memory card/USB device
a)
b)
Memory card
(sold separately)
CompactFlash/
MicroDrive
Secure Digital/
Memory Stick/
xD/
MultiMediaCard
USB device
(digital camera, flash drive, card reader, etc.—sold separately)
USB cable included with your USB
device.
USB adapter cable included with
your EX model picture frame.
a)
b)
8www.kodak.com/go/easysharecenter
1Doing more
All buttons and controls described are on the remote control unless otherwise specified.
For supported picture, video, and music file formats, see the extended user’s guide.
Home screen—picture sources and settings
1Press .
All connected sources and the Settings icon are
displayed.
2Press to highlight a picture source, then:
■Press to start a slide show.
■Or, press OK to display thumbnails, folders,
albums.
Home screen options:
My Frame—the frame’s internal memory. Copy your special pictures to internal
memory from a memory card or other device (page 13).
Memory card—appears when you insert a card (page 7). The label and icon indicate
the type of card.
Camera—appears when you connect a digital camera via USB cable (page 7).
USB drive—appears when you insert a USB flash drive (page 7).
Doing more
www.kodak.com/go/digitalframesupport 9
Viewing pictures and videos
The viewing methods described here apply to pictures and videos from any picture
source: internal memory (My Frame), a memory card, camera or other USB device, or
wirelessly from your network computer or Gallery account.
Thumbnails view
■To view your pictures as thumbnails,
press when a slide show is playing.
■To navigate through the thumbnails, press .
■To play a video ( ), highlight it and press OK.
■To view a different folder, highlight it and press OK.
Network computer—appears if you are connected to a wireless network computer.
Display pictures that are stored on the computer. See your
Wireless Setup Guide
.
KODAK Gallery—appears if you have set up your Gallery account and are connected
to a wireless network. Display your albums and My Friends’ Albums from the Gallery.
See your
Wireless Setup Guide
.
KODAK Gallery, with new picture notification —someone has shared pictures
with you at the Gallery! See page 11.
Settings—customize your frame settings. For example, set slide show durations and
transitions, viewing options, clock and timer, etc. For more information, see your
extended user’s guide at www.kodak.com/go/digitalframesupport.
Doing more
10 www.kodak.com/go/easysharecenter
Single view
■To view a single, full-screen picture, highlight it in thumbnails view and press OK.
■To magnify a picture up to 8X, press . To view other parts of the picture, press
. Continue pressing to return to full view.
■To rotate a picture, press .
Slide show
■To start a slide show from any selected picture (thumbnail or single view), press .
■To start a slide show from the Home screen , press to highlight a picture
source, then press .
■To change the slide duration or choose a different transition type, go to Home ,
Settings , Viewing Options.
Arrange by date or filename
By default, the pictures on your frame are arranged by date, starting with the oldest.
You can change the arrangement, or sort order, of your pictures by date or
alphabetically.
To change the sort order, press , then select Sort by →OK. Select a sort order, then
press OK.
