Koden MDP-621 Manuale utente
MDP-621
MDP-641
MDP-640
MDP-600SER.OM.E 0093161022-07
Declaration of Conformity
(As required by Article 6.3 of Directive 1999/5/EC-RTTE Directive)
Declares under his sole responsibility that the produced Marine Radar System manufactured
by
Koden Electronics Co., Ltd.
5278 Uenohara
Uenohara-Shi,
Yamanashi-Ken
409-0112
Japan
Telephone +81 554 20 5865 Telefax +81 554 20 5880
Intended for Worldwide use as a Marine Radar for use aboard non-SOLAS vessels and
identified by the type number MDP-621 / MDP-641 / MDP-640 to which this
declaration refers has been tested to the essential radio test suites required by the notified
body and is in conformity with the standards
EN 60945 : 2002 ( Clauses 9,10 & 12 )
EN 62252 : 2004 ( Clauses 4.8, 4.33, 5.8, 5.33 and Annex D )
ITU-R Recommendation RM.1177
and complies with the essential requirements of Directive 1999/5/EC
Conformity procedure under Annex IV of 1999/5/EC (Technical Construction file) has been
undertaken by
QinetiQ (0191) Fort Cumberland Road, Eastney, Portsmouth, England.
The Technical Construction File is held by Mr Heinz Hoghoff at
Koden Elektronik GmbH,
Am Gewerbepark 15,
D-64823 Gross-Umstadt / Hessen
Germany
Telephone +49 6078 2056 Telefax +49 6078 73824
Kenichi Chiwaki, QA Manager.
Koden Electronics Co., Ltd.
Statement Number: QQ-RTTE-11/05-01
: QQ-RTTE-12/05-01
: QQ-RTTE-14/05-01
Notified Body : QinetiQ
07 Jul. 2005
AMENDMENT HISTORY
RADAR PLOTTER SYSTEM OPERATION MANUAL
Doc No: 0093161022
No. Document No & Rev No. Date Amendments
0 93161022-00 04/06/29 First issue
1 93161022-01 05/01/11 Chapter3,5,6,7,8,9,10.
2 93161022-02 05/03/22 Chapter4
3 93161022-03 05/10/07 K-Link System
4 0093161022-04 06/01/19 Cover
5 0093161022-05 06/04/10 Declaration
6 0093161022-06 06/11/02
C-MAP MAX :Chapter1,2,3,4,5,6,7,8,9,10,11,12
7 0093161022-07 07/02/26 Chapter3
8
9
10
Amendment policy
When any change is applied in the document, only the document number of the relevant sheet(s) and
cover sheet are modified and the rest of the sheets are not changed. The document number is shown in
the footer area, right or left bottom of each sheet.
○
c2004, 2005 2006,2007 Koden Electronics Co.,Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, translated in any form by any means without
the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in this
publication are subject to change without notice. Koden assumes no responsibility for any errors,
incidentals or consequential damages caused by misinterpretation of the descriptions contained in this
publication.
Safety Symbols
To prevent the risk of personal injury or damage to the equipment, the following safety
symbols are used to indicate safety-related information. Be sure that you clearly un-
derstand the meanings of the symbols BEFORE using the equipment.
Symbols Used in Manual
This indicates a very dangerous procedure that could result
in serious injury or death if not performed properly.
DANGER
!
This indicates a hazardous procedure that could result in
serious injury or death if not performed properly.
WARNING
!
This indicates a hazardous procedure or danger that could
result in a light-to-severe injury, or that might damage the
equipment, if proper precautions are not taken.
CAUTION
!
Safety Symbols Used on Equipment
The following safety symbols are used inside or on the equipment near operation lo-
cations to provide information about safety items and operation precautions. Ensure
that you clearly understand the meanings of each symbol and take necessary precau-
tions BEFORE using the equipment.
This indicates high voltages with a risk of serious electric shock if the part is
touched. NEVER touch the part with bare hands, etc.
This symbol prohibits the operation shown inside the symbol. (The example
on the left prohibits disassembly.)
This symbol indicates that the operation inside the symbol is potentially
hazardous. (The example on the left indicates that a power plug should be
held when disconnecting it from an AC outlet.)
This indicates the ground (earth) terminal. If the equipment cannot be
grounded via a power cord,connect this terminal to ground. There is a risk of
serious electric shock if the equipment is not grounded.
MDP-621/641/640
RADAR PLOTTER
Operation Manual
MDP-621/641/640 OPERATION MANUAL –06 i
For Safety
WARNING and CAUTION for Scanner Unit and Antenna;
1 Do not approach the antenna while it is transmitting.
In addition, at inspection never look into the wave-guide during transmission.
Distance at which RF power density level to become 100 W/m2: 0.8 m
Distance at which RF power density level to become 10 W/m2: 8 m
2 There is a risk of receiving electric shock if these parts are touched by accident.
Only qualified personnel should remove covers on these parts.
1 2
WARNING for Display Unit;
There is a risk of receiving electric shock if these parts are touched by accident.
Only qualified personnel should remove covers on these parts.
ii MDP-621/641/640 OPERATION MANUAL – 06
Installation
Read and understand the manual thoroughly before installing this unit.
To The User
* Read and follow the operation and maintenance procedures in this manual. Note that this
equipment is only a navigational aid. There is no warranty for navigational safety. It is no sub-
stitute for prudent navigational procedure and should not be relied on solely for passage.
* If this equipment does not operate properly, immediately turn off the power switch and disconnect
the main power supply. Notify your authorized Simrad dealer or technical service center as soon
as possible.
* The liquid crystal display as well as some of the internal components of this radar can be dam-
aged by dropping or excessive force due to impact. Mount the unit so that it will not be subject to
these forces.
* Mercury (Hg) is used in the LCD backlight. When the unit is taken out of service, it should be
disposed of according to local regulations regarding hazardous materials.
DISCLAIMER
KODEN assumes no liability for any errors, omissions, damages, or accidents resulting from the
interpretation of the supplied documentations.
MDP-621/641/640 OPERATION MANUAL –06 iii
CAUTION
RADAR PLOTTER
MDP-621/641/640
1. When POB is active, Soft Key Menu does not appear by pressing GOTO Key
and WAYPOINT cannot be set.
To cancel POB, the following action is required. Turning the power off does not
cancel POB.
(1) Press POB Key.
(2) Soft Key Menu appears.
(3) Press the Soft Key assigned for POB CANCEL.
2. Pressing DELETE Key to erase any MARK will completely eliminate the des-
ignated MARK. The MARK cannot be retrieved once it is erased.
Additional Notice on Fish Finder Processor Unit CVB-20
1. Power Switch:
CVB-20 does not have an independent power switch.
Power is always on while it is plugged to the power source.
CVB-20’s power is not off even if the main display unit is off.
We recommend to using the switch on the distributor or connecting with a
separate switch to put the power off when the CVB-20 is not in operation.
2. Starting Fish Finder Operation:
Fish finder operation starts and its display appears at 30 seconds after both the CVB-20
and display unit are turned on.
iv MDP-621/641/640 OPERATION MANUAL – 06
MDP-621/641/640 Main Index
Operation manual
Main Index
Chapter 1 General Information
Chapter 2 Equipment Composition
Chapter 3 Specification
Chapter 4 Installation
Chapter 5 Basic Operation
Chapter 6 Plotter Operation
Chapter 7 Radar Operation
Chapter 8 Sounder Operation
Chapter 9 Navigation Data Operation
Chapter 10 MENU Operation
Chapter 11 Trouble Shooting
Chapter 12 Maintenance
93161022-03 Main Index
MDP-621/641/640 Chapter 1
Operation manual General Information
Chapter 1 General Information
Page No.
1.1 General description...................................................................1-1
1.2 Applicable technical standard..................................................1-1
1.3 Equipment composition............................................................1-1
1.3.1 Model outline ................................................................................................1-2
1.3.1.1 Radar Plotter.................................................................................................1-2
1.3.2 Network outline.............................................................................................1-3
1.3.2.1 Radar Plotter and Sounder ...........................................................................1-3
1.3.2.2 Radar Plotter multi-display............................................................................1-4
1.3.2.3 Radar Plotter multi-display and Sounder ......................................................1-5
1.4 Applied software........................................................................1-5
1.5 About GPS..................................................................................1-6
1.6 About radar ................................................................................1-7
1.6.1 What is radar ................................................................................................1-7
1.6.2 Characteristics of Radar Wave.....................................................................1-7
93161022-03 Contents
MDP-621/641/640 Chapter1
Operation manual General Information
Chapter 1 General Information
1.1General description
The K-link system is a network navigation system with radar, plotter, and sounder functions. The
system is developed for small and medium size vessels. The Radar Plotter (MDP-621/641/640)
features a high-resolution 7-inch TFT flat Liquid Crystal Display. This device provides a plotter screen,
radar screen, sounder screen, and a map-overlaid radar screen as multimode screens on a single
screen or split screen.
The device has worldwide C-Map NT MAX charts as its standard. For creating original charts, the
desired C-Map USER C-CARD shall be provided by the purchaser.
1.2Applicable technical standard
The Radar Plotter meets with the requirements of IEC 60945 Edition 3, general requirements for
marine electronic equipment.
1.3 Equipment composition
Table 1. 1 Model composition
Radar Plotter
Model MDP-621 MDP-641 MDP-640
Display RGD-600
Transceiver 2kW Radome
RB714A 4kW Radome
RB715A 4kW Open
RB716A
Aerial
1.2 ft 2 ft 3 ft
RW701A-03
4 ft
RW701A-04
0093161022-06 1-1
