Kogan KAPB10KALBA Manuale utente

10000MAH 18W

PD POWER BANK

BLACK ALUMINIUM

(KAPB10KALBA)

Caution!

•When using for the first time, note that the power bank will achieve its best

performance after two to three times fully charge and discharge.

•Extend the charging time for 1-2 hours in the first three times to maximise the

performance of polymer battery.

•Do not attempt to disassemble and modify the power bank.

•Avoid making physical damage to the power bank.

•Avoid using this product in the following environments: high temperature, low

pressure, low temperature, humidity, dust, magnetic field strong and long-term

exposure to sunlight.

•Recommended conditions for use are between 0°C to 35°C, with humidity of 5% -

95%.

•This product must not be exposed to dripping and splashing water. Keep away

from liquids, including cups that may spill.

•Follow the relevant local environmental regulations to dispose of the product and

accessories.

Tips:

•If you plan to not use the power bank for a long time, it is recommended to fully

charge the battery before storing, and to store it in a dry environment with a

temperature range from 5 - 35°C. Avoid direct exposure to sunlight.

•Fully discharge then perform full recharging if you have not used the power bank for

more than three weeks. Failure to do so may shorten battery life.

Environmental Claims

Name

Name and Content of Hazardous Substances

Cr (VI)

PBB

PBDE

Power bank

Accessories

O: Means the PH substances in the material is under the GB/T 26572 standard

X: Means the PH substances is out of the GB/T 26572 standard.

SAFETY & WARNINGS

In the box:

•1 x Power bank

•1 x USB Cable

•1 x Manual

OVERVIEW

Indicator light

USB Output Port2

USB Output Port1

Power

ON/OFF

Type-C input/output port

Micro USB Port

Power Display

After starting power bank, the in-built intelligent management system will perform a self-

test, and the screen will display the current power for each of the three outputs.

Digital display range: 0-100

100 = full power.

Status

Display

Power

Note

Charging the power

bank Flashing Digital precision

display

While charging, if the display

reads “100” and is not

flashing, the power bank is

fully charged.

Providing charge to

attached devices Solid Digital precision

display

During discharge (providing

power to devices), if the

display reads “00”, then the

power bank is out of power.

Not charging or

providing charge. Solid Digital no-precision

display

Push the button and the

power bank will automatically

turn off after for 8 seconds

Charging the Power Bank

•Connect the cable USB port to the charging device and the other end to the Micro

input connector of the power bank.

•After connecting, the power bank is automatically charged and the current power

level on the battery status indicator flashes. When the battery is fully charged, the

status indicator light will be on.

Providing charge to attached devices

•Check whether the charging voltage of the digital device matches the discharging

voltage of the power bank.

•Select one matching charging cable, connect one end to the power bank output

interface, the other end to the digital device, the power bank will automatically

recognise to charge a digital device.

OPERATION

Battery type

Grade-A polymer battery cell

Capacity

10000mAh/37Wh (TYP)

Micro-USB Input

DC 5V/2.4A, 9V/2A

Type-C Input

PD 5V/3A, 9V/2A (18W Max)

Type-C Output

PD 5V/3A, 9V/2A, 12V/1.5A (18W Max)

USB Output 1

DC 5V/3A, 9V/2A, 12V/1.5A (18W Max)

USB Output 2

DC 5V/3A, 9V/2A, 12V/1.5A (18W Max)

Total Output

Maximum 18W

Product dimensions

141 x 71 x 16mm

Product weight

280g

SPECIFICATIONS

NOTES

Need more information?

We hope that this user guide has given you

the assistance needed for a simple set-up.

For the most up-to-date guide for your product,

as well as any additional assistance you may require,

head online to help.kogan.com
