Konica Minolta 7013 Manuale utente
Sending a fax
Sending a fax using the ADF . . . . . . . . . . .. . . . . . . . . page 2
Sending a fax using the platen glass . . . . . . . . . .. . . . page 3
Broadcast . . . . . . . . . . . . .. . . . . . . . . . . . ............page 4
Cancel sending a fax . . . . . . . . . . . .. . . ............page 5
Making a copy
Basic copy . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . page 6
Sortcopy .....................................page 7
Enlarged/Reduced copy . . . . . . . . . . . .. . . . . . . . . . . . . page 8
Using the Bypass tray . . . . . . . . . . . .. . ...........page 10
Just in case
Clearing original document jams . . . . . . . . . . ......page 12
Clearing printout jams . . . . . . . . . . . .. . ...........page 14
Function table .......................page 16
Konica 7013
Quick Reference
Sending a fax using the ADF
2
Sending a fax
Set the document in the
ADF face up and adjust
the document guides.
Adjust resolution and contrast,
if necessary.
2
Enter the fax number using the numeric keypad
or
Press the one-touch key*1
or
Press SPEED DIAL/TEL INDEX and enter the three-
digit identifier for the speed-dial number using
the numeric keypad.
You can set up to 50 sheets of A4, A5 or F4 sized
documents in the ADF at one time.
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
*1: When you press a one-touch key, you do not need
to press
START
.
Enter the fax number.
3Press START.
4
Press COPY/FAX to change
to Fax mode.
1
3
Sending a fax using the platen glass
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
Press DOCUMENT SIZE to
select the document size.
Adjust resolution and contrast,
if necessary.
4
Press COPY/FAX to change
to Fax mode.
1Place the document on the platen
glass face down and align it to the
right front corner.
Close the platen cover.
3
For ways to enter the fax number,
refer to step 3 on page 2.
Enter the fax number.
5
Press START.
6
If you want to send more pages,
place the next page, then press NEXT DOC.
When you have finished scanning all
pages, press START
If there’s a document in the ADF,
remove it.
Open the platen cover.
2
Broadcast
4
Set the document in the
ADF face up, or on the
platen glass face down.
Adjust the document type and the
contrast, if necessary.
2
Enter the fax number using the numeric keypad.
or
Press the one-touch key*1
or
Press SPEED DIAL/TEL INDEX and enter the three-digit identifier for
the speed-dial number using the numeric keypad.
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
Press COPY/FAX to change
to Fax mode.
1
*1: When you press a one-touch key, you do not need to press
START
.
Enter the fax number.
To add more fax numbers,
repeat step 3 and 4.
4
Press START.
5
Press BROADCAST.
3
5
Cancel sending a fax
Press to see the individual numbers
within the broadcast.
Press
or
until you find the number
you want to cancel.
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
Press COMM.CANCEL/CONFIRM.
1
Press STOP.
4
If you want to cancel the command
shown, press CANCEL,CANCEL.
If you want to cancel another command, go back to step 2.
3
Press
or
to scroll through
currently stored commands.
2
Basic copy
6
Making a copy
Press COPY RESET to clear
the previously entered copy
settings.
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
Press COPY/FAX to change
to Copy mode.
1
Press START.
5
Adjust the following,
if necessary.
• Select the document size by
pressing the DOCUMENT SIZE.
• Select the document type and
the contrast.
3
Set the document in the
ADF face up, or on the
platen glass face down.
2Enter the number of
copies using the
numeric keypad.
4
If you want to stop copying,
press STOP.
Helpful Tip
7
Sort copy
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
Press COPY/FAX to change
to Copy mode.
1
Press START.
5
The sort setting is set to On for the default setting.
To change the default setting:
1. Press Program key, B,3,0,6,ENTER.
2. Press
or
until the setting you want appears.
3. Press ENTER to save the setting.
Enter the number of
copies using the
numeric keypad.
4
Helpful Tip
Press SORT to turn the
sort setting to on or off.
When the sort setting is On, the LED
on SORT glows.
2
If you selected non-sort copies,
you can use the platen glass.
Set the document in
the ADF face up.
Adjust resolution and contrast,
if necessary.
3
3
121
112
223
33
3
123
123
123
12
N
on-sort:
S
ort:
Enlarged/Reduced copy
8
If you want enlarged copies,
use the platen glass.
Set the document in the
ADF or on the platen glass.
Adjust the document type and the
contrast, if necessary.
1
If you want to reduce or enlarge your document
automatically to fit on the paper size you selected,
program the following setting in advance:
1. Press Program key, B,3,0,4,ENTER.
2. Select “Enlarge/Reduce” by using
or
of
the cursor key.
3. Press ENTER.
Helpful Tip
3
Enter the document size
by pressing the DOCUMENT
SIZE.
2
You can choose from:
• 50 %
• 70 % (A4 -> A5)
• 81 % (B5JIS -> A5)
• 86 % (A4 -> B5JIS)
• 115 % (B5JIS -> A4)
• 122 % (A5 -> B5JIS)
• 141 % (A5 -> A4)
• 200 %
1Choose the desired ratio by using
or
of the cursor key.
Fixed ratio
9
MONITORMONITORMONITOR
/CALL
MONITORMONITOR
/CALL
GROUP
1Press ZOOM to turn the ZOOM light on.
2Adjust the ratio by 1 percent increments
using
or
of the cursor key.
You can set the ratio between 50% and 200%.
Adjust by 1 percent increments
1Press #.
2Enter your desired ratio (50 to 200 %)
using the numeric keypad.
3Press #again.
Direct
Press START.
5
Enter the number of copies
using the numeric keypad.
4
Using the Bypass tray
10
Press COPY/FAX to change
to Copy mode.
1
Set the document in the ADF face up,
or on the platen glass face down.
2
Open the bypass tray on the right side
of your machine.
Pull out the hopper of the bypass tray
and pull the release lever.
Hopper
Release lever
3Place the paper on the bypass tray
face down.
Adjust the paper guide to fit the
paper. Then push back the flapper
release lever.
4
