KRAFTWERK 32039 Manuale utente
www.KRAFTWERKtools.com
Rechargeable 10 W COB LED
power work and spotlight
Art. 32039
EN
Instruction Manual
lamp.
11.1 V
2200 mAh
Li-ion
-10 0C - 40 0C
3 h
IP65
3 h
1000 Lumen
6 h
500 Lumen
IK07
6000 K
Temp
color
PRODUCT DESCRIPTION
2
SPECIFICATIONS
COB LED light intensity: 500 Lumen (50% brightness) / 1000 Lumen (full brightness)
Light Source: 10 W COB LED
Working time: 6 h (50% brightness) / 3 h (full brightness)
Charging time: Approx. 3 h
Input power supply: 100-240 V~ 50/60 Hz
Transformer: 15.0 V 1.0 A
IP level: IP65
IK level: IK07
1. ON/OFF switch
2. 10 W COB LED
3. Charger socket
4. Battery capacity indicator
5. U bracket
6. AC main charger 100-240 V~ 50/60 Hz (Art. 32039AL)
6
2
1
5
3
4
USING INSTRUCTIONS
The ON/OFF switch is located on the back of the lamp:
●Press the ON/OFF switch once: 50% brightness
●Press the ON/OFF switch a second time: full brightness
●Press the ON/OFF switch a third time: OFF
CHARGING PROCESS
To charge the lamp, remove the rubber cap from the hollow plug socket on the rear of the lamp and
insert the round plug of the AC/DC power supply. Then connect the AC/DC power supply to a mains
socket.
The battery should only be charged with the charger supplied by the manufacturer. To avoid damage,
please do not use any other chargers.
When not in use, the charger must be unplugged from the outlet.
Keep the lamp in a dry place away from direct sunlight. The lamp must be protected against high
humidity and water.
WARNING!
Avoid looking directly into the beam, as it will dazzle.
Don't use the lamp near open flames.
Do not disassemble.
Lamp gets hot after long use! Cool down the lamp before touch it.
If lamp will be stored for one month or more, please fully charge it prior to storage.
Don't leave battery flats, otherwise it could be over discharged and may NOT be able to be reused.
The battery cannot be replaced.
The battery must be removed from the appliance before it is scrapped.
The appliance must be disconnected from the supply mains when removing the battery.
The battery is to be disposed safety.
NOTE: Before disposing of damaged goods, check with your state Environmental Protection
Agency to find out about special restrictions on the disposal of the lamp and batteries or return
them to a certified service center for recycling.
3
WARRANTY
We do not take responsibility for any damage caused by misuse or any use that is not in compliance with
the safety standards described herein.
CUSTOMER SERVICES
Contact your local importer of your specialized dealer to obtain address of our service department.
You find our partners under www.KRAFTWERKtools.com
From date of purchase receipt
2 YEARS GUARANTEE
on material- or production-defects
4
ART. 32025-3
OPTIONAL:
Max. 1648 mm
Min. 684 mm
