3 Overview
The SL-14RC is a highly versatile master room controller that acts as an all-in-one
extended remote control panel for control of A/V equipment—especially projectors
and associated equipment—in any room (such as classrooms, boardrooms, or
auditoriums). It streamlines operations and simplifies control by integrating audio,
video, and computer-video sources into a centralized system. Optional 3-button
remote control panels are available which enable you to remotely duplicate the
functionality of front panel buttons.
The SL-14RC features:
•12 configurable front panel buttons (configured using the K-Config
Configuration software)
Available from Kramer Electronics on our Web site at:
http://www.kramerelectronics.com/support/?soft=k-config
•1 configurable rotary up/down controller with direction indicator LEDs
(configured using the K-Config Configuration software)
•1 general purpose I/O port that can be configured as an analog input, digital
input, or digital output for interfacing with a variety of devices such as
sensors, switches, LEDs, and relays
•6 bi-directional RS-232 ports that can control AV equipment such as
projectors, LCD and PDP displays, power amplifiers, switchers and scalers
•2 relay contacts that can control other room items related to the AV system,
such as, raising and lowering drapes, screen or projector
•IR control on 2 outputs (terminal blocks)
•IR Learning that learns commands from any IR remote
•Compatibility with Kramer Site-CTRL software for network remote control
and management over the Ethernet port
•A K-NET™ control channel that can be used to connect to RC-3TB Remote
Control Panels, or for connecting compatible user interfaces and supplies
power and control data over a single cable
K-NET™ is a proprietary Kramer protocol for interconnecting Kramer units
•Flexible control via Ethernet and K-NET
