Kuryakyn 8621 Manuale utente
PARTS INCLUDED
1 Lens Grill
1 Alcohol Pad
1 Installation Instructions
Please read and understand entire instructions before starting installation.
THANK YOU FOR CHOOSING KÜRYAKYN!
IN ORDER TO PROTECT YOU AND OTHERS FROM POSSIBLE INJURY
AND/OR PROPERTY DAMAGE OR LOSS, PLEASE PAY CLOSE ATTENTION
TO ALL INSTRUCTIONS, WARNINGS, CAUTIONS AND ATTENTION NOTES
REGARDING THE USE AND CARE OF THIS PRODUCT.
CAUTION! This indication alerts you to the fact that ignoring the contents described herein
can result in potential injury or material damage.
ATTENTION!
This indication alerts you to the fact that ignoring the contents described herein
may negatively affect product performance and functionality.
STRICTLY OBSERVE THE FOLLOWING GUIDELINES IN ORDER TO USE THE
PRODUCT PROPERLY AND AVOID POTENTIALLY DANGEROUS ACCIDENTS.
PROCEDURE
STEP 1 Read and understand all steps in the instructions before starting the installation. Park
the motorcycle on a hard, level surface; turn off the ignition and allow the engine to cool.
STEP 2 Test fit the Lens Grill to the rear fender light. It may be helpful to make light,
temporary markings with masking tape to ensure a proper fit for installation.
CAUTION! Clean only with warm water and a mild, non-abrasive soap. Some cleaning
products contain harsh chemicals that can severely damage product and void warranty.
STEP 3 Clean the rear fender light. If the mounting area is excessively dirty, wash with a
mild soap and water, rinse the area and allow to dry completely. Proceed to clean the area with
the supplied alcohol pad and let the area dry completely.
ATTENTION! Ensure the area of installation is free of grease, oil, dirt or other debris to ensure
proper adhesion. Küryakyn WILL NOT issue
a warranty on any parts lost due to improper
installation.
ATTENTION! The adhesive will not bond correctly
if applied at temperatures less than 50°F. Do not
attempt this installation in temperatures less than
50°F.
STEP 4 Rub the adhesive backing on the Lens
Grill to activate the adhesive.
8621-11HD-0509
LENS GRILL FOR REAR FENDER LIGHT 8621
-cont.-
PIC. 1
FITS: ’09-UP ULTRA CLASSIC ELECTRA GLIDE AND ELECTRA GLIDE CLASSIC
INSTALLATION
STEP 5 Remove the adhesive backing and mount the Lens Grill to the rear fender light using any
markings from Step 2 as a guide.
STEP 6 Press and hold the Lens Grill in place for one (1) full minute, full bonding strength will
occur in 24 hours.
PAGE
2
LENS GRILL FOR REAR FENDER LIGHT
PIC. 2
