Kwikset Smartcode 888 Manuale utente
©2020 Spectrum Brands, Inc.
Programming and Troubleshooting Guide
Mastercode 2
Troubleshooting: Installation 8
Troubleshooting: Door Jamming and Door Handing 10
Troubleshooting: Keypad 14
Troubleshooting: Smart Home Systems 15
Troubleshooting: Battery 17
Battery FAQ 18
61899 Rev 01
1 / 18
Technical Support
1-866-863-6584
www.kwikset.com
1
3
2
4
5
6
7
©2020 Spectrum Brands, Inc.
Mastercode
Programming timeout: If no button is pressed for ve seconds, the system will time out
(indicated by three beeps and a red ashing lock button), and you will need to restart the procedure.
1. Make sure the audio setting on the lock is turned on / not muted.
2. Keep door open. Press and HOLD the Program button until the lock
button ashes green (about 5 seconds).
3. Enter new Mastercode.
4. Press Lock button once.
5. Re-enter Mastercode.
6. Press Lock button once.
If programming is successful, the lock button will flash green once
with one long beep.
If programming is unsuccessful, the lock button will ash red three
times with three beeps. Make sure the Mastercode has not already been
programmed. Attempt the procedure again, making sure to enter the
same new Mastercode in step 2 and 4.
7. Press the Program button once. If you hear three beeps and see the
lock button ash green, the Mastercode is enabled. Note: The lock will
time out after ve seconds.
Using a Mastercode is an optional, added-security measure. It is not enabled by default. A Mastercode is
used to add and delete user codes, but it cannot unlock the door (unless the same code is programmed
as a user code, though this is not recommended). The Mastercode must be 4-8 digits.
61899 Rev 01
2 / 18
Technical Support
1-866-863-6584
www.kwikset.com
1
A
B
About the Mastercode
Enabling and Setting the Mastercode
©2020 Spectrum Brands, Inc.
1. Keep door open. Press the Program button once. The lock button will
ash green and you will hear three beeps.
2. Enter Mastercode.
3. Press Lock button once.
4. Enter new user code.
5. Press Lock button once.
If programming is successful, the lock button will flash green once
with one long beep.
If programming is unsuccessful, the lock button will ash red three times
with three beeps. Make sure the user code is not a duplicate and that it is
between 4 and 8 digits during your next attempt. Make sure the lock has
room for an additional code. If all user codes are lled, delete a code to make
room for this one. Make sure to enter a valid Mastercode in step 2.
6. While the door is open and locked, test the user code to make
sure it unlocks the door.
The procedure for adding user codes is different when the Mastercode is enabled. For instuctions on how
to add user codes when the Mastercode is disabled, see the Installation and User Guide that came with
your lock.
Mastercode (cont.)
61899 Rev 01
3 / 18
Technical Support
1-866-863-6584
www.kwikset.com
CAdding User Codes with the Mastercode Enabled
1
©2020 Spectrum Brands, Inc.
1. Keep door open. Press the Program button once. The lock button will
ash green and you will hear three beeps.
2. Press Lock button once.
3. Enter Mastercode.
4. Press Lock button once.
5. Enter user code to be deleted.
6. Press Lock button once.
7. Re-enter user code to be deleted.
8. Press Lock button once.
Procedure continued on next page
Mastercode (cont.)
61899 Rev 01
4 / 18
Technical Support
1-866-863-6584
www.kwikset.com
DDeleting a Single User Code with the Mastercode Enabled
1
©2020 Spectrum Brands, Inc.
If programming is successful, the lock button will flash green once
with one long beep.
If programming is unsuccessful, the lock button will ash red three times
with three beeps. Make sure to enter the same valid code in steps 5 and
7. Make sure to enter a valid Mastercode in step 3.
9. While the door is open and locked, test the user code to make sure it
no longer unlocks the door.
1. Keep door open. Press the Program button once. The lock button will
ash green and you will hear three beeps.
2. Press Lock button once.
3. Enter Mastercode.
4. Press Lock button once.
5. Press “9-0” six times.
6. Press Lock button once.
Procedure continued on next page
Mastercode (cont.)
61899 Rev 01
5 / 18
Technical Support
1-866-863-6584
www.kwikset.com
EDeleting All User Codes with the Mastercode Enabled
1
©2020 Spectrum Brands, Inc.
7. Press “9-0” six times.
8. Press Lock button once.
If programming is successful, the lock button will flash green once
with one long beep.
If programming is unsuccessful, the lock button will ash red three times
with three beeps. Make sure to enter a valid Mastercode in step 3 during
your next attempt.
9. Press the Lock button while the door is open and unlocked. If
the latch bolt does not extend to lock, then all codes have been
successfully deleted.
Mastercode (cont.)
61899 Rev 01
6 / 18
Technical Support
1-866-863-6584
www.kwikset.com
1
©2020 Spectrum Brands, Inc.
1. Make sure the audio setting on the lock is turned on / not muted.
2. Keep door open. Press and HOLD the Program button until the lock
button ashes green (about 5 seconds).
3. Press Lock button once.
4. Enter Mastercode.
5. Press Lock button once.
6. Re-enter Mastercode.
7. Press Lock button once.
If disabling is successful, the lock button will flash green once with
one beep.
If programming is unsuccessful, the lock button will ash red three times
with three beeps. Make sure the Mastercode has been enabled before
trying to disable it. Attempt this procedure again, making sure to enter
the same Mastercode in steps 3 and 5.
8. Press the Program button once. If you don’t immediately hear three
beeps and see the lock button ash green, the Mastercode is disabled.
Note: The lock will time out after ve seconds.
Mastercode (cont.)
61899 Rev 01
7 / 18
Technical Support
1-866-863-6584
www.kwikset.com
FDisabling and Deleting the Mastercode
1
©2020 Spectrum Brands, Inc.
Troubleshooting: Installation
If you encounter any of the problems above, the deadbolt latch may be
installed upside down. Remove the interior assembly, mounting plate,
and exterior assembly from the door, and look at the latch inside the
door hole.
If the word “UP” is upside down and at the bottom of the latch, the latch
is installed incorrectly.
Reinstall the latch, making sure the word “UP” faces upward.
Other solutions may include:
1. Loosen the mounting screws and make sure they go in straight without
cross-threading.
2. Loosen the mounting screws and latch screws and reinstall the
mounting screws rst before tigthening the latch screws.
3. Chisel out the bore hole opposite side of the latch if the latch cannot
be centered.
61899 Rev 01
8 / 18
Technical Support
1-866-863-6584
www.kwikset.com
2
A
B
C
The interior mounting screws are dicult to tighten.
The interior and exterior assembly won’t mount parallel to the door edge.
The interior assembly does not fit on the mounting plate.
©2020 Spectrum Brands, Inc.
The turnpiece was rotated past its normal range.
Troubleshooting: Installation (cont.)
If the interior assembly is not installed on the door, place the interior
cover over it. Align the hole in the turnpiece with the shaft.
The turnpiece should be able to rotate to the vertical position.
The triangular turnshaft should point up as shown.
If it cannot rotate to the vertical position, use force to rotate the
turnpiece clockwise until it clicks. The turnpiece should now be able to
rotate to the vertical position.
If the interior assembly is installed on the door, and the turnpiece cannot
rotate to a vertical position, perform the door handing process. See the
Installation and User Guide for more details.
If manual door handing still does not work, contact Customer Service.
Vertical
Vertical
61899 Rev 01
9 / 18
Technical Support
1-866-863-6584
www.kwikset.com
DThe turnpiece is upside down, or it cannot rotate to a vertical position.
2
©2020 Spectrum Brands, Inc.
Troubleshooting: Door Jamming and Door Handing
The door handing process was not
executed during installation.
Perform the door handing process in the Installation Guide.
The latch cam is hitting the bore hole
Remove the mounting plate and exterior assembly (A). Use a
screwdriver to turn the latch (B). If it hits the bore hole, use a
chisel to correct the bore hole (C).
The wrong deadbolt latch is installed.
SmartCode deadbolts require a tapered latch bolt for ease of operation.
If the latch being used is from an older lock, it will likely not have a
tapered latch bolt. Remove the lock from the door, including the old
latch. Replace with the new tapered latch that came with the lock and
reinstall the lock.
A
B
C
61899 Rev 01
10 / 18
Technical Support
1-866-863-6584
www.kwikset.com
3
A
B
The lock jams and the turnpiece does not rotate smoothly.
The lock beeps, the lock button flashes red, and the door cannot lock.
B1
B2
B3
B4
The deadbolt latch and strike are misaligned,
causing the latch to bind.
Adjust the tab of the lower strike (for your knob or lever) to help align the
upper latch and strike so that the upper latch bolt enters the strike when
the door is locked. If needed, call Kwikset to order a warped door kit.
