KYMCO Quannon 125 Nota di rilascio
DRIVER'S MANUALDRIVER'S MANUAL
KWANG YANG MOTOR CO.,LTD.KWANG YANG MOTOR CO.,LTD.
QUANNON 125QUANNON 125
Dear KYMCO bike Users:
Thank you for purchasing this KYMCO bike and welcome to the
family of KYMCO bike riders. To enjoy safer and more pleasant
riding, become thoroughly familiar with this owner's manual before you
ride the bike. You safety depends not only on your own alertness
and familiarity with the bike but also the bike mechanical
condition. A pre-ride inspection before every outing and regular
maintenance are essential. The quality of each KYMCO bike is
guaranteed.
1. The information and specifications stated in this manual are for
reference only and subject to change without notice.
2. When starting the engine, the battery must be installed to
facilitate starting and increase the engine performance.
Note:
TABLE OF CONTENTS
1.PRECAUTIONS FOR A SAFE RIDING
2.ASSEMBLY PARTS
3.OPERATION INSTRUCTIONS
4.PRE-RIDE INSPECTION
IGNITION SWITCH/STEERING HANDLEBAR LOCK
ELECTRIC STARTER BUTTON. HEADLIGHT SWITCH
ENGINE STOP SWITCH. PASSING LIGHT CONTROL SWITCH
HEADLIGHT DIMMER SWITCH. TURN SIGNAL SWITCH
HORN BUTTON
HELMET BUCKLE. TOOL BOX
INSTRUMENTS AND INDICATORS
MULTI-FUCTION DISPLAY
ADVANCE INSPECTION. ENGINE OIL LEVEL INSPECTION/REFILING
BRAKE INSPECTION. TIRE INSPECTION
FUEL LEVEL INSPECTION/REFILLING
STEERING HANDLEBAR. BRAKE SHOE INSPECTION
3
5
7
7
8
10
11
12
15
13
20
21
23
17
9
20
TABLE OF CONTENTS
5.ENGINE STARTING METHODS
6.NORMAL RIDING METHOD
7.PRECAUTIONS FOR RIDING
HORN/LIGHTS INSPECTION
DRIVE CHAIN INSPECTION/ADJUSTMENT
CLUTCH LEVER FREE PLAY INSPECTION
FRONT/REAR SHOCK ABSORBER INSPECTION
BRAKE PERFORMANCE INSPECTION. REARVIEW MIRROR ANGLE CHECK
LICENSE PLATE CHECK.
PREVIOUS ABNORMAL PARTS INSPECTION
LUBRICATION POINT CHECK
WHEN THE ENGINE IS COLD
WHEN THE ENGINE IS WARM
STARTING THE ENGINE. REBOUND THE SIDE STAND
CORRECT SITTING POSITION. START MOVING
29
30
31
31
32
33
25
26
28
29
TABLE OF CONTENTS
CORRECT RIDING. SPEED CONTROL
PROPER RIDING WILL PROLONG THE SERVICE LIFE OF ENGINE
APPLY BOTH FRONT AND REAR BRAKES WHEN BRAKING
DO NOT MAKE SUDDEN STOP OR SHARP TURN
BE MORE CAREFUL WHILE RIDING IN RAINY DAYS
WHILE GO NEAR THE PARKING PLACE
WHILE THE MOTORCYCLE IS COMPLETELY STOPPED
PARKING. HANDLEBAR
AIR CLEANER INSPECTION AND AIR CLEANER CLEANING&REPLACEMENT
APPEARANCE CLEANING
BATTERY
FUSE REPLACEMENT
ENGINE OIL CHANGE
SPARK PLUG INSPECTION
8.HOW TO STOP RIDING
9.EASY MAINTENANCE
45
33
34
35
36
31
32
38
38
40
41
42
44
TABLE OF CONTENTS
10.IMPORTANT NOTICES
BRAKE FLUID LEVEL INSPECTION/REFILLING
RUBBER COVER INSPECTION FOR WIRE AND CABLE
WHEN THE ENGINE FAILS TO START OR STOPS DURING RIDING
IN CASE OF BREAKDOWN
POLLUTION-FREE PERIODIC MAINTENANCE SCHEDULE
SPECIFICATIONS
CLEAN AIR SYSTEM
46
47
49
50
47
48
Location of Frame Serial Number
FRAME NUMBER
The read frame number, please remove
with a flat head screwdriver.
Frame number is the same written in document and
warranty card.
Please write down your frame number in place below.
the cover on
inner cover
FRAME NUMBER:
1
ENGINE NUMBER
The engine number is stamped on left engine case.
Please write down your engine number in place
below.
KEY NUMBER
The key number (1) will be needed when you order
replacement part. Record the number for your
reference.
ENGINE NUMBER:
KEY NUMBER: (1)
2
1.PRECAUTIONS FOR A SAFE RIDING
(1) CLOTHES
A motorcycle rider should not wear loose or too long
clothes to avoid danger.
During riding or 10 minutes after the motorcycle is stoppd
, do not touch the exhaust muffler to avoid scalding.
When parking the motorcycle, keep it away from dry lawn
or inflammables to avoid danger.
To relax and wear comfortable clothes are the main
points for a safe riding.
To observe traffic laws, keep a cool mind, relax and be
careful will provide you a safe riding.
Wear helmet and fasten it tightly.
Have the clothes well-arranged. Fasten shirt cuffs and
keep them from hooking the brake lever.
Wear low-heeled shoes for a safe riding.
When riding, use both hands to grasp the handlebar. It is
very dangerous to hold the handlebar with one hand.
3
CAUTION:
