KYMCO XCITING 250 Manuale utente

OWNER'S MANUAL

KWANG YANG MOTOR CO.,LTD.

XCITING 500 AFI

XCITING 500

XCITING 250 AFI

XCITING 250

Issued: 15.02.2006

FOREWORD

Thank you for purchasing this KYMCO scooter and welcome to the family of KYMCO

scooter riders.

Please read this owner's manual carefully before riding so that you will be thoroughly

familiar with the proper operation of your scooter controls, its features, capabilities, and

limitations.

To ensure a long, trouble-free life for your scooter, give it the proper care and

maintenance described in this manual.

For replacement parts and accessories, we recommend genuine KYMCO products.

They've been specially designed for your vehicle and manufactured to meet KYMCO's

demanding standards.

Keep this owner's manual aboard your scooter at all time so that you can refer to it

whenever you need information. This manual should be considered a permanent part of

the scooter and should remain with the scooter when it is sold.

All information, illustrations, photographs and specifications contained in this manual

are based on the latest product information available at the time of publication. Due to

improvements or other changes, there may be some discrepancies in this manual.

KYMCO reserves the right to make changes at any time without notice and without

incurring any obligation.

READ THIS MANUAL CAREFULLY

CAUTION

NOTE:

ON-ROAD USE

Your Owner's Manual contains important information on safety, operation, and

maintenance. Any one who operates this scooter should carefully read and understand

the contents of this manual before riding the scooter.

Gives helpful information

The Owner's Manual should be considered a permanent part of your scooter. It should

remain with the vehicle at all times and stay with the scooter if it is sold.

Indicates a strong possibility that serious injury or death may

result if instructions are not followed.

Indicates a possibility that equipment or property damage

could result if instructions are not followed.

SPECIAL MESSAGES

Please read this manual and follow its instructions carefully. To emphasize special

information the words , and carry special meanings and should

be carefully reviewed.

This scooter is designed to be used only on the road.

WARNING CAUTION Note

WARNING

BRAKES.........................................28

FUEL FILL CAP................................30

FRONT SMALL BOX.........................32

CENTER SMALL BOX......................33

SEAT..............................................34

ADJUSTABLE BACKREST...............35

CENTER COMPARTMENT...............36

CENTER COMPARTMENT LIGHT.....37

CELL PHONE SOCKET & CELL

PHONE FIXED SEAT.......................37

HELMET HOLDERS........................39

STAND...........................................40

SUSPENSION.................................42

DIAGNOSTIC TOOL CONNECTOR

(XCITING 500AFI/XCITING 250AFI)..43

STARTING THE ENGINE.................45

RIDING...........................................50

PRE-RIDE INSPECTION...............44

OPERATION.................................45

CONTENTS

SCOOTER SAFETY........................1

PARTS LOCATION........................12

IMPORTANT SAFETY

INFORMATION................................1

PROTECTIVE APPAREL...................3

LOAD LIMITS AND GUIDELINES.......5

LOCATION OF THE WARNING AND

SPECIFICATION LABELS..................8

FRAME NUMBER............................16

ENGINE NUMBER...........................17

KEY NUMBER.................................18

KEYS.............................................19

IGNITION SWITCH..........................19

INSTRUMENT AND INDICATORS....21

RIGHT HANDLEBAR SWITCH..........25

LEFT HANDLEBAR SWITCH............27

CONTROLS..................................19

Page Page

(Cont'd)

COOLANT.......................................85

FRONT AND REAR SUSPENSION

INSPECTION..................................87

SIDE STAND...................................88

BRAKE LEVER ADJUSTER.............89

BRAKE FLUID................................89

BRAKE PAD WEAR........................90

PARKING BRAKE OPERATION

(XCITING 500 AFI/XCITING 500).......91

BATTERY........................................92

FUSE REPLACEMENT....................94

TIRES............................................97

CLEANING.................................101

STORAGE GUIDE.......................106

SPECIFICATIONS

(XCITING 500AFI/XCITING 500)...109

SPECIFICATIONS

(XCITING250AFI/XCITING 250)....111

PARKING........................................55

BREAK-IN (RUNNING IN)................57

THE IMPORTANCE OF

MAINTENANCE..............................59

MAINTENANCE SCHEDULE

(XCITING 500 AFI/XCITING 500).......60

MAINTENANCE SCHEDULE

(XCITING 250AFI/XCITING 250 )......63

TOOL KIT.......................................66

CRANKCASE BREATHER...............66

ENGINE OIL...................................67

TRANSMISSION OIL.......................76

AIR CLEANER................................78

THROTTLE OPERATION.................81

IDLE SPEED...................................82

SPARK PLUG..................................84

INSPECTION AND

MAINTENANCE............................59

Page Page

SCOOTER SAFETY

IMPORTANT SAFETY INFORMATION

Wear a helmet

Make yourself easy to see

Know your limits

Your scooter can provide many years of service and pleasure, if you take responsibility for

your own safety and understand the challenges that you can meet on the road. There is

much that you can do to protect yourself when you ride. You will find many helpful

recommendations throughout this manual. Following are a few that we consider most

important.

Scooter safety equipment starts with a quality helmet. One of the most serious injuries that

can happen is a head injury. Always wear a properly approved helmet. You should also

wear suitable eye protection.

To make yourself more visible, wear bright reflective clothing, position yourself so other

drivers can see you, signal before turning or changing lanes, and use your horn when it will

help others notice you.

Ride within the boundaries of your own skill at all times. Knowing these limits and staying

within them will help you to avoid accidents.

Keep your scooter in safe condition

Inspection before riding

Be extra safety conscious on bad weather days

odification

For safe riding, it's important to inspect your scooter before every ride and perform all

recommended maintenance. Never exceed load limits, and only use accessories that have

been approved by KYMCO for this scooter.

Do not forget to perform an entire safety inspection to ensure the safety of the rider.

Riding on bad weather days, especially wet ones, requires extra caution. Braking distance

double on a rainy day. Stay off of the painted surface marks, manhole covers and greasy

appearing areas as they can be especially slippery. Use extreme caution at railway

crossings and on metal gratings and bridges. Whenever in doubt about road conditions,

slow down.

Modification of the scooter, or removal of original equipment may render the vehicle unsafe

or illegal. Obey all applicable equipment regulations in your area.

PROTECTIVE APPAREL

Helmets and protection

Additional riding gear

For your safety, we strongly recommend that you always wear an approved scooter helmet,

eye protection, boots, gloves, long pants, and a long-sleeved shirt or jacket whenever you

ride.

Your helmet is your most important piece of riding gear because it offers the best protection

against head injuries. A helmet should fit your head comfortably and securely. Always wear

a face shield or goggles to protect your eyes and help your vision.

In addition to a helmet and eye protection, we also recommend:

Sturdy boots with non-slip soles to help protect your feet and ankles.



Leather gloves to keep your hands warm and help prevent blisters, cuts, burns and

bruises.

A scooter riding suit or jacket for comfort as well as protection. Bright-colored and

reflective clothing can help make you more noticeable in traffic. Be sure to avoid loose

clothes that could get caught on any part of your scooter.

(1)Wear gloves.

(2)Clothes should be close-fitting.

(3)Always wear an helmet. You

should also wear a face shield

or goggles.

(4)Wear bright or reflective

clothing.

(5)Shoes should be close-fitting,

have low heels and offer ankle

protection.

(1) (2) (3)

(4)

(5)

Not wearing a helmet

increases the chance of

serious injury or death in a

crash.

Be sure you and your

passenger always wear an

approved motorcycle helmet

that fits properly. You should

also wear eye protection and

other protective apparel when

you ride.

WARNING
